- Page 1 Smart Battery 2019 User Manual...
- Page 2 To Users Dear user, thank you for choosing XAG products. For safety reasons and the best experience possible, XAG recommends that you read through the User Manual and Disclaimer in this document before attempting to use the Smart Battery 2019.
-
Page 3: Product Profile
User Manual Product Profile The Smart Battery 2019 is available in two versions: B12620Q (standard for P20) and B12800Q (standard for P30). Both are compatible with all XAG P-Series Plant Protection UAV Modules. The Smart Battery contains 12 large- capacity lithium polymer batteries, and is integrated with a BMS module. It enables real-time monitoring of voltage, current, and temperature, and also features charging protection. - Page 4 User Manual Battery Preheating Press and hold the power button for 5 seconds when the battery is OFF until a beep is heard from the battery and the status indicator is on. The pre-heating of the battery will start and the battery will turn off automatically after heating.
-
Page 5: Technical Specifications
Charging temperature: 10 - 40 °C Capacity: Storage temperature: -10 - 30 °C 14000mAh/620Wh (B12620Q) 18000mAh/800Wh (B12800Q) Weight: Approx. 4.6 kg (B12620Q) Rated output: 44.4 V /70A( B12620Q ) Approx. 5.4 kg (B12800Q) 44.4 V /80A( B12800Q ) 183*137*277 mm (B12620Q) Dimensions: 183*137*302 mm (B12800Q) - Page 6 • It is strictly forbidden to use batteries other than those provided by XAG. For replacement, please contact the after sales or designated dealers of XAG. The user shall bear the responsibility for battery accidents, flight failures or other accidents caused by the use of batteries not provided by XAG.
- Page 7 This does not mean that the contents of this Disclaimer are necessarily invalid. 9. To the extent permitted by law, XAG has the final right to interpret and modify the above terms. XAG has the right to update, modify, or terminate these terms through its official website, the “Product Manual/ Operation Manual”, online APP and other means without prior notice.
- Page 8 All information of this User Manual (including but not limited to any text description, illustrations, photos, methods and processes, etc.) belongs to XAG Co., Ltd. and is protected by copyright law. Without written authorization, no individual or institution is allowed to reproduce, extract, translate, distribute or otherwise reproduce or quote any content hereof.
