Summary of Contents for FUJIDENZO CU-221EDF SS
- Page 1 Commercial Stainless Steel Freezers December 2016...
- Page 2 CU-221EDF SS Stainless Steel Dual Function Upright Freezer Features: - Digital Temp Control - With Lock and Key - LED-Lighted Interior - Programmable Automatic Defrost - Adjustable Wire Shelves - Roller Feet with Stopper - Embraco/Secop Compressor - Eco-friendly R404a Refrigerant - Capacity: 600 Liters - Temp: -22˚C to +10 ˚C...
- Page 3 CU-438EDF SS Stainless Steel Dual Function Upright Freezer Features: - Digital Temp Control - With Lock and Key - LED-Lighted Interior - Programmable Automatic Defrost - Adjustable Wire Shelves - Roller Feet with Stopper - Embraco/Secop Compressor - Eco-friendly R404a Refrigerant - Capacity: 1065 Liters - Temp: -22˚C to +10 ˚C - HWD in mm: 2010 x 1333 x 774...
- Page 4 Accessories 1. User’s Manual 2. Programming Manual 3. Warranty Card 4. Keys...
-
Page 5: Technical Specifications
Technical Specifications Model Number CU-221EDF SS CU-438EDF SS Rated Voltage / Frequency 220-240V/60Hz 220-240V/60Hz 4.2A 6.3A Current Wattage 8.8KWh/24h 9.6KWh/24h Energy Consumption Refrigerant/Amount R404a/380g R404a/450g 115kg 164kg Net Weight in kg Gross Weight in kg 125kg 173kg Embraco Embraco Compressor Brand... -
Page 6: Model And Serial Number Location
Model and Serial Number Location Model Number Serial Number Located at the right-hand wall of the unit. -
Page 7: Installation Procedure
Installation Procedure 1. After delivery, allow the unit to stand for 12 hours before operation, in order to let the compressor oil settle. 2. Before using the unit for the first time clean the shelves and freezer cavity with soapy water. ONLY USE DISH WASHING SOAP. 3. -
Page 8: Control Panel
Control Panel Compressor Temperature Controller Indicator Light Switches the controller to programming mode Power Switch Increases the value of the controller parameter Decreases the value of the controller parameter Activates the Manual Defrost mode... - Page 9 Control Panel Legends and Commands Control Panel Legends Control Panel Commands...
- Page 10 Usage TURNING ON THE UNIT AND SETTING THE TEMPERATURE Make sure that power switch is set to [O] before the power cord is plugged into the power source. Switch on the Power [I]. The current temperature will be displayed on the screen.
- Page 11 Usage TO MANUALLY DEFROST THE UNIT Press and hold the DEFROST button for 5 seconds. The defrost cycle will start immediately and the DEFROST symbols will light up on the display. NOTE: The defrost cycle will last for 30 minutes...
-
Page 12: Care And Maintenance
Care and Maintenance Switch off and disconnect the power cord from the power supply before cleaning Clean the freezer cavity as often as possible to maintain food safety Do not use abrasive cleaning agents as this leaves harmful residue and damages the freezer cavity. - Page 13 Care and Maintenance The condenser filter should periodically be cleaned in order to let the unit run on its optimal performance. Condenser Filter...
-
Page 14: Error Codes
Error Codes Self-correction Routine Error Code Self-correction Routine P1 and P2 Unit automatically stops for a few seconds afterwards the unit resumes its normal operation HA and LA Error automatically clears as soon as the temperature returns to normal values. EA and CA Error automatically clears as soon as the digital input is disabled... -
Page 15: Warranty Information
Warranty Information Commercial Stainless Steel Freezer 1 Year Warranty on Parts 1 Year Warranty on Service 1 Year Warranty on Compressor...
