Summary of Contents for holzkraft HB 1401
- Page 1 Assembly instructions Workbench HB 1401 HB 1901...
- Page 2 Assembly Instructions HB 1401/ HB 1901 Version 2.02 Edition 17.09.2019 Technical Data Unit HB 1401 HB 1901 Dimensions [LxBxH] approx. 1340x650x850 1800x760x850 Weight approx. Length of workspace without vice jaws 1340 1840 Width/depth of workspace without vice jaws Working height...
- Page 3 Assembly Instructions HB 1401/ HB 1901 Version 2.02 Edition 17.09.2019 Illustrations Illustration 1 Illustration 2 Illustration 3 Illustration 4 llustration 5...
- Page 4 Assembly Instructions HB 1401/ HB 1901 Version 2.02 Edition 17.09.2019 Assembly Instructions 1. Place Base (5), Top Rail Support (4), Back Leg (3) and Front Leg with Bench Dog Storage Holes (2) with dowel holes facing inward als shown (Ill. 1). Attach the Base and Top Rail Support to the Front Leg with Bench Dog Holes (2) and Back Leg (3) using four Dowels (18) and Glue (20) for each (see Ill.1).
