ARCHIVADOR / MUEBLE PARA IMPRESORA (OFL21-D)
BUREAU À CHEMISE / SUPPORT POUR IMPRIMANTE (OFL21-D)
Questions, problems, missing parts? Before returning to the store call
¿Tiene alguna pregunta, problema o le faltan piezas? Antes de regresar a la tienda, llame
Questions, problèmes, parties manquantes? Avant de retourner au magasin appelez
FILE / PRINTER STAND (OFL21-D)
Customer Service
Time available: 8:00 am - 5:00 pm PST
1-888-552-0592
Hotline:
al Servicio al Cliente.
Horario: 8:00 am a 5:00 pm PST
Número gratuito:
Service à la clientèle
Heures de disponibilité : 8am à 5pm PST
Ligne sans frais:
Thank you for choosing E-Ready Furniture.
Gracias por preferir E-Ready Furniture.
Merci d'avoir choisi E-Ready Furniture.
1 of 10
Assembly Instructions
Instrucciones de Armado
Instructions d'ssemblage
1-888-552-0592
1-888-552-0592
Advertisement
Summary of Contents for E-Ready Furniture OFL21-D
- Page 1 Instructions d'ssemblage FILE / PRINTER STAND (OFL21-D) ARCHIVADOR / MUEBLE PARA IMPRESORA (OFL21-D) BUREAU À CHEMISE / SUPPORT POUR IMPRIMANTE (OFL21-D) Questions, problems, missing parts? Before returning to the store call Customer Service Time available: 8:00 am - 5:00 pm PST...
- Page 2 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Getting to know your product Conociendo su producto Apprendre à connaître votre produit Part List: Lista de partes: Liste des pièces: Part Description Quantity Descripción Cantidad Description Quantité Pieza Pièce Top Assembly Parte superior Assemblage supérieur Left Side Assembly Parte lateral izquierda...
- Page 3 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Hardware List: Lista de herrajes y accesorios: Liste des matériaux: NOTE: Hardware not shown to actual size. NOTA: Las ilustraciones de los herrajes y accesorios no aparecen en su tamaño real. NOTE: Les images de matériaux ne sont pas représentatives des grandeurs réelles. Part Description Quantity...
- Page 4 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Two persons are recommended for assembly. Unpack the inventory parts on a soft and smooth surface. Do not use power tools. Do not overtighten any connectors. A Philips head screwdriver is required (no t included) for the assembly.
- Page 5 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Step 1 Place Left Side Assembly (2) on the soft and smooth surface with holes facing up. Connect Top Assembly (1) to Left Side Assembly (2) with Allen Head Bolts (H1), Lock Washers (H2) and Flat Washers (H3) by turning Allen Wrench (H4) until tight.
- Page 6 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Step 3 Attach the Right Side Assembly (3) to the current assembly using Allen Head Bolts (H1), Lock Washers (H2) and Flat Washers (H3) by turning the Allen Wrench (H4) until tight. Paso 3 Una la Parte lateral derecha (3) al montaje actual usando Pernos Allen (H1), Arandelas de presión (H2), Arandelas planas (H3) al girar la Llave Allen (H4) hasta que estén bien ajustados.
- Page 7 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Step 4 Insert the back panel (6) into grooves on Left Side Assembly and Right Side Assembly (2&3) as shown. Paso 4 Inserte el Panel posterior (6) en las ranuras de la Parte lateral izquierda y la Parte lateral derecha (2 y 3) como se muestra en la ilustración.
- Page 8 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage front favant rente grooves ranuras front favant rainures rente Step 6 Please do the assembly as the arrows show: 1) Attach the Drawer Right Panel (9) to the Drawer Front (7). Please note the mark and arrow on (9) when doing assembling. 2) Insert Screws (H7) into the intended holes on the Drawer Right Panel (9), and tighten them with a Philips screwdriver.
- Page 9 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Step 7 Attach drawer back to the current drawer assembly as shown. 1) Insert the left 4 Screws (H7) into the intended holes on the Drawer Right Panel and tighten them with a Philips screwdriver. 2) Connect the 3 minor parts (H5) together and insert them to the intended holes on the back of the front panel with 2 bolts and tighten them with a Philips screwdriver.
- Page 10 Assembly Instructions Instrucciones de Armado Instructions d'ssemblage Step 8 1) Place the File Hanger Bars (H8) into slots. 2) Refer to Page 4 for instructions on how to install the drawer into the stand. Paso 8 1) Coloque la Barra para colgar archivos (H8) en la ranura. 2) Consulte la página 4 donde aparecen las instrucciones sobre cómo instalar el cajón en el mueble.
