Summary of Contents for a-TroniX Wallbox home
- Page 1 User Manual Wallbox home plus with charging socket Wallbox home, home plus und business Article Article number a-TroniX Wallbox Home 9885132 a-TroniX Wallbox Home Plus 9885176 a-TroniX Wallbox Home Plus with charging socket 9885739 a-TroniX Wallbox Business 9885123 09/2021 Page 1...
- Page 2 User Manual Wallbox home, home plus, home plus with charging socket and business INTRODUCTION The publication and copyright of this documentation remain with the company AKKU SYS Akkumulator- und Batterietechnik Nord GmbH. Verbindungsweg 23 - 25469 Halstenbek / Hamburg - GERMANY Phone +49 4101 | 3 76 76-0 / Fax +49 4101 | 3 76 76-66 info@akkusys.de / www.akkusys.de...
-
Page 3: Table Of Contents
User Manual Wallbox home, home plus, home plus with charging socket and business Table of contents Page 1. ABBREVIATIONS 2. SAFETY INSTRUCTIONS 2.1. Safety symbols and notes 2.2. Environment 2.3. Installation 2.4. Operating 2.5. Maintenance 3. STANDARDS 3.1. Charging mode 3.2. - Page 4 User Manual Wallbox home, home plus, home plus with charging socket and business 5.4. Installation Steps 5.4.1. Step 1: Install the attachment 5.4.2. Step 2: Wiring 5.4.3. Step 3: hang on 5.4.4. Step 4: fixation 6. OPERATION 6.1. Power On 6.2.
-
Page 5: Abbreviations
User Manual Wallbox home, home plus, home plus with charging socket and business 1. ABBREVIATIONS Abbreviations Description International Electrotechnical Commission Electrical Vehicle, this can be BEV (battery EV) or PHEV (plug-in hybrid EV) EVSE Electric Vehicle Supply Equipment [IEC61851-1] Kilo Watt (unit of power) -
Page 6: Safety Instructions
User Manual Wallbox home, home plus, home plus with charging socket and business 2. SAFETY INSTRUCTIONS Persons installing and using chargers must observe the principles and regulations ■ to ensure personal safety, the safety of the operating personnel and the safety of the appliance. -
Page 7: Safety Symbols And Notes
User Manual Wallbox home, home plus, home plus with charging socket and business 2.1. Safety Symbols and Notese The following warning signs, mandatory signs and information signs are used in the charging station operating instructions: Caution: Warning of electrical hazards. -
Page 8: Environment
User Manual Wallbox home, home plus, home plus with charging socket and business Environment EV Charging station should be installed on the incombustible such as metal; ■ otherwise, hazardous fire may result. EV Charging station should not be installed in the area that contains ■... -
Page 9: Operating
User Manual Wallbox home, home plus, home plus with charging socket and business 2.4 Operating Strictly forbidden for minors or persons of restricted capacity to approach ■ the charging station to avoid injury. Forced charging is strictly forbidden when the electric vehicle or charging ■... -
Page 10: Standards
3.1. Charging mode According to IEC 61851-1(3.1.9; 6.2.3). ■ The a-TroniX-series Wallbox is an EVSE, that conforms to the Mode 3 (quick charge up ■ to 250A). Mode 3 is a method for connecting an electric vehicle to an AC electric vehicle supply device that is permanently connected to an AC supply network. -
Page 11: Charging Connection
Case B connection for the a-TroniX Wallbox Home Plus with charging-socket: 3.3.2. Case C connection Case C connection for the a-TroniX Wallbox Home, Home Plus and Business articles: 3.4. EU Declaration of Conformity Our EU Declaration of Conformity can be found at the following link: https://www.akkusys.de/wp-content/uploads/2021/06/Wallbox_EU-Konformitaetserklaerung.pdf... -
Page 12: Product Information
Shape and dimensions of the a-TroniX series AC EV charging station (see Fig. 4-1): Fig. 4-1 The Shape & Dimensions of M3W The AC EV charging station of the a-TroniX series provides a friendly user interface with ■ the corresponding control, measurement and communication functions. -
Page 13: Block Diagram
4.2. Block diagram Ethernet Wifi Main PCBA RFID RCCB Charging Connector Fig. 4-2 Block diagram of the a-TroniX AC EV Charging station 4.3. Product series 3-phase products (with 3-phase type 2 plug, see Fig 3-2 (b)) Modell Home, Home Plus with Business... -
Page 14: Functional Description
User Manual Wallbox home, home plus, home plus with charging socket and business 4.4.2. Functional description 1 Charging mode Modus 3 2 Charging control Local: „Plug-and-charge“ or „swipe card-controlled“ Remote: Smartphone APP control 3 Display screen Optional, 4.3-inch LCD screen (display charging current, voltage, energy, charging time, state &... -
Page 15: Nameplate
User Manual Wallbox home, home plus, home plus with charging socket and business 4.5. Nameplate On the back of your wallbox you will find the type plate for identification. (Fig. 4-3): Fig. 4-3 Nameplate of charging station 5. INSTALLATION INSTRUCTIONS 5.1. -
Page 16: Unpacking
User Manual Wallbox home, home plus, home plus with charging socket and business 5.2. Unpacking 5.2.1. Packing list In the package, there is a packing list, which includes: 1 EV-charging station (a-TroniX Wallbox) ■ 1 RFID Card ■ 1 set of wall-mounting accessories (including screws) ■... -
Page 17: Tools For Installation
In order to ensure good ventilation condition, you should mount the charging station vertically and leave enough space. c. Mounted the a-TroniX Wallbox on the wall is shown in Fig.5-1 and 5-1-1. d. If you purchase products with floor mounted accessories, the installation effect is similar to that of wall mounted product. - Page 18 User Manual Wallbox home, home plus, home plus with charging socket and business Fig. 5-1 Mounted the a-TroniX-series product on the wall (Home, Home Plus, Business) Fig. 5-1-1 Mounted the a-TroniX-series product on the wall (Home Plus with charging socket)
-
Page 19: Installation Steps
User Manual Wallbox home, home plus, home plus with charging socket and business 5.4. Installation Steps 5.4.1. Step 1: Install the attachment Drill mounting holes with a diameter of 10 mm and a depth of 50 mm at the corresponding height at a distance of 130 mm ×... -
Page 20: Step 3: Hang On
User Manual Wallbox home, home plus, home plus with charging socket and business 5.4.3. Step 3: hang on Follow the arrow, and hold the Wallbox Accessories 4 on the attachment. Fig. 5-4 Hang the wallbox on the attachment 5.4.4. Step 4: fixation Tighten the set screws on the left and right ends to fixed the Wallbox. -
Page 21: Operation
The „POWER“ indicator light lights up and the charging station switches to standby mode. 6.2. Interface 6.2.1. Information As shown in Fig. 6-1, the a-TroniX series product is equipped with several interfaces. Fig. 6-1 HMI of the a-TroniX Wallbox 1 LED indicators... -
Page 22: Led Indicators
In any state, the Power indicator is twinkle, indicating that the charging station is connected to the CMS through the network. 6.2.3. LCD Display The LCD of the a-TroniX series is a 4.3 inch screen that mainly displays various status infor- mation of the charging station (see fig. 6-2). a) Standby... -
Page 23: Rfid Reader
Fig. 6-2 LCD display 6.2.4. RFID reader In general, the a-TroniX Wallbox is equipped with an RFID card reader as standard and the charging process can be started and stopped using the RFID card configured with the host (see Fig. 6-3). The special custom card swipe function is not described separately here. -
Page 24: Emergency Stop Button
6.2.6. Charging Port & Type2 Plug Holder The a-Tronix series AC EV charging station has a type 2 charging connector. When the charging station is in standby mode, insert the charging plug into the type 2 holder to protect the charging plug. -
Page 25: Stop Charging
User Manual Wallbox home, home plus, home plus with charging socket and business 6.4. Stop charging a) There are two normal stoppages for „plug-and-charge“ charging station: first, automatic stoppage with full charge, and second, manual stoppage. b) Operation of manual stoppage: Fig. - Page 26 User Manual Wallbox home, home plus, home plus with charging socket and business a) Switch on the WLAN router to ensure that the router can establish a normal connection to the Internet. b) Turn on the smartphone‘s WLAN, connect the smartphone to the router via WLAN and make sure that the phone can access the Internet via the router.
- Page 27 User Manual Wallbox home, home plus, home plus with charging socket and business Fig. 6-5 The WiFi configuration page f) When all indicator lights start to flash at the frequency of 1 Hz, it indicates that the WiFi configuration of charging station is completed. At the same time, the LCD screen will display „Successful“...
-
Page 28: Error Handling And Maintenance
User Manual Wallbox home, home plus, home plus with charging socket and business 7.7. ERROR HANDLING AND MAINTENANCE 7.1. Error Handling (Troubleshooting) The charging station is automatically protected in the event of the error. The error information and handling methods are as follows. - Page 29 User Manual Wallbox home, home plus, home plus with charging socket and business Error information Error Handling Method Error code 16: Error light flash slowly Metering error once and fast 6 times • Power off and restart the device. Error light flash...
-
Page 30: Maintenance
User Manual Wallbox home, home plus and business 7.2. Maintenance To ensure the long-term stable operation of the equipment, please maintain the equipment regularly (usually every month) according to the operating environment. a) The equipment is maintained by professionals. b) Check whether the equipment is well grounded and safe.
