Voltage testing

Apply the test probes to The level of voltage pre-
the potential points you sent is indicated by the
wish to test. LED's lighting up as far as
the step level of voltage
For DC voltage testing, the
present. An acoustic indi-
test probe on the display
cation is also given for
handle represents the
Combi Check 1.2.
positive pole, and the
small test probe the neg-
ative pole.
The positive and the neg-
ative diode of the 6 V volt-
age step will light up
simultaneously for AC
voltage.
The entire LED step dis-
play will briefly light up at
the start of each voltage
test.

Continuity testing

Before conducting a con- with the test probes. If
tinuity test in electrical contact resistance is
systems, first switch off < 500 kOhms, the +6 V
external voltage sources diode will light up.
and, where applicable,
An acoustic indication is also
discharge capacitors.
given for Combi Check 1.2.
Short the test probes and
Impressed external voltages
keep button pressed.
will be indicated despite the
Contact the test object continuity test, and will not
with the test probes. harm the tester.
Contact the test object
12
Semiconductor testing
When the button is pressed The display handle repre-
during polarity-dependent sents the positive pole, and
continuity testing, the internal the small handle the negative
test voltage source is pole. If continuity is given, the
switched to the test probes. +6 V diode illuminates. An
acoustic indication is also
given for Combi Check 1.2.
Phase testing
(Combi Check 1.2 only)
correct
WARNING: Phase testing
cannot be performed in
unfavourable locations, e.g.
on ladders with wooden
rungs or in rooms with insu-
lated floor coverings and in
AC voltage systems not
properly bonded to earth.
To perform the phase test,
contact the small test
probe with the phase
(> 90 V AC) of the AC
voltage system and touch
the phase tester contact
on the indicator handle
with your thumb. The 6 V
step indicator (+ and –)
will light up upon phase
contact and an acoustic
signal is also given.
incorrect
13
