Summary of Contents for Coldex TD35 VS
- Page 1 TD35 VS - TD50 VS Compressor for R134a 12/24V DC Technical specifications PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC) C/so Umberto,58 - Tel (+39) 0161 42 44 52 Fax (+39) 0161 42 40 92 www.procold.it info@proco ld.it...
- Page 2 2.3.Attached Controller, Few attachment, Easy to use. 2.4.Rotary speed at 2000 rpm 3500rpm adjustable. 3 Type Hermetic reciprocating refrigeration compressor . 4 Technical Data Table 1 Specification Compressor Model COLDEX TD35 VS COLDEX TD50 VS Displacement, cm Applications Rotation, rpm 2.000 2.500 3.000 3.500...
- Page 3 5 Controller 5.1 Wiring TD35 VS TD50 VS The Compressors are equipped with a brushless dire ct current motor which is controlled by an Attached Controller, the wiring is shown as following drawing: 1 Battery 2 Fuse 3 Main Switch (optional)
- Page 4 5.2 The Technical Specification of controller is shown: Table 2 Controller Data TD35 VS - TD50 VS Compressor Model Model 12/24V DC 116mm × 103mm × 50mm Dimensions Output Power W 20W~ 140W Static Consumption Controller Power W Max. Ambient Temp.
- Page 5 17 VDC The controll er consider it is wo rking in a 24 V DC system. If a 220K resistor is connected between C - P , the operating voltage range could be TD35 VS TD50 VS 31.5V, this means...
- Page 6 7 Transportation and storage 7.1 Please keep perpendicularity, can not be turn ed upside down and avoid vibration and shocks during transportation. 7.2 Please ensure to store the compressors under dr y and well-ventilated condition to avoid the package getting wet. 7.3 More than two layer package of compressors is no t available, and avoid any rolling during loading and unloading.
- Page 7 DIMENSIONS COMPRESSOR COLDEX TD35 VS - TD50 VS COMPRESSOR CONTROLLER COLDEX 12-24 Volt DC RoHS SUCTION Ø 6.20 PROCESS Ø 6.20 DISCHARGE Ø 5.15 PROCOLD S.r.l. - ITALY- 13043 CIGLIANO (VC) C/so Umberto,58 - Tel (+39) 0161 42 44 52 Fax (+39) 0161 42 40 92 Rev.
