Head rest 10-237
Head rest 10-237 including versions
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2020-10-30
Document number: M10-237EN rev.01
1
Version
10-237
10-237-Mayf
C-C:
106 mm
C-C:
Ø:
15 mm
Ø:
Length:
120 mm
Length:
10-237-T
171,5 mm
Pole:
20x20mm
18 mm
Length:
180 mm
170 mm
Advertisement
Table of Contents
Related Manuals for Reison 10-237
Summary of Contents for Reison 10-237
- Page 1 Head rest 10-237 Head rest 10-237 including versions Version 10-237 10-237-Mayf 10-237-T C-C: 106 mm C-C: 171,5 mm Pole: 20x20mm 18 mm Ø: 15 mm Ø: Length: 180 mm 170 mm Length: 120 mm Length: Warning! This symbol indicates important information related to safety. Follow these instructions carefully.
- Page 2 Intended use Head rest intended for support and positioning of patient head during e.g. ENT-surgery. The product is to be used by medical professionals within a medical facility. Safety regulation Maximum load: 15 kg in even distribution, corresponding to a patient weight of 200 kg, according to EN 60601-1 and EN 60601-2.
- Page 3 User instruction Installation Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Adjusting the lock mechanism Tool: 2 mm hex key. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts Version: 10-237 10-237-Mayf 10-237-T Article no. Article no. Article no. Description Head rest holder 10934 11391 12008 Pivot holder 10300 10300 10300 Pivot link 10705 10705 10705 Head plate holder 11853 11853 11853 Head plate 11854 11854 11854...
- Page 6 EN 60601-1 and EN 60601-2 Material Head rest Stainless steel High pressure laminate Dimension Version UDI-DI Weight (H x W x L) 10-237 07350111831288 4,2 kg 90-350 x 250 x 570 10-237-Mayf 07350111831295 4,2 kg 90-350 x 250 x 570 10-237-T...
- Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
