T3 Flexi Installation Manual

T3 Flexi
Assembled Straight Dimensions(mm):
3 Panel: 2100(h) x 2433(w) x 279(d)
3 Panel - 16kg
4 Panel - 20kg 4 Panel: 2100(h) x 3233(w) x 279(d)
5 Panel - 23kg 3 Panel: 2100(h) x 4033(w) x 279(d)
T3 T3 Flexi Components
Foot &
Adapter
x x8 .3 Panel
A
x x10 .4 Panel
x x12 .5 Panel
Graphic
Angle
x4
D
NB: When assembling the frame make sure
all silver fronted beams are facing outwards
Graphic
Hanger
Visible Graphic Area(mm):
x6 .3 Panel
G
Front Panel: 800 (w) x 2060 (h)
x8 .4 Panel
Side Panel: 262 (w) x 2060 (h)
x12 .5 Panel
Connector
x23 .3 Panel x10 .3 Panel
B
x27 .4 Panel x12 .4 Panel
x31 .5 Panel x14 .5 Panel
Frame
(210mm)
x10 .3 Panel x6 .3 Panel
E
x12 .4 Panel x8 .4 Panel
x14 .5 Panel x12 .5 Panel
T3 Flexi
Frame
(950mm)
C
Flexi
Frame
(950mm)
F
Installation
