- Page 1 Quick Reference Guide Droplet + SMA for Flexible Exports (SA) For SA Power Networks Flexible Exports Prepared by: SwitchDin Pty Ltd 91 Parry Street Newcastle West 2302 Document Number: QRG-SMA-1 Quick Reference Guide Revision: Issue 1.0...
- Page 2 ❑ SMA Sunny Boy 3.0-6.0 ❑ Any Compatible Smart Meter ❑ SwitchDin Residential Droplet ❑ GPO for SwitchDin Droplet ❑ Sets of cables (ethernet & ethernet to USB adaptor) ❑ SwitchDin App: www.switchdin.com/app 2. Onsite, wire up Smart Meter on grid or load configuration. Refer...
- Page 3 4. Wiring the droplet to the inverter Follow one of the processes below 4.1. SMA Energy Meter OPTION 1 : Direct connect between inverter and meter Connect the SMA Energy Meter Connect the inverter to the Connect the droplet to the to the inverter via ethernet droplet via wifi router via ethernet or WiFi...
- Page 4 Eastron RJ45 cable + RS485 to USB converter Serial Connection: 1. Use the cable provided by Eastron meter 2. Match and connect the pin between the Eastron Meter and the RS485 to USB converter. Output Signal Full Duplex Half-Duplex connection connection T/R+ TXD(A+)
- Page 5 5.2. SMA Energy Meter (ONLY FOR OPTION 2) 6. Scroll down and look for SMA 7. Click “Select meter role to…“ dropdown Speedwire Energy Meter list and select 7.1. Grid meter role – for grid meter configuration 7.2. Load meter role – for load meter configuration 8.
- Page 6 5. Click the “Select meter role to con…” drop down 7. Click back on the top left corner and select and select “Grid meter role” or “Load meter role” “Manual” discovery 6. Click the configure button (blue hammer and 8. Search “Site Aggregates”, and click ‘+’ spanner) 5.4.
- Page 7 Power WIFI WiFi No Wi-Fi Wi-Fi connected Weak Wi-Fi signal Configure via iNet Internet No Internet Internet connected SwitchDin app Cannot see Connected to SDin SwitchDin comms SwitchDin SwitchDin Devs Devices attached No devices Devices detected Warranty claims & support: support@switchdin.com...
