PVC Venetian Blind
Model Code: 4716, 4717, 4718, 4719, 4720, 4721, 4722, 4723, 4724, 4725, 4726, 4727
Page 1
User Manual
Model Code:
4716-4727
Manual Version: V1.0
Oypla.com LLP / www.oypla.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for OYPLA Home 4716-4727
- Page 1 Page 1 User Manual Model Code: 4716-4727 Contents Front Cover Safety Instructions Assembly Instructions Operating Instructions Back Cover *COLOUR MAY VARY PVC Venetian Blind Manual Version: V1.0 Model Code: 4716, 4717, 4718, 4719, 4720, 4721, 4722, 4723, 4724, 4725, 4726, 4727...
- Page 2 Page 2 Safety Instructions Contents Front Cover Notice: Ensure you read and fully understand instructions before use While every attempt is made to ensure the highest degree of protection in all equipment, we cannot Safety guarantee freedom from injury. The user assumes all risk of injury due to use. All merchandise is sold Instructions on this condition, which no representative of the company can waive or change.
- Page 3 Page 3 Contents Assembly Instructions Front Cover Parts List: Safety Instructions If you are missing any of the below parts, please contact cservice@oypla.com Assembly Instructions Operating Instructions Back Cover Part Description Quantity Blind Wand Bracket Central Support 60/80cm Model: 0pcs, 100/120cm Model: 1pc Bracket Face Hold Down Bracket...
- Page 4 Page 4 Contents 1. The blind can be positioned: Front Cover Inside Mounting (fit to the inside of the window frame) (fig. 1) Outside Mounting (fit to the outside of the window frame) (fig. 2) Safety Ceiling Mounting (fit to the ceiling above the window frame) (fig. 3) Instructions Assembly Instructions...
- Page 5 Page 5 Contents 4. Slide the Bracket Face Plate (E) into the Bracket (C). See figure 6. Front Cover Safety Instructions Assembly Instructions Operating Instructions Back Cover 5. Affix the Wand (B) onto the Blind (A). See figure 7. 6. Using the Short Screws (H) provided, affix the Hold Down Brackets (F) The hole on the end of the bottom rail fits into the Hold Down Bracket at the end of the window.
- Page 6 Page 6 Contents Shortening the Blind Note: Before fitting, you can custom-fit the blind to the correct height. *Use figures 11 to 14 to help you through this process. Front Cover 1) Height – when the blind is fully lowered, there should be no slats Safety overlapping at the bottom of the blind.
- Page 7 Page 7 Contents Operating Instructions Front Cover Safety Lowering: Hold cord at eye level, and Instructions push to the left pulling down gently – until the cord lock releases. Allow the Assembly cord to slip through fingers until blind Instructions reaches desired level.
