Summary of Contents for OneAccess 1645

  • Page 1 1645 Installation Guide Version: 1.5 - 558499 30 January 2015...
  • Page 2 Modification date 30 January 2015 ©OneAccess Copyright notice The information and descriptions contained in this publication are the property of OneAccess. Such infor- mation and descriptions must not be copied or reproduced by any means, or disseminated or distributed without the express prior written permission of OneAccess.
  • Page 3 Col presente, OneAccess dichiara che questo 1645 è in acquiescenza coi requisiti essenziali e stipulazi- oni attinenti ed altre di Direttivo 1999/5/EC. Με το παρόν η OneAccess δηλώνει ότι το 1645 είναι συμμορφούμενο με τις βασικές απαιτήσεις και με τις υπόλοιπες σχετικές διατάξες της οδηγίας 1999/5/EC.
  • Page 4 Si vous souhaitez plus d'information concernant le point de collecte où vous pouvez apporter vos appareils usagés afin qu'ils soient recyclés, veuillez contacter votre importateur local. Pour la Belgique, vous pouvez prendre contact avec rma@oneaccess-net.com. Das Symbol der durchgestrichenen Abfalltonne auf Rädern bedeutet dass das Produkt in der Europäischen Union einer getrennten Mülsammlung zugeführt werden muss.
  • Page 5 This guide briefly highlights the Total Maintenance Application or All these documents, together with the free maintenance tool TMA and the firmware of the TDRE devices, can be found on the OneAccess Products distribution CD that is delivered with all TDRE prod- ucts.
  • Page 6 Your feedback Your satisfaction about this purchase is an extremely important priority to all of us at OneAccess. Accord- ingly, all electronic, functional and cosmetic aspects of this new unit have been carefully and thoroughly tested and inspected. If any fault is found with this unit or should you have any other quality-related com- ment concerning this delivery, please submit the Quality Comment Form on our web page at www.oneaccess-net.com...

  • Page 7: Table Of Contents

    Safety instructions / Consignes de sécurité ............. 13 Unpacking ........................ 15 Selecting a site ......................16 Mounting the 1645 on a wall ..................17 Mounting the 1645 in a 19” rack................19 Connection precautions.................... 20 Connecting the 1645 ....................21 The front panel LED indicators.................

  • Page 8: Installation Guide

    1645 User manual Installation Guide...

  • Page 9: Introducing The 1645

    Chapter 1 User manual Introducing the 1645 Introducing the 1645 This chapter gives an introduction to the 1645. The following gives an overview of this chapter: • 1.1 - General description on page 3 • 1.2 - 1645 Family Overview on page 5 •...

  • Page 10: General Description

    Monitoring quality and availability of every dataflow as part of the carrier Ethernet service gives a clear view on the status and the performance of the Ethernet service. The 1645 supports both point-to-point OAM monitoring (IEEE 802.3ah) and end-to-end performance monitoring (IEEE 802.1ag & ITU-T...
  • Page 11 Quality Monitoring And Service Level Agreements The 1645 keeps statistics of the last 15 minutes, 2 hours, 24 hours and 7 days. Selected statistics can be stored over a longer period on the device for later retrieval and processing on a management plat- form.

  • Page 12: 1645 Family Overview

    1645 Chapter 1 User manual Introducing the 1645 1645 Family Overview The following gives an overview of the 1645 versions: 1645 Gb5TU 1645 MGb5TU 1645 2Gb6TU 1645 M2Gb6TU 1645 AV2 Gb5TU...

  • Page 13: Versions Mapping

    1645 Chapter 1 User manual Introducing the 1645 Versions Mapping The products are US certified under a different name as the commercial name. In this table, you can find the mapping between the certification name and the commercial name: Commercial Name...

  • Page 14: Maintenance And Management Tools

    Introducing the 1645 Maintenance and management tools This section gives a quick overview of the various maintenance and management tools that can be used to manage the 1645. The following gives an overview of this section: • 1.4.1 - Overview of various tools on page 8 •...
  • Page 15 User manual Introducing the 1645 1.4.1 Overview of various tools The 1645 is manageable in many different ways. This section gives a quick overview of the various main- tenance and management tools. These are: Maintenance or Description and reference management...
  • Page 16 The Easy Configurator allows you to add HTML pages on top of the standard Web Interface by adding a set of specific files on the file system of the 1645. These files can be made either by OneAccess or by the customer itself.
  • Page 17 1645 Chapter 1 User manual Introducing the 1645 1.4.2 Upgrading the software Some devices are equipped with boot, loader and application software, while others only have boot and application software: • The boot software takes care of the initial phase in the start-up sequence of the device. It is located on the lowest software level.

  • Page 18: Maintenance And Management Tools Connection Possibilities

    Introducing the 1645 Maintenance and management tools connection possibilities The following table gives an overview of all the maintenance and management tools and how you can connect them with the 1645: Maintenance or manage- Tool - 1645 connection ment tool...

  • Page 19: Installing And Connecting The 1645

    1645. You are advised to read this chapter from the beginning to the end, without skipping any part. By doing so, your 1645 will be completely installed and ready for configuration when you reach the end of this chapter.

  • Page 20: Safety Instructions / Consignes De Sécurité

    • Any changes or modifications not expressly • Tout changement ou modification non approved by OneAccess could void the user's expressément approuvé par OneAccess peut authority to operate the equipment. invalider l'autorisation accordée à l'utilisateur de mettre l'équipement en service.
  • Page 21 1645 Chapter 2 User manual Installing and connecting the 1645 Use Precautions Précautions d'usage • To avoid damage to the device, please • Pour éviter d'endommager l'équipement, observe all procedures described in this chap- veuillez respecter toutes les procédures ter.

  • Page 22: Unpacking

    If the shipping carton is undamaged, do not dispose of it in case you need to store the unit or ship it in the future. Package content The 1645 package includes the following items for standard items: • 1645 device.

  • Page 23: Selecting A Site

    1645 Chapter 2 User manual Installing and connecting the 1645 Selecting a site Warning Avertissement • Always place the unit in such a way that the air • Placez toujours l'appareil de sorte que les vents are not blocked. ouïes d'aération ne soient pas obturées.

  • Page 24: Mounting The 1645 On A Wall

    Mounting the 1645 on a wall Procedure The bottom plate of the 1645 has 2 notches in order to enable wall mounting. Refer to the figure below, for the position of these notches. By installing two screws at the required distance, the device can be hung on any vertical surface.
  • Page 25 1645 Chapter 2 User manual Installing and connecting the 1645 Bottom plate of the 1645...

  • Page 26: Mounting The 1645 In A 19" Rack

    M6x16 screws. • In case the 1645 is mounted in a rack and the standard wall plug power supply is not convenient, the unit can also be ordered with a desktop power supply. In such case, an additional PSU Holder can be mounted to put the power supply on.

  • Page 27: Connection Precautions

    For the definition of an IT power system, refer to Annex V - AC power distribution systems of EN60950- 1, section V.4 IT power distribution systems. The connectors of the 1645 should only be connected to the following circuit types: Interface type...

  • Page 28: Connecting The 1645

    User manual Installing and connecting the 1645 Connecting the 1645 This section describes the 1645 rear panel. It identifies the interface type and port numbering, and explains how to connect the device. The following gives an overview of this section: •...
  • Page 29 1645 Chapter 2 User manual Installing and connecting the 1645 2.7.1 Rear view of the 1645 The following figure shows the back panel of the 1645 Gb5TU: The following figure shows the back panel of the 1645 MGb5TU:...
  • Page 30 1645 Chapter 2 User manual Installing and connecting the 1645 The following figure shows the back panel of the 1645 2Gb6TU: The following figure shows the back panel of the 1645 M2Gb6TU:...
  • Page 31 1645 Chapter 2 User manual Installing and connecting the 1645 The following figure shows the back panel of the 1645 AV2 Gb5TU:...
  • Page 32 User manual Installing and connecting the 1645 2.7.2 The different parts of the 1645 The following table gives an overview of the possible connectors located at the back of the 1645 and explains their function: Interface identi- Interface function fication DSL 1-2 These RJ11 connectors are SHDSL line connectors.
  • Page 33 1645 Chapter 2 User manual Installing and connecting the 1645 Interface identi- Interface function fication ETH2 SFP This is a fibre Gigabit Ethernet SFP slot to connect the user side, i.e. the local net- work. ETH3 SFP Connect one side of an optical cable to the SFP module inserted in the SFP slot;...

  • Page 34: The Front Panel Led Indicators

    1645 Chapter 2 User manual Installing and connecting the 1645 The front panel LED indicators This section gives an overview of the front panel LEDs and what they indicate. The following gives an overview of this section: • 2.8.1 - Introducing the front panel LEDs on page 28 •...
  • Page 35 2.8.1 Introducing the front panel LEDs When all the connections are made and the 1645 is powered, the LEDs on the front panel reflect the actual status of the device. The following figure shows the front panel LED indicators of the 1645 Gb5TU:...
  • Page 36 1645 Chapter 2 User manual Installing and connecting the 1645 2.8.2 LED states The state of the LEDs indicates the following: LED name Colour Description Bicolour • OFF: No input power. • ON - Green: Switched on and operational. •...
  • Page 37 1645 Chapter 2 User manual Installing and connecting the 1645 LED name Colour Description ETH2 Bicolour • OFF: The Ethernet port is not connected. • Green: The Ethernet port is active. ETH3 • Blinking green: Traffic in progress on the second (ETH2) / third (ETH3) Ethernet port.

  • Page 38: Powering Up The 1645

    Connect the power supply to the AC mains. Self test A few seconds after the power is switched on, the 1645 performs a series of self-tests and loads the software into memory (RAM), during which the PWR LED on the front panel blinks.

  • Page 39: Tma Sub-System Picture

    How to display the sub-system picture? To display the sub-system picture of the 1645, click on the sub-system picture button located in the TMA toolbar: Structure of the sub-system picture This paragraph displays and labels the different elements of the sub-system picture.
  • Page 40 1645 Chapter 3 User manual TMA sub-system picture Below, the sub-system picture of the 1645 MGb5TU is displayed: The following table gives an overview of the sub-system picture elements and what they indicate: Element Description LEDs on front These reflect the actual status of the device.

  • Page 41: Technical Specifications

    1645 Chapter 4 User manual Technical specifications Technical specifications This chapter gives the technical specifications of the 1645. The following gives an overview of this chap- ter: • 4.1 - SHDSL line specifications on page 35 • 4.2 - VDSL and ADSL line specifications on page 36 •...

  • Page 42: Shdsl Line Specifications

    1645 Chapter 4 User manual Technical specifications SHDSL line specifications • Single pair, dual pair, 4 pair line access • Connector: RJ11 Ω • Impedance: 135 • Cable to be used: CAT5E twisted pair • Coding: TCPAM, compliant to ITU-T G.991.2; G.SHDSL, and G.SHDSL.bis via TCPAM-16 and TCPAM-32 •...

  • Page 43: Vdsl And Adsl Line Specifications

    1645 Chapter 4 User manual Technical specifications VDSL and ADSL line specifications • Single pair line access • Connector: RJ11 • Impedance: 135 ohm • Cable to be used: CAT5E twisted pair • Coding compliant to: ANSI T1.413 Issue 2 ETSI TS 101 388 v1.3.1...

  • Page 44: Eth1 4 Port Ethernet Switch Specifications

    1645 Chapter 4 User manual Technical specifications ETH1 4 port Ethernet switch specifications • 4 port Ethernet switch with 10/100/1000 Base T ports • Connectors: RJ45 (EIA/TIA 568B) • Cable to be used: standard Ethernet cable, minimum category 5 Each UTP Ethernet port supports: •...

  • Page 45: Eth2/Eth3 Utp Interface Specifications

    1645 Chapter 4 User manual Technical specifications ETH2/ETH3 UTP interface specifications • Connector: RJ45 (EIA/TIA 568B) • Cable to be used: standard Ethernet cable, minimum category 5 • Applicable standards: IEEE 802.3 (10Mbps Ethernet Half Duplex or Full Duplex) IEEE 802.3u (100Mbps Ethernet Half Duplex or Full Duplex) IEEE 802.3ab (1000Mbps Full duplex)

  • Page 46: Eth2/Eth3 Sfp Interface

    1645 Chapter 4 User manual Technical specifications ETH2/ETH3 SFP interface • 100 or 1000 Base X port • INF-8074 and SFF-8472 compliant • The following working modes are supported and/or can be forced: Full duplex 100 Mbps Full duplex 1000 Mbps Speed selection: by configuration only •...

  • Page 47: Usb Interface Specifications

    1645 Chapter 4 User manual Technical specifications USB interface specifications • Standard Type A USB connector. • USB version 2.0 interface. • The USB interface can operate as a master. • The USB master interface can deliver up to 1000mA at 5V.

  • Page 48: Console Port Specifications

    1645 Chapter 4 User manual Technical specifications Console port specifications • Connector: RJ45 (EIA/TIA 568B) • Data: RS232 9600 bps 8 data bits no parity 1 stop bit • The following table shows the connector layout of the RJ45 Console connector:...

  • Page 49: Power Requirements

    • Output: 12 Vdc; 2,9 A; 35W • Limited Power Source (LPS) Do not use another type of power supply than the one recommended by OneAccess. Dimensions The 1645 has a metal housing with the following characteristics: • Width: 275 mm •...

  • Page 50: Safety Compliance

    1645 Chapter 4 User manual Technical specifications 4.10 Safety compliance • EN60950-1: Safety of information technology equipment, including electrical business equipment. • Devices with earth stud: Class I equipment (powered by Class II AC/DC adapter) • Devices without earth stud: Class III equipment (powered by Class II AC/DC adapter) 4.11...

  • Page 51: Annex

    1645 Annex Annex...

  • Page 52: Annex A:console Cable

    1645 Annex A: Annex Console cable Annex A: Console cable Standard console cable The following figure shows the console cable assembly; it has reference code 501288:...

  • Page 53: Index

    Annex Index installing and connecting the device 12 introducing Numerics maintenance and management tools 7 1645 family, overview 5 the device 3 1645, what is 3 introduction 2 connecting the device 21 LED indicators 27 connecting the different parts of the device 25...
  • Page 54 1645 Index Annex connector lay-out 36 over-voltage and over-current protection compliance 44 power requirements 42 safety compliance 44 USB interface 40 statements iii TDRE version vi what is vi technical specifications 34 TMA sub-system picture 32 how to display 32...
