Anest Iwata SER-24 Instruction Manual

Instruction Manual
DEIONIZING AIR BLOW GUN
SER-24
More than 2,000V AC high voltage is dealt with the product, therefore, be sure to read this manual before using the product to fully understand the functions
of this unit.
Keep the manual for future use.
■ Residual risk
Residual risk map requiring protective measures by the product user
Model: " DEIONIZING AIR BLOW GUN: SER-24"
Residual risks are classified and described according to the definition below.
DANGER Indicates that a person is likely to die or be seriously injured if protective measures are not implemented.
WARNING Indicates that if the warning is neglected, it may result in death or serious injury.
CAUTION Indicates that if the caution is neglected, it may result in injury or property damage.
The symbols and numbers of the parts shown in the figure correspond to those listed in the "List of Residual Risks" of this product. For details on each residual risk,
refer to "Residual Risk List".
Air inlet
エアー入力（φ6）
DANGER
Warning No.1
Caution
DANGER
Warning
Note
Gun body
本体
Power input cable (3M)
電源入力ケーブル（3m）
Optional
エアチューブ（φ6）
Air tube
No.4
DANGER
Warning
Note
1
Residual risk where parts on the equipment
are not identified
DANGER
Warning No.2,No.3,No.6
Caution
No.5
AC Adapter
ACアダプタ
AC100V〜240Vへ
エア源へ
To Air source
