07-DEC-2009
2009-4012
DOMESTIC Chlorine or bromine Generating Device
Installation and Operation Manual
KEEP OUT OF REACH OF CHILDREN
MODEL DIG60 REGISTRATION NUMBER 28034 PEST CONTROL PRODUCTS ACT
Maximum output of hypochlorous or hypobromous acid equivalent to 0.88 kg of free available chlorine per day
One DIG60 Unit Can Treat a Maximum Of 190,000 Litres Of Swimming Pool Water
READ THE LABEL AND THIS MANUAL BEFORE INSTALLING & OPERATING
NOTICE TO USER: This pest control product is to be used only in accordance with
the directions on the label. It is an offence under the Pest Control Product Act to
use this product in a way that is inconsistent with the directions on the label. The
user assumes the risk to persons or property that arises from any such use of this
product.
Fox Pool Canada Limited, 5430 Harvester Road, Burlington, ON. L7L 5N5
(FOX DIG6 0 Residential English Final Jan 2 0 05 )
Fox
GALAXY
Model
Digital 60
by FOX POOL CANADA LIMITED
Controls Bacteria And Algae In Swimming Pool Waters
(For Indoor or Outdoor Use)
RETAIN MANUAL FOR FUTURE REFERENCE
C
IMPORTANT
Phone: 905-333-1654
NSF50

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALAXY Digital 60 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fox GALAXY Digital 60

  • Page 1 Fox Pool Canada Limited, 5430 Harvester Road, Burlington, ON. L7L 5N5 Phone: 905-333-1654 (FOX DIG6 0 Residential English Final Jan 2 0 05 )
  • Page 2: Fox Galaxy

    Section 1a – GENERAL PRODUCT INFORMATION Fox Galaxy Model Digital 60 by FOX POOL CANADA LIMITED Record The Following Information Installer: _____________________________Date of Installation: __________________________ Control Unit Control Unit Model Number: DIG60______________ Serial Number: # ____________________________ Cell Cell Model: # RC13 Serial Number: # ____________________________ Customer Assistance…...
  • Page 3: Important Safety Instructions

    115/230VAC, 50/60 Hz Models (fixed wiring) A wire connector is provided on your Fox Galaxy Model Digital 60 to connect a minimum 8.4 mm² (No. 8 AWG) in the U.S.A. and 6.3mm² (No.6 AWG) in Canada solid copper bonding conductor between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe or conduit within 1.5 m (5 ft.) of the unit.
  • Page 4: Table Of Contents

    Section 1c – GENERAL PRODUCT INFORMATION Table of Contents Fox Galaxy Model Digital 60 by FOX POOL CANADA LIMITED Section 1 GENERAL INFORMATION Product Information and Contact Numbers ............1 Important Safety Instructions ................... 2 Table of Contents ....................... 3 Section 2 INSTALLATION Main Components ......................
  • Page 5: Section 2 Installation

    Section 2a – INSTALLATION Main Components Tri-Sensor Assembly DIG 60 = RC13Cell union Flow In Flow Out to pool Control Box Flow Bypass Manifold Assembly CONTROL BOX converts incoming ELECTROLYTIC CELL TRI-SENSOR ASSEMBLY AC power to a Low Voltage DC current, receives Low Voltage DC current from ensures that adequate flow, which energizes the Cell(s).
  • Page 6: Control Box Connections

    For control of your main circulation pump (single or two speed) through the Fox Galaxy Model Digital 60’s Internal Relay, cut and strip the pre-wired Line In wires, and jump #1 to #3 and #2 to #4 (Gr/Yel can be discarded). Route a new set of Pump AC Line IN wires from the circuit breake r/electrical panel into #3, #4 and Pump Ground Lug.
  • Page 7: Cell And Manifold Installation

    Cell and Manifold Installation Your Fox Galaxy System is adaptable for use with the 13 blade (RC13) cell. The manifold must be located as the last accessory in the POOL RETURN LINE only. For special plumbing configurations, please contact your representative for assistance in locating the manifold.
  • Page 8: Section 3 Operation

    Key Features The Fox Galaxy Model Digital 60 display will show the SANITIZER OUTPUT LEVEL (in percent %) and whether the system is in BOOST or SUPER-BOOST Mode on the first line of the two line alphanumeric display. The second line will display the current TIME in either 12 or 24-hr mode, the TEMPERATURE in either Fahrenheit or Celsius, whether the cell is powered or not, shown as ON or OFF and Polarity Direction, shown as a “.”...
  • Page 9 The MENU Button allows you to enter the programming and monitoring functions. Use UP/DOWN ARROW and SELECT to scroll through the Main menu and Sub-menu: Main Menu 1.0 Test Fox Galaxy Model Digital 60 2.0 Owner Options 3.0 Maintenance Menu 4.0 Installer Menu...
  • Page 10 3.7 Calibrate Salt: allows you to calibrate the salt display. Contact the factory for calibration solution 3.8 Replace Cell: Only used when replacing cells. May be used to zero the amp -hour counter. Consult FOX Pool Canada Limited for details 3.9 Back –...
  • Page 11: Pool Water Preparation

    Start Up Procedures Keep the Output Setting on your Fox Galaxy Model Digital 60 on 0% (OFF) until you get your water clear, blue and properly balanced. After balancing your water chemistry according to the Water Chemistry Parameters shown on page 10, add the proper amount of salt (see Salt Requirement Chart above) and circulate 24-hours prior to starting your Fox Galaxy Model Digital 60.
  • Page 12: Monitoring And Maintenance

    BROMINE RESIDUAL: Along with the normal Salt level, add 0.45 kg (1 lb) Sodium Bromide (NaBr) per 7500 L (2000 gallons) of water. Your Fox Galaxy Model Digital 60 will now generate Bromine to sanitize your pool. Maintain your bro mine level by checking your salt level.
  • Page 13: Section 4 Service And Maintenance

    Section 4a –SERVICE and MAINTENANCE CONTROL BOX There are very few serviceable parts on the Fox Galaxy Model Digital 60 Control Box except the fuses. For any other problems with the Control Box, please contact your representative or Authorized Dealer/Service Center.
  • Page 14: Cell

    VISUAL CELL INSPECTION: The titanium Cell blades, seen inside the Cell body, should be straight and clear of any debris between the blades. Your Fox Galaxy Model Digital 60 is designed to automatically self-clean scale build -up within the Cell. However, imbalanced water chemistry and certain conditions can cause a heavier scale build up that exceeds the self-cleaning capability and would need to be cleaned manually by the method described below.
  • Page 15: Parts Explosion

    Section 4c –SERVICE and MAINTENANCE Parts Explosion Manifold Assembly: Manifold Union w/Strainer: (#941) (#19065) TRI-SENSOR Union Nut Union O-Ring (#19014) Strainer (#19064) CELL w/ UNIONS MANIFOLD UNION w/Strainer MANIFOLD BASE w/Check Valve Electrolytic Cell: (Cell Unions and Cord ordered separately) 12 ft.
  • Page 16: Section 5 Troubleshooting

    Section 5a – TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE SOLUTION Insufficient Sanitizer Production. A) The test kit reagents or test strips are old or expired. A) Retest with new Reagents or Strips. B) The unit is set too low in relation to sanitizer demand. B) Increase the Sanitizer % output.
  • Page 17 5430 Harvester Road Burlington, Ontario L7L 5N5 Phone: 905-333-1654 REGISTRATION NO. 28034 PEST CONTROL PRODUCTS ACT FOX GALAXY MODEL DIGITAL 60 Chlorine or bromine Generating Device One DIG60 unit can treat a maximum of 190,000 Liters of swimming pool water.
  • Page 18 60 REGISTRATION NUMBER 28034, PEST CONTROL PRODUCTS ACT. This cell must only be used on this model of chlorine or bromine generating device. Read the Label and the Installation and Operation Manual of the chlorine or bromine generating device FOX GALAXY Model DIGITAL 60 before using.
  • Page 19 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
