- Page 1 User Manual STUDIOMASTER T700 Turntable V1.2...
-
Page 2: Table Of Contents
Introduction ................................ 1 Unpacking ....................................1 Scope of delivery ..................................1 Foreword ................................2 Analogue music experience ..............................2 Integrated phono preamplifier .............................. 2 Electronic speed control ................................ 2 Note on wearing parts ................................2 Assembly and installation ............................ 3 Assembly step 1: Checking the DIP switches .......................... -
Page 3: Introduction
Introduction Congratulations on purchasing your new STUDIOMASTER T700 turntable and thank you for the trust you have placed in us through the acquisition of this high-quality product. Before putting your Revox turntable into operation, you should follow the details in these operating instructions so that the sound quality can reach its full potential. -
Page 4: Foreword
Thanks to the built-in phono preamplifier, the T700 is compatible with all Revox products - such as Joy S119, Joy S120, and also the M series as well as with products from the past (Evolution, Emotion, Exception, B series) and can be easily integrated into a Revox Multiroom and Multiuser System. -
Page 5: Assembly And Installation
Assembly and installation The STUDIOMASTER T700 turntable is a mechanical precision instrument and is therefore dismantled before transport so that the turntable bearings and tonearm bearings are not damaged during transport. Before dismantling, each T700 turntable is completely assembled, the shaft and bearings are aligned with one another and a complete final test is carried out. Acoustic monitoring of the T700 in a hi-fi chain concludes the test. -
Page 6: Assembly Step 2: Placing Sub-Platter And Platter
with two hands and then encircle the pulley (drive shaft motor) by means of a slight pull. For an even application of the belt, turn the platter a few revolutions by hand until the belt is in the middle of the pulley. STUDIOMASTER T700 Turntable... -
Page 7: Assembly Step 4: Mounting The Tonearm Weight On The Tonearm
0.2 g according to your own preferences. The possible range provided for the tracking force of the Quintet Bronze System by Ortofon itself is 2.1 - 2.5 g. A detailed description of the Revox tonearm scale can be found in the Tonearm scale chapter on page 12 Fig.: Remove protective cover from tonearm scale Fig.: Tonearm scale open installation... -
Page 8: Assembly Step 6: Attaching The Anti-Skating Weight
At the output of the cinch sockets Analog Line Output, the T700 outputs a stereo audio signal at line level. This means that the T700 can be connected directly to any analog input of an amplifier, receiver or an Audiobar from Revox without the need for a separate phono preamplifier. -
Page 9: Operation
If you are still a fan of turntable support, you can of course use one. For this you should note that the height setting of the tonearm may then have to be adjusted to the higher position of the record. How this is done is described in the chapter Adjusting the tone arm height on page 11. STUDIOMASTER T700 Turntable... -
Page 10: Cleaning The Record
If there is no record playback, the tonearm should always be "parked" in its holder. A needle that remains in the groove for days or weeks can damage the needle bearing and thus reduce the tracking ability. The lead-out groove is near the center of the record STUDIOMASTER T700 Turntable... -
Page 11: Basic Settings And Maintenance
DIP switch, i.e. the DIP switch is in the ON position, the printed value is the terminating resistor. In the case of the Ortofon Quintet Bronze pick-up system, Revox decided on a value of 100 Ω - see Figure 2. -
Page 12: Sensitivity (Mc Sensitivity)
Target speed setting The tonearm of the STUDIOMASTER T700 turntable is set in the factory to the pre-assembled Ortofon Quintet Bronze pick-up system. This includes the parallel alignment of the tonearm to the turntable, the setting to the two angle-neutral fixed points and the azimuth alignment of the pick-up. -
Page 13: Replacing The Pick-Up
Quintet Bronze pick-up system, the azimuth can be very accurately determined with the help of a small make-up mirror that is placed under the pick-up. Viewed from the front, every small difference / misalignment in the horizontal plane can then be clearly identified. Carefully tighten the small screw again by hand after the adjustment process. STUDIOMASTER T700 Turntable... -
Page 14: Tonearm Scale
Tonearm scale Revox delivers the T700 with a digital tonearm scale in the accessory box for precise determination of the tracking force. This allows you to set the tracking force recommended by the manufacturer of the cartridge to an accuracy of 0.01 g. A test weight of 5.0 g is included in the accessories box for checking the measurement accuracy. -
Page 15: Technical Data T700
0.21 kg sub-platter aluminum 5,0 g (anti-skating weight 9 mm) 1,8 g (anti-skating weight 6 mm) - alternative Subject to errors and technical changes. Copies and prints, including extracts, require the written approval of Revox Deutschland GmbH. STUDIOMASTER T700 Turntable... - Page 16 Österreich / Austria Revox Handels GmbH Josef-Pirchl-Strasse 38, AT 6370 Kitzbühel Tel +43 535 666 299, Fax +43 535 666 299 4 info@revox.at www.revox.at Bedienungsanleitung Active 04 / Artikel-Nr 10.18.1504 E&EO Copyright by Revox Deutschland GmbH, Germany STUDIOMASTER T700 Turntable...
