- Page 1 Built-in ovens KM 20 KMS 20 Instruction booklet...
-
Page 2: Important Safety Information
Important Safety Information It is of the utmost importance that this booklet be kept with the appliance, so that it can be consulted for any reason.Should the appliance be sold or transferred to another owner, please ensure that the booklet goes with it, so that the new user is able to become familiar with its operation and the relevant warnings. -
Page 3: Table Of Contents
Contents Instructions for the User Defrosting Important Safety Information Tips on using the Oven Description of the Appliance Grilling Operation Cleaning and maintenance Electronic Programmer Service and spare parts Before the First Use The Guarantee Using the Oven Hints and Tips Instructions for the Installer Oven fan protection filter The Conventional Oven... -
Page 4: Operation
Operation Oven function control knob The oven function control knob can be set on the following symbols and functions: Oven light Upper and lower heating elements Upper heating element Lower heating element Simple grill element Double grill element Fan grill element Convection heating element Defrosting Thermostat Control Knob... -
Page 5: Electronic Programmer
Electronic Programmer Child safety Minute minder function Symbol Cookpot symbol Cooking duration End of cooking time Auto Manual function symbol Cookpot symbol - This will be displayed when a program is in operation. Time Auto symbol - This will be displayed setting when the oven has been programmed for automatic operation. - Page 6 Manual Function Press button to set the oven for manual function. To set the Timer to switch off only This is useful if you want to begin cooking immediately but have the oven switch off automatically. 1. Set the oven function control knob and the thermostat control knob on the required settings.
- Page 7 Special functions Child Safety Function To avoid children switching on the oven, it is possible to lock the oven controls. To lock the oven controls, the oven must be switched off. To lock the oven controls: 1. Press buttons at the same time and keep them pressed for about 8 seconds.
-
Page 8: Before The First Use
Before the First Use Remove all packaging, both inside and 2. Switch the oven function control knob to outside the oven, before using the appliance. fan cooking Before first use, the oven should be heated 3. Set the thermostat control knob to MAX. without food. -
Page 9: Hints And Tips
Hints and Tips The effects of dishes Condensation and steam When food is heated it produces steam in on cooking results the same way as a boiling kettle. The oven Dishes and tins vary in their thickness, vents allow some of this steam to escape. conductivity, colour, etc. -
Page 10: The Conventional Oven
The Conventional Oven Things to note When using this setting, heat comes from both the top and bottom elements. This • The thermostat control light will remain allows you to cook on a single level and is on until the correct temperature is particularly suitable for dishes which require reached. - Page 11 Cooking Chart The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10 °C to suit individual preferences and requirements. NOTE: Shelf positions are counted from bottom of the oven. Food Shelf Cooking...
-
Page 12: Using The Fan Oven
Using the Fan Oven Even Heating for Baking The air inside the oven is heated by the element around the fan situated behind the The fan oven has uniform heating on all back panel. The fan circulates hot air to runner positions. -
Page 13: Tips On Using The Oven
Tips on using the Oven Runner positions are not critical, but make sure the shelves are evenly spread. When cooking more than one dish in the fan oven, place dishes centrally on the shelves rather than several dishes on one shelf. - Page 14 Cooking Chart This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements. Food Shelf Cooking Position...
-
Page 15: Grilling
Grilling Grilling must be carried out with the oven How to Use the Inner Grill door closed. The grill pan handles must be Element removed from the pan. The inner grill provides quick direct heat to How to Use the Grill the central area of the grill pan. - Page 16 Cooking Chart - Grilling FOOD Grill and Inner Grill Element Thermal Grill Time Temp Temp Time (Mins) (°C) (°C) (Mins per side) Bacon Rashers 8-12 Beefburgers 6-10 10-15 Chicken Joints 10-15 35-45 Chops- Lamb 7-10 20-25 - Pork 10-15 25-35 Fish- Whole Trout /Herring 8-12...
-
Page 17: Cleaning And Maintenance
Cleaning and maintenance Changing the oven light Ensure that the appliance is disconnected from the electricity supply before embarking bulb upon any maintenance operation. Disconnect the appliance from the electricity General cleaning supply, press and unscrew the glass protection sheath; The oven should be cleaned when it is cold. -
Page 18: Instructions For The Installer
Cleaning the oven door It is advisable to remove the door from the oven in order to clean thoroughly; to do this follow this proce- dure: open it completely; lift the two levers positioned on the hinges and rotate them completely towards the door; close the door until it touches the two levers;... -
Page 19: Electrical Connection
Electrical connection Only qualified personnel should install the appliance (place in cabinet and make electrical connection). Every operation must be carried out with appliance disconnected from the electricity supply; when this is not possible the maximum care is required when working on the appliance. Before proceeding to the connection of the The manufacturers decline all oven make sure that:... -
Page 20: Building In
Building in Fixing the oven into kitchen Fitting dimensions of oven (Fig. 1) cabinets Any cabinet containing an electrical appliance must have the charcteristics held suitable for this purpose to permit the appliance to operate to its best potential. Protection against any possible contact with the electrical parts must be assured through the correct installation of the appliance into the cabinet, in accordance with the current... - Page 21 Fitting and assembly Insert the appliance into the cabinet space; open the oven door and fix the body of the oven to the cabinet using four wood screws of a suitable size for the holes already made around the oven (see figs 4 and 5).
-
Page 22: Service And Spare Parts
The Guarantee Your new appliance is covered by a guarantee. You will find the Guarantee certificate attached to this booklet. If the certificate is not evident, contact your supplier quoting the date of purchase, the model and the serial number of the appliance, which are printed on the identification plate of the appliance.
