Artemis 600S User Manual

Diode laser hair removal system

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

User Manual

Diode laser hair removal system

Model No.: Artemis600S

Manufacturer：Wuhan Lotuxs Technology Co.,Ltd

Address ：5th Floor，E2 Building，Future City,

No.999 High-tech Avenue, East Lake High-tech Zone,

Wuhan 430206, Hubei

Tel：0086-27-88189920

Fax：0086-27-87515058

Please read the user manual before use.

Table of Contents

Need help?

Do you have a question about the 600S and is the answer not in the manual?

Questions and answers

Summary of Contents for Artemis 600S

Page 1 User Manual Diode laser hair removal system Model No.: Artemis600S Manufacturer：Wuhan Lotuxs Technology Co.,Ltd Address ：5th Floor，E2 Building，Future City, No.999 High-tech Avenue, East Lake High-tech Zone, Wuhan 430206, Hubei Tel：0086-27-88189920 Fax：0086-27-87515058 Please read the user manual before use. ...
Page 2: Table Of Contents
Contents 1. Safety ................错误！未定义书签。 1.1 Intruduction ....................1 1.2 Brief introduction ..................2 1.2.1 Eye protection ................2 1.2.2 Patient protection ................3 1.2.3 Operator protection ........错误！未定义书签。 1.2.4 Treatment room Requirements ............. 3 1.3 Main warning ................... 3 1.4 Warning labels ..................
Page 3 4.1.4 System ready ................22 4.2 Other functions..................22 4.2.1 Track customer treatment record ..........22 4.2.2 Log out/Switch operation ............23 4.2.3 Save or modify treatment parameter ........... 23 4.2.4 System setting ................24 4.3 Treatment ....................25 5.
Page 4: Safety
Chapter 1. Safety It shows the safety considerations when using the Artemis 600S diode laser hair removal system in this Chapter, especially the safety for the optical and electrical system. Warning It may cause personal injury if not adjust or use the machine as required by this manual.
Page 5: Brief Introduction
Maximum Permissible Exposure (M.P.E.) on the cornea and on the skin. The laser beam can thus be considered as dangerous if the operator is closer from the source than the N.O.H.D. And the N.O.H.D of Artemis 600S is 4.57m.
Page 6: Patient Protection
◆Ensure there is no highly reflective material in the office, otherwise the radiations will do harm to the body. 1.3 Main Warnings Artemis 600S can only be operated when the system inspection is done and no alarm generated. Please carefully read the following warnings ...
Page 7 ◆Do not open the cover to adjust or repair the system by yourself. Only the authorized person by Lotuxs could do so. ◆To make sure that rated voltage of Artemis 600S agree with the commercial voltage (AC200-240V) in your country.
Page 8: Warning Labels
Warning labels 1.4.1 Sample for warning labels Labels Remark Name plate Information and technical information for machine and manufacturer Laser warning label Remind there is laser radiation near the device. Attention: Check the document along with the machine Please follow the user manual to operate the machine Emergency Shut-down...
Page 9: Warning Labels In Treatment Room
Picture 1.8 Warning for laser beam 1.5 Laser, electrical and mechanical safety 1.5.1 Laser safety The Artemis 600S diode laser hair removal machine is a high-tech laser device, operators should pay attention to the laser safety when use the machine, follow the below instructions: ...
Page 10: Electrical And Mechanical Safety
◆Make sure all staff in the treatment room know how to use and shut down the diode laser hair removal machine. ◆The Artemis 600S diode laser hair removal machine should be operated by the professional staff. ◆Do not use the handle piece beyond the scope of this user manual.
Page 11: Fire Hazards
voltage, and only authorized personnel by Lotuxs can open the cover plates. ◆Do not open the power supply or the cover plates while maintaining, or leave it untended. ◆The machine has is well-balanced, and can be moved with caution. ◆The ground electrode in the power protection sheath should be connected with earth through wall Line;...
Page 12: Safety Setting
Artemis 600S is equipped with a few safety device that the operator should be familiar with. Key Switch: It is used to turn on or off the Artemis 600S diode laser hair removal machine. Only the key of Lotuxs can open the machine, which can prohibit illegal use.
Page 13 The network power supply connected to this unit must use a single-phase three-wire power socket that conforms to the national standard and has good grounding, and the specification is 10A. ◆There is no application part that protects against defibrillation discharge effects.
Page 14: Machine Introduction
Chapter 2 Machine introduction This chapter is the general introduction for Artemis 600S diode laser hair removal machine 2.1Brief introduction 2.1.1Machine outlook ...
Page 15: Machine Specification
2.1.3 Machine specification Artemis 600S laser hair removal utilize the unique 810nm diode laser with long pulse width and the right wavelength to penetrate into the hair follicle. Using the theory of selective laser absorption, laser can be preferentially absorbed by the melanin of the hair.
Page 16: Working Environment
2.3Working environment ◆Working environment A．Environment temperature : 10℃~40℃; B． : ≤80%; Relative Humidity C．Atmospheric Pressure: 860hPa~1060hPa; D．Power Supply: AC200～240V/50Hz. ◆Transportation and Storage Environment A．Environment Temperature::0℃~60℃; B． : ≤100%; Relative Humidity C．Atmospheric Pressure: 500hPa~1060hPa ...
Page 17: Installation
Chapter 3. Installation The Artemis 600S diode laser hair removal machine is used in beauty salon and beauty clinics. 3.1 Installation environment requirements Select a place to install the Machine While selecting the place, you have to consider the following factors: ◆Keep the machine away from the inflammables, the explosives and corrosives,...
Page 18: Installation Requirements
The dimension of Artemis 600s Diode laser hair removal machine is 53cm×45cm×132cm (vertical screen) Electrical Requirements The rated voltage of Artemis 600S diode laser is in accordance with the requirement of the user. And the electrical requirements are as follows Single-phase AC200～240V， 50Hz10% The grounded circuit contributes a lot to safe operation.
Page 19: Movement
The dust in the air should be as less as possible. The dust can absorb light energy and be heated. The dust on the surface of sapphire may damage the sapphire when it was being hearted. The metal particles may damage electrical components. Temperature: To ensure the best working status of the machine, the indoor temperature should be kept between 20C and 25C, and relative humidity should be not exceed 80%.
Page 20 C． The machine should be protected with 70mm to 100mm shock-proof materials. The front panel should be protected with thick foam plastic, especially the LCD. D．Enclose the case properly E．Label the remarks “Fragile! Take Care!” ...
Page 21: Operation Instruction
Chapter 4. Operation Instruction This chapter shows how to use the Artemis 600S diode laser hair removal machine 4.1 Instruction 4.1.1 System start-up Connect to power supply, and push the air switch upwards to the position“I”, turn the key switch clockwise to turn on the machine, and go to the main interface, as picture 4.1.
Page 22 Picture 4.2 Customer data interface Press gender, to choose “Male” or “Female”, and enter the customer’s phone number, then press “Save”, see as picture 4.3 Picture4.3 Save new customer data ●Ways to login Way 1： Go back to main interface after saved new customer data, press the button “Data”...
Page 23: Treatment Mode And Parameter Setting
Picture 4.4 Customer search interface Remark: On the upper right corner of the phone number there is a green icon “Reminder”, which shows it is time to remind the customer to do next treatment session. And press the red delete button on the phone number can delete the customer data.
Page 24 Feature for SHR mode is lower power density, higher average power STACK MODE is used for facial hair treatment (hair line, lip hair), bikini area, finger, foot and other smaller area treatment. Parameter scope for three treatment modes（Press the button “ ”...
Page 25: System Ready
Tips: During the treatment, the operator should adjust the power from lower to higher, make sure the customer can tolerate, according to customer’s feeling, if feel too hot, can press the cooling button “ ” on the lower right corner. 4.1.4 System Ready The machine is in ready status after chosen the treatment mode and set the treatment parameter, shown as picture 4.8, press the button “Ready”...
Page 26: Log Out/Switch Operation
Remark： 1. Slid the screen up and down to track more customers’ treatment record. 2. Press the button “Customer” , can go back to the search page as picture 4.4 3. Press the button “Home” , can go back to the main interface. 4.
Page 27: System Setting
Picture 4.12 save setting parameters 4.2.4 System setting Press the button “System” you will see the system setting, it shows the machine SN number, software version, main engine SN number, Handle piece SN number, working time and etc. Shown as picture 4.13 Picture 4.13 System setting Default：...
Page 28: Treatment
Back：Back to the previous interface。 Debug： Monitor the current threshold current, maximum power, maximum current and temperature for laser module and skin. Update: Update the machine control board or system version online or by USB. Shown as picture 4.12 Picture 4.14 System update 4.3 Treatment Step1: Cleanse...
Page 29 Picture 4.13 Shave the hair Step 3：Apply cooling gel Apply cooling gel on the target treatment area to protect the skin, minimizing discomfort and protecting your skin during the treatment. Picture 4.14 Apply cooling gel Step 4：Set the treatment parameter Adjust the power density and frequency.
Page 30: Maintenance And Repair
Chapter 5. Maintenance and repair In this chapter the methods to maintain the machine and the solutions for common fault is included. The user could only carry out the following maintenance work, while the other can only be done by technician authorized by Lotuxs. 5.1Machine cleaning Clean the surface of the machine with wet cotton ball once a week.
Page 31: Regular Maintenance
1． Turn off the machine and disconnect the power cord. Check whether the machine is off and power cord is disconnected before changing water to avoid danger. 2．Lock the universal wheel There are four universal wheels at the bottom of the machine, two of which has locks.
Page 32: Troubleshooting
◆Inspection or replacement for the “O” shape ring of the handle connection position. Warranty: Wuhan Lotuxs Technology Co., Ltd offers one year free warranty. Environmental protection and disposal: Please do not discard the old machine to public waste bin. Please dispose or recycle your old electronic devices to local authorized garbage can.
Page 33: Attention
5.5 Attention Attention： 1. There is high voltage when using the Artemis 600S diode laser hair removal system, the operator should follow the user manual strictly, it is forbidden to touch the parts with electricity to avoid electric shock.
Page 34: Application Guide
Chapter 6 Application guide Artemis 600S should be operated by practiced beautician or other professional personnel. Wuhan Lotuxs Technology Co., Ltd will hold such trainings regularly around the country. It is recommended that the beauticians should participate in the training.
Page 35: Post-Hair Removal Care
6.3 Post-hair removal care Cold compress rather than ice compress can release the swelling and discomfort. The temperature of the pack for cold compress cannot be lower than 4 C. 　 The blisters and ulcers on the skin after hair removal treatment can be treated with antibiotic ointments and burn ointments (e.g.
