Eco Tech DW 45 Manual For Use And Maintenance

Professional double-wire layering machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INTERRAFILO PROFESSIONALE DOPPIO CAVO
PROFESSIONAL DOUBLE-WIRE LAYERING MACHINE
MACHINE ENFOUISSEUSE DOUBLE CÂBLE PROFESSIONNELLE
PROFESSIONELLE KABELVERLEGUNGSMASCHINE MIT DOPPELTEM KABEL
ENTERRADOR DE CABLES PROFESIONAL DOBLE CABLE
PROFESSIONELL KABELLÄGGARE FÖR DUBBEL KABEL
KAAPELINLASKUKONE KAHDELLE KAAPELILLE AMMATTIKÄYTTÖÖN
PROFESJONALNA MASZYNA DO JEDNOCZESNEGO UKŁADANIA DWÓCH KABLI PODZIEMNYCH
PROFESSIONAALNE TOPELTKAABLI PAIGALDUSMASIN
MODELLO - MODEL - MODÉLE - MODEL – MODELO - MODELL - MALLI - MODEL - MUDEL DW45
•
MANUALE DI USO E MANUTENZIONE
•
MANUAL FOR USE AND MAINTENANCE
•
MANUEL D'UTILISATION ET DE MAINTENANCE
•
HANDBUCH ZUR VERWENDUNG UND WARTUNG
•
MANUAL DE USO Y MANTENIMIENTO
•
HANDBOK FÖR ANVÄNDNING OCH UNDERHÅLL
•
KÄYTTÖ- JA HUOLTO-OHJE
•
INSTRUKCJA OBSŁUGI I KONSERWACJI
•
HOOLDUS- JA PAIGALDUSJUHEND
Revision
0
Date
24/09/2019
Description
Issue
IT ‐ EN ‐ FR ‐ DE ‐ ES ‐ SV ‐ FI – PL ‐ EE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DW 45 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eco Tech DW 45

  • Page 1 INTERRAFILO PROFESSIONALE DOPPIO CAVO PROFESSIONAL DOUBLE-WIRE LAYERING MACHINE MACHINE ENFOUISSEUSE DOUBLE CÂBLE PROFESSIONNELLE PROFESSIONELLE KABELVERLEGUNGSMASCHINE MIT DOPPELTEM KABEL ENTERRADOR DE CABLES PROFESIONAL DOBLE CABLE PROFESSIONELL KABELLÄGGARE FÖR DUBBEL KABEL KAAPELINLASKUKONE KAHDELLE KAAPELILLE AMMATTIKÄYTTÖÖN PROFESJONALNA MASZYNA DO JEDNOCZESNEGO UKŁADANIA DWÓCH KABLI PODZIEMNYCH PROFESSIONAALNE TOPELTKAABLI PAIGALDUSMASIN MODELLO - MODEL - MODÉLE - MODEL –...
  • Page 2 ENGLISH IMPORTANT! IMPORTANT! This machine has been manufactured according to CE standards and is certified by the related marking This machine has been manufactured according to CE standards and is certified by the related marking Throughout this manual and on the machine are given indications and captions Throughout this manual and on the machine are given indications and captions followed by the danger sign below that indicate a potential danger.
  • Page 3 ENGLISH The machine is equipped with a rotary cutting component. Never get the hands and feet near it!!! Dangers list label applied on the machine, clearly visible WARNING!!! The machine is equipped with an extremely powerful cutting component, therefore keep the hands and feet away from it and never work on the machine while the engine is running.

  • Page 4: Using The Machine

    ENGLISH DW 45 – PROFESSIONAL TWO‐CABLE LAYER Dear Customer, thank you for having chosen ECOTECH Italy; we trust your new machine matches fully our needs. To optimize the use of the cable layer and for an effective maintenance over time, please read all signs and recommendations described in this manual, which must be preserved and must always accompany the machine.
  • Page 5 ENGLISH Fig.1 1. Fuel tank cap 2. Engine starting contactors 3. Gas lever 4. Cutter adjuster 5. Forward motion adjuster 6. Cutter start lever 7. Handlebar oscillation control lever 8. Oscillation control adjuster 9. Forward motion lever 10. Cable winder 11.
  • Page 6 ENGLISH INSTRUCTIONS FOR USE Prior to starting the engine and beginning to work, make sure to perform the checks listed below: • Check the integrity of the cable outlet spout on the cable laying blade (Fig. 2). Check in particular the integrity of the hose inside of the blade. If damages are found, replace it. Also check that there are no cuts along the entire edge of the blade spout;...
  • Page 7 ENGLISH THE MACHINE MUST BE RUN-IN! DURING THE FIRST OPERATION HOUR THE BELTS WILL SETTLE. IN! DURING THE FIRST OPERATION HOUR THE BELTS WILL SETTLE. MAKE SURE THE STRETCHING SPRINGS WORK PROPERLY (fig.1 n.4/n.5). ASSEMBLING OR REPLACING THE BLADE The blade of the cable layer consists of various parts to be assembled be The blade of the cable layer consists of various parts to be assembled before proceeding to fasten it to the machine.

  • Page 8: Speed Control

    ENGLISH Fig.6 Fig.7 ASSEMBLING OR REPLACING THE CUTTER Make sure to have at hand a 6 mm spanner. To assemble or replace the cutter, unscrew the retaining screw of the head (fig.8-A), remove the worn cutter if already fitted to the head (fig.8-B) and insert the new cutter. Tighten completely the retaining screw.
  • Page 9 ENGLISH of the transmission box. This operation can severely damage the mechanical part of the transmission. The forward lever (fig.1 n.9) must ALWAYS be pulled completely, i.e. until it touches the handle. HOW TO ADJUST THE HEIGHT OF THE HANDLEBAR The handlebar of the machine can be adjusted on five heights.
  • Page 10 ENGLISH HOW TO USE THE TWO‐CABLE BLADE Laying two cables at the same time is required when it is necessary to go around trees, flowerbeds, etc. (islands) away from the outer perimeter of the workspace. Proceed as follows (check the sequence given in Fig. 15): ADJUSTING THE BLADE DEPENDING ON THE CABLE THICKNESS The machine is adjusted for 4 mm cables.
  • Page 11 ENGLISH START START START START START START START STOP Fig. 15...

  • Page 12: Troubleshooting

    ENGLISH END OF THE WORKS Once the works are finished, switch off the engine, move the gas lever (fig.1 n.3) to STOP (or, if the engine is fitted with a stop switch, use it after the engine rpm went idle), and, if provided, close the fuel tap. After the cable laying has finished, it is essential to clean and grease the head of the cutter (check the following paragraph).
  • Page 13 ENGLISH Fig. 16...

  • Page 14: Maintenance Of The Machine

    ENGLISH D. The machine is not working properly: make sure • the cutter is not too worn. • the cutter is not broken or has been fitted. • the air filter (see the engine booklet) is not too clogged causing a considerable engine power decrease.
  • Page 15 ENGLISH TECHNICAL DATA ENGINE HONDA GCVx 145 4- HONDA GXV 160 4-stroke stroke spark ignition spark ignition engines engines 5 STAGE POWER 3.1 kW / 3600 rpm 3.2 kW / 3600 rpm START-UP recoil start recoil start TRANSMISSION mechanical gearbox with mechanical gearbox with oil bath gears oil bath gears...

  • Page 16: Declaration Of Conformity

    DECLARATION OF CONFORMITY (Annex II-A Dir. 2006/42/EC) THE MANUFACTURER ECOTECH Italy Via Copernico, 85 47122 Forlì FC - Italy declares, under its exclusive responsibility that the product: Cable Layer DW 45 Type: DW 45 Year of manufacture: 2019 Serial number: 000001 - 999999 Max.
