ML651B
Digital Media Player
V:0933-0316-10
introduction
DISPLAY
VOLUME
Press to adjust the
volume.
SKIP/SEARCH
Press to skip between
tracks. Press and hold
to search through an
individual track.
MENU
Press to access the
sub-menu of the current
mode.
Press and hold to return
to the main menu.
PLAY/PAUSE
Press to play or pause
tracks.
Loading Files
1 Connect the unit to a computer (Windows,
Apple, or Linux) using the Mini-USB con-
nection and the included USB cable.
2 Once connected, the unit will show up on the
connected computer as if it were a connected
USB thumb drive, external hard drive, or
memory card.
3 Drag and drop the desired audio, video, photo,
or ebook files into the unit's drive location on
the connected computer.
File Compatibility:
MUSiC: MP3, WMA
ViDEO: MTV
VOiCE: WAV
PHOTOS: JPEG, BMP
EBOOK: TXT
4 After the files are loaded onto the unit, right-
click on the drive and eject it from the com-
puter, then disconnect the USB cable.
1 Power the digital media player on.
2 Navigate to the Photo icon on the main menu
and press the PLAY button.
3 Navigate through the file browser using the
VOLUME and SKiP/SEARCH buttons, and
press the PLAY button to select a JPEG or
BMP photo file.
4 Press the VOLUME and SKiP/SEARCH but-
tons to cycle through all of the photos in the
current directory.
5 Press and hold the MEnU button to return to
the Main Menu.
STEREO HEADPHONE
JACK
RESET
Press using a paperclip
or like object to reset the
MP3 player.
MINI-USB PORT
ON/OFF
Adjust to power the MP3
player off or on.
RETURN
Press to return to the
previous menu.
Music
1 Power the digital media player on.
2 Navigate to the Music icon on the main menu
and press the PLAY button.
3 Press the PLAY button to begin playing music
from your digital media player.
Record
1 Power the digital media player on.
2 Navigate to the Record icon on the main menu
and press the PLAY button.
3 The digital media player will begin recording
automatically.
4 Press the PLAY/PAUSE button to stop or
resume recording.
5 Press the RETURn button to return to the
Main Menu.
Charging
1 Connect the digital media player to a
computer to charge it's internal battery.
Play Options
While in Music mode, press the MEnU button to
access the Music sub-menu.
Repeat
• No Repeat
• Repeat One
• Repeat All
• Random All
• Folder Normal
• Folder Repeat
• Folder Random
Equalizer
• Normal
• Pop
• Rock
• Classic
• Jazz
• Bass
File
Use to access a file view of the music stored on
the MP3 player.
Voice
1 Power the digital media player on.
2 Navigate to the Voice icon on the main menu
and press the PLAY button.
3 Press the SKiP/SEARCH buttons to cycle
through the available recordings.
4 Press the PLAY button to begin playing the
selected recording.
5 Press the RETURn button to return to the
Main Menu.
