9. Pitching Angle Adjustment
120°
Adjust to desired location or tilt
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your dealer if you have any questions.
11
+3°
-3°
+15°
-15°
INSTALLATION INSTRUCTIONS
Full-motion Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM
LISTED WEIGHT CAPACITY. SERIOUS
INJURY OR PROPERTY DAMAGE MAY
OCCUR!
400x200/300x300
400x400/600x400
45kg
(99lbs)
60
"
MAX
MAX
ISSUED: OCT. 2011
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lumi LPA19-444
Summary of Contents for Lumi LPA19-444
- Page 1 INSTALLATION INSTRUCTIONS Full-motion Wall Mount 9. Pitching Angle Adjustment +3° -3° 120° +15° -15° CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY Adjust to desired location or tilt OCCUR! 45kg Maintenance (99lbs) " 400x200/300x300 •...
-
Page 2: Component Checklist
Component Checklist NOTE: Read the entire instruction manual before you start installation and assembly. IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, telephone your local distributor for a replacement. WARNING •... - Page 3 2b. Solid Brick and Concrete Block Mounting: 1. Removing the Decorative Covers 60mm/2.4" ø 10mm ø 3/8" 2a. Wood Stud Wall Mounting: 55mm/2.2" ø 4.5mm ø 3/16" Drill pilot holes √ Drill pilot holes √ Screw the wall mount onto the wall with the up arrow of the plate upward Screw the wall...
- Page 4 3. Installing Decorative Covers 5. Installing Adapter Bracket 5-1 For Flat Back Screen 4. Removing the lower thumbscrew. Tighten all screws but do not over tighten.
- Page 5 6. Hook the TV onto the Wall Mount 5-2 For Recessed Back Screen or to Access A/V Inputs Two qualified persons are required Loosen the upper thumbscrew spacing 4mm to adapter bracket. Hook the TV onto the wall mount · Position the adapter bracket as close as possible to the middle of the screen.
-
Page 6: Cable Management
7. Cable Management 8. Adjusting Wall Mount Head • Remove cable covers as required, Connect cables to your TV and route along the arms. • Re-attach the cable covers to hold the cables in place . Depending on the weight of the display, it is necessary to slightly loosen or tighten the adjustment screw using an Allen key.
