Summary of Contents for XAG GNSS RTK Fix Station
- Page 1 XAG GNSS RTK Fix Station Installation Guide Version 1.0...
- Page 3 To Users Dear user, thank you for choosing XAG products. For safety reasons and the best experience possible, XAG recommends that you read through the Installation Guide and Disclaimer in this document before attempting to use the XRTK4 Fix Station.
-
Page 4: Table Of Contents
Contents List of Items Overview - XAG GNSS RTK Fix Station Site Selection - XAG GNSS RTK Fix Station Installation - Station Bracket Installation - Solar Panel Installation - XRTK (Data SIM Required) Installation - Wiring Guides RTK Module Status Indicator... -
Page 5: List Of Items
List of Items Before unpacking and using the product, please carefully check if it contains all the items listed below. Please contact XAG™ or your dealer if there are any missing items. Station Bracket × 1 Support Rod ×1 Solar Panel (With Battery) -
Page 6: Overview - Xag Gnss Rtk Fix Station
Overview - XAG GNSS RTK Fix Station XAG XRTK (Beidou) Fixed Station is comprised of the RTK Positioning Module, Solar Panel and Station Bracket XRTK Module XRTK Module S/N Tightening Ring Support Rod Solar Panel Solar Panel Battery Adjustable Mount... -
Page 7: Site Selection - Xag Gnss Rtk Fix Station
Site Selection - XAG GNSS RTK Fix Station To ensure the continuous operation of the XAG GNSS RTK Fix Station, Site selection must follow the following principles: The XAG GNSS RTK Fix Station as the horizontal plane, there are no obstructions higher than 15°... -
Page 8: Installation - Station Bracket
Method 2 – Direct Drilling & Installation Where conditions permit, you may choose to drill and install the 4 fixing pieces directly on the ground at a suitable position, then secure the Station Bracket with the 4 fixtures and 8 expansion bolts. XAG AUSTRALIA... -
Page 9: Installation - Solar Panel
Refer to the figure below to align the 4 solar panels with the reserved screw holes on the Adjustable mount of the Station bracket, then tighten the screws to secure each Solar Panel (2 screws for each panel). Once the Solar Panel is secured, adjust the solar panels to a deflection angle of 45°. 45 ° XAG AUSTRALIA... -
Page 10: Installation - Xrtk (Data Sim Required)
Position the Support Rod vertically and align with the Station Bracket, then secure and tighten the screws (4) Align and insert the XRTK Module vertically on the top of the support rod, and rotate the tightening ring CCW (Counter-Clockwise) to firmly secure the connection of the support rod. XAG AUSTRALIA... -
Page 11: Installation - Wiring Guides
During the installation, check and ensure the power cords of the solar panel and the support rod are properly and connected. Unsecured or Improper Connection may result in water penetration resulting in rusting or damage to the interface. XAG AUSTRALIA... -
Page 12: Rtk Module Status Indicator
8 meters. Low Voltage: The buzzer sends an alert when the battery voltage is lower than 12.5V. Immediate ▸ charging required; when the voltage is higher than 13.5V, the red light will return to Normal and the alert stops XAG AUSTRALIA... -
Page 13: Fix Station Activation & Firmware Update
Fix Station is ready to be used (Generally within 1 Business Day). • Firmware Update Once the XAG GNSS RTK Fix Station is activated and connected to the Cloud Network, the firmware update is autonomous. During the update process, service may be temporarily interrupted (The RTK Module Status Indicator F1 &... -
Page 14: Maintenance
Clean the surface of the solar panel every month, then check and tighten loose screws and ensure Fix Station was not moved. Do not move the Fix Station after installation. If you need to change it, please contact XAG Technical support. -
Page 15: Technical Specifications
1 x Bluetooth 3 x GPRS Communication Modules Hardware Interface 1 x Power Supply Interface 3 x SIM card slot Solar Panel: Solar Panel 10400mAh Battery Capacity 14.4V Output Voltage 18~22V ＜ Charging Voltage ＞ 7h Power Consumption XAG AUSTRALIA... -
Page 16: Disclaimer
This does not mean that the contents of this Disclaimer are necessarily invalid. 8. To the extent permitted by law, XAG has the final right to interpret and modify the above terms. XAG has the right to update, modify, or terminate these terms through its official website, the “Product Manual/Operation Manual”, online APP and other means without prior notice. - Page 17 The copyright of all information in this user manual (including but not limited to any text description, illustrations, photos, methods, processes, etc.) belongs to XAG Australia and is protected by copyright law. No individual or organization may imitate, extract, translate, distribute or reproduce or quote all the contents of this manual...
