- Page 1 Network Digital Video Recorder Hardware User’s Manual...
-
Page 3: Copyright Notice
Trademarks All other product names mentioned in this documentation are for identification purposes only and remain the sole property of their respective owners. Copyright @ 2005 by Giantec Inc. All Right Reserved. March 2005, Version 3.1... - Page 5 Giantec Internet Services Customer satisfaction is our number one concern. To ensure that customers receive the full benefit of our products, Giantec Internet Services has been set up to provide technical support, driver updates, product information, and user’s manual updates. The following...
-
Page 7: Table Of Contents
Table of Contents CHAPTER I INTRODUCTION Limited Warranty Function Introduction Features CHAPTER II PACKAGE CHAPTER III INSTALLATION Indicator Cable Connection Connect VGA Monitor ... 5 Connect Camera Cable to BNC Connector ... 6 Connect to LAN Connector: Plug RJ-45 Connector to LAN Port... 6 Connect to Printer Port (Option) ... - Page 8 P/T/Z Setting ...18 Pin Assignment of COM2 ...18 Cable Connection...18 Jumper 3 Setting of COM2...18 CHAPTER V CMOS SETTING Introduction Setup Pages Standard CMOS Features ...20 Advanced BIOS Features...21 Advanced Chipset Features...22 Integrated Peripherals ...24 Power Management Setup ...25 PnP / PCI Configuration ...26 PC Health Status...26 Frequency / Voltage Control ...27 Load Optimized Defaults ...27...
-
Page 9: Chapter Iintroduction
Moreover, to be free from defects in materials and workmanship under normal use and service for all parts one year after the original purchase date. During this period Giantec Inc. will replace parts at no charge, however, labor cost will be laid after one year. Please contact your dealer / distributor for details. -
Page 10: Features
Network DVR Hardware User’s Manual Features The tracer2000 comes with the following hardware devices: Control Panel with IR Receiver One 10/100Mbps TX Fast Ethernet with RJ-45 Connector One RS232 and one RS232/422/485 Selectable Interface One VGA (DB-15) Connector One Speaker Out One Microphone In Two USB Ports (USB 1.1 Interface) -
Page 11: Chapter Ii Package
Battery (AAA) x 2 tracer2000 Software User’s Manual tracer2000 Hardware User’s Manual Installation CD-ROM Please keep the packaging materials. You may need them for the use of further service. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Page 3 of 31... -
Page 12: Chapter Iii Installation
Network DVR Hardware User’s Manual Chapter III Installation Power/ Playback Display Alarm Menu Confirm Removable Air LEFT RIGHT Removable Air Filter Bracket Filter Bracket DOWN ※ Remove and clean up Air Filters monthly is essential. Front Panel View MIC and... -
Page 13: Indicator
Following is the basic device must be prepared before to start installation complete system. tracer2000 CCD Cameras VGA Monitor Please follow the procedure to connect the cable. Connect VGA Monitor Version 3.1 tracer2000 Network DVR Hardware User’s Manual H.D.D Page 5 of 31... -
Page 14: Connect Camera Cable To Bnc Connector
Connect Camera Cable to BNC Connector Connect to LAN Connector: Plug RJ-45 Connector to LAN Port Insert RJ-45 cable to network LAN socket on the rear of tracer2000. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Page 6 of 31... -
Page 15: Connect To Printer Port (Option)
Network DVR Hardware User’s Manual Connect to Printer Port (Option) There are two types of printer port. One is LPT the other is USB. Connect port as show as below: USB Port Version 3.1 Page 7 of 31... -
Page 16: Power Connector
Press “I” to start up system and then you can see the power LED will be light in front of panel. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Pushes switch “I” to turn it on. Page 8 of 31... -
Page 17: Chapter Iv Pin Assignment
Network DVR Hardware User’s Manual Chapter IV Pin Assignment Internal Jumpers and Connectors Version 3.1 Page 9 of 31... -
Page 18: Power Switch For Atx Power Supply (Jp1)
P.S. For the AT system (short Pin10 & Pin12) for power on. Internal USB Connector (USB2) Power Connector (P1) CMOS Clear (J1) POWER OFF and Move JUMPER from Pin1-2 to Pin2-3 of J1, Version 3.1 tracer2000 Network DVR Hardware User’s Manual Signals Signals Signals USB2-1 Power... -
Page 19: Com2 Mode Select (Jp3)
Auto by CPU FAN Control (FAN1, 2) Function PWM Control HDD Connector (IDE1, 2) Pin No. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Mode RS232 3-5, 4-6, 9-11, 10-12, 17-18 RS422 1-3, 2-4, 7-9, 8-10, 15-16 RS485 1-3, 2-4, 7-9, 8-10, 13-14... -
Page 20: Parallel / Printer Connector (Prn)
Video Input (J2) Pin No. Note: VIN xx is analog video input channel xx. V-I-OExx is Odd / Even field information of video input channel xx. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Signal Pin No. Strobe Data 0... -
Page 21: General Purpose Input / Output (J3)
1.12 General Purpose Input / Output (J3) Pin No. 1.13 Infra-Red (IR) Version 3.1 tracer2000 Network DVR Hardware User’s Manual Signal Pin No. GPIO-0 GPIO-1 GPIO-2 GPIO-3 GPIO-4 GPIO-5 GPIO-6 GPIO-7 Pin No. Signal IRRX IRTX CIRRX Signal Audio IN3... -
Page 22: Pci Bus Pin Assignment
1.14 PCI Bus Pin Assignment Pin No. Version 3.1 tracer2000 Network DVR Hardware User’s Manual SOLDER SIDE COMPONENT SIDE Pin No. TRST* -12V +12V INTA* INTC* INTB* INTD* PREN1* PREN2* 3VSB RST* GNT0* REQ0* PME* AD30 AD31 VCC3 AD29 AD28... -
Page 23: External Connector
External Connector CRT Display Connector (VGA) Pin No. Audio Input Connector GPIO Connector USB Connector Version 3.1 tracer2000 Network DVR Hardware User’s Manual Signal Pin No. GREEN BLUE MIC1 MIC2 MIC3 MIC4 USB Ports Name USB0- USB0+ 4, 8 1, 5... -
Page 24: Com1 Connector
COM1 Connector COM2 Connector Pin No. Note: Please setup mode type by JP3. Version 3.1 tracer2000 Network DVR Hardware User’s Manual RS232 Connector (COM1) Pin No. Signal RS232 / RS422 / RS485 Connector (COM2) RS232 RS422 RS485 DATA- DATA+ RTS-... -
Page 25: Ethernet Connector (Rj-45)
External Speaker Connector HDD LED Connector External Power Connector Serial Port Audio OUT Video INPUT CMOS RAM Clear Audio / GPIO Version 3.1 tracer2000 Network DVR Hardware User’s Manual Pin No. Signal Audio IN CPU FAN Printer Label IDE1, IDE2 USB2... -
Page 26: P/T/Z Setting
Jumper 3 Setting of COM2 The system default of COM2 is RS485. Adjust jumper JP3 in system for RS422, RS232 signals as show below. RS485 Version 3.1 tracer2000 Network DVR Hardware User’s Manual RS232 / RS422 / RS485 Connector (COM2) RS232 RS422 RS232... -
Page 27: Chapter Vcmos Setting
PnP / PCI Configurations PC Health Status Esc: Quit F10: Save & Exit Setup Version 3.1 tracer2000 Network DVR Hardware User’s Manual setup program built into the ROM BIOS. The setup Frequency / Voltage Control Load Optimized Defaults Set Supervisor Password Set User Password Save &... -
Page 28: Standard Cmos Features
Drive B Video Halt On Based Memory Extended Memory Total Memory ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Mon., Feb 8 1999 16:19:20 2557MB None None None None None EGA/VGA No Errors 64512 K... -
Page 29: Advanced Bios Features
Delay (Msec) Security Option OS Select For DRAM > 64MB Report NO FDD for Win95 ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Disabled Item Help Enabled Enabled Menu Level Enabled Disabled Allows you to choose the VIRUS... -
Page 30: Advanced Chipset Features
Delay (Msec) Security Option OS Select For DRAM > 64MB Report NO FDD for Win95 ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Disabled Item Help Enabled Enabled Menu Level Enabled Disabled Allows you to choose the VIRUS... - Page 31 * Onboard Display Cache Setting * CAS# Latency Paging Mode Control RAS-to-CAS Override RAS# Timing RAS# Precharge Timing ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Item Help Menu Level Disabled Disabled Disabled Enabled Enabled 64MB 100MHz...
-
Page 32: Integrated Peripherals
EPP Mode Select ECP Mode Use DMA PWRON After PWR-Fail Watch Dog Timer Select ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Enabled Item Help Enabled Auto Menu Level Auto If your IDE hard drive supports... -
Page 33: Power Management Setup
Secondary IDE 0 Secondary IDE 1 FDD, COM, LPT Port PCI PIRQ [A-D]# ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Disabled Item Help S1 (POS) User Define Menu Level DPMS Stop Grant Disabled... -
Page 34: Pnp / Pci Configuration
IN1(V) IN2(V) VBAT(V) 5VSB(V) Shutdown Temperature ↑↓←→Move F10: Save F5: Previous Values Version 3.1 tracer2000 Network DVR Hardware User’s Manual Disabled Item Help Auto (ESCD) Menu Level Press Enter Disabled Default is Disabled. Select Enabled to reset Extended System Configuration Data (ESCD) when... -
Page 35: Frequency / Voltage Control
Save & Exit Setup Save CMOS value changes to CMOS and exit setup. 2.12 Exit Without Save Abandon all CMOS value changes and exit setup. Version 3.1 tracer2000 Network DVR Hardware User’s Manual Enabled Item Help Disabled Menu Level Enter: Select... -
Page 36: Chapter Vi System Hdd Installation Guide
Network DVR Hardware User’s Manual Chapter VI System HDD Installation Guide Follow the step to setup HDD drawing box. 1. Remove the screws on the case. (Marked in while circles) Remove the screws on the case. Version 3.1 Page 28 of 31... - Page 37 Network DVR Hardware User’s Manual 2. Take off the upper cover and remove the screws. Remove the screw. Version 3.1 Page 29 of 31...
- Page 38 Network DVR Hardware User’s Manual 3. Remove HDD tray, and install HDD properly. Version 3.1 Page 30 of 31...
- Page 39 Network DVR Hardware User’s Manual 4. Insert the assembled HDD tray into tracer2000, and connect both power and HDD. 5. Assemble the upper cover and the screws. Version 3.1 Page 31 of 31...
