USER'S MANUAL
ITEM NO.: X-ERIFT 2500 INTERVAL
PLEASE READ ALL INSTRUCTION IN THE OWNER'S MANUAL
CAREFULLY BEFORE ASSEMBLY AND USE THE TREADMILL.AND
KEEP IT FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2500 INTERVAL and is the answer not in the manual?

Questions and answers

Marlon Flores
June 18, 2025

My x-erfit 2500 interval does not turn on the control panel only the main power source

User image 68531c707742a
0

Related Manuals for x-erfit 2500 INTERVAL

Summary of Contents for x-erfit 2500 INTERVAL

  • Page 1: Content

    USER'S MANUAL ITEM NO.: X-ERIFT 2500 INTERVAL PLEASE READ ALL INSTRUCTION IN THE OWNER'S MANUAL CAREFULLY BEFORE ASSEMBLY AND USE THE TREADMILL.AND KEEP IT FOR FUTURE REFERENCE.

  • Page 2: Table Of Contents

    CONTENT -------------------------------------------------------------------------------------------------------------------------------- CONTENT ----------------------------------------------------------------------------------2-3 IMPORTANT SAFETY PRECAUTIONS -------------------------------------------------------------------------------------------------3-6 ASSEMBLY INSTRUCTIONS ------------------------------------------------------------------------------7 FOLDING & UNFOLDING INSTRUCTIONS ----------------------------------------------------------------------------------------------------------8 GROUNDING METHODS -------------------------------------------------------------------------------------------------------------9-14 OPERATION GUIDE --------------------------------------------------------------------------------------------------------------14 SAFETY EXERCISES -----------------------------------------------------------------------------------------------------------15 WARM-UP EXERCISES --------------------------------------------------------------------------------------------16 MAINTENANCE INSTRUCTIONS ----------------------------------------------------------------------------------------------------------------17 BELT ADJUSTMENT -------------------------------------------------------------------------------------------------------------18 EXPLODED DRAWING -------------------------------------------------------------------------------------------------------------------------19-21 PARTS LIST ERROR CODE AND SIGNIFICANCE-----------------------------------------------------------------------------...

  • Page 3: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS WARNING: Before starting any exercise program, consult with your physician or health professional， especially the person who is above 35 years old people or has some health problems before. We take no responsibility for any troubles or hurt due to above reasons. Don't power on until you finish assembling the treadmill.

  • Page 4: Assembly Instructions

    16. The treadmill maximum user weight is 130kgs. 17. Please do not overuse the treadmill so can avoid any injury and do not use incorrect way for your safety. 18. When the treadmill is not being used, please keep the safety pull pin in the safety place to avoid the other use.
  • Page 5 STEP 1：According to the following steps, lift up the computer bracket. Be careful not to damage the cables when folding. STEP 2：Secure the treadmill with Bolt M10*15 (D23),M10*55(D24) and Washer (D7).
  • Page 6 Step 3:Attach the front cover L(B26)&R(B27) to the base frame with bolt (D40). Step 4： Put on the safety key (C15),MP3 line(C29),Bottle cup(B28) and plug in the power line(C19) ATTENTION: Must confirm complete assembly as required above and lock all bolts. Do the following operations after checking everything is OK.

  • Page 7: Folding & Unfolding Instructions

    Folding instruction Lift up the deck and push forward until you hear "click" that made by hydraulic cylinder, meaning it is locked into position. Unfolding instruction Push the safety sleeve with your foot lightly and pull down the machine at the same time as the arrow direction.

  • Page 8: Grounding Methods

    Grounding Methods This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

  • Page 9: Operation Guide

    Operation Guide WINDOW DISPLAY 1.1. 1.2. START Normal start after 5 seconds countdown 1.3 PROGRAM 1 manual mode，15 pre-set programs, 3 users, 1 body fat program 1.4. SAFETY LOCK FUNCTION The window shows"---" when take away the safety lock and the treadmill will stop quickly with "didi" alarm noise.
  • Page 10 1.5.3 “MODE” BUTTON When the treadmill is not running, press this button to choose countdown modes:”H-1”,”H-2”,”H-3”;:H-1” is the time countdown mode, and “H-2” is the distance countdown mode, “H-3” is the calorie countdown mode; press the “SPEED+/-” or “INCLINE+/-“button to adjust the data.
  • Page 11 Display the incline 1.6.6 PULSE Display pulse data 1.6.7 ALL WINDOW DISPLAY DATA RANGE TIME：0:00 – 99.59(MIN) DISTANCE: 0.00 – 99.9(KM) CALORIES: 0.0 – 999 (C) SPEED: 0.8-20.0(km/h) PULSE: 50 – 200 (BPM) INCLINE：0 – 15 1.7 PULSE FUNCTION When the treadmill is running, hold the hand pulse about 5 seconds, it will display pulse data. The pulse data range is 50-200 times/ minute.
  • Page 12 1.9 Manual model operation 1.9.1 Press start key, time count down 5 seconds, then treadmill will start to work with initial speed 0.8km/h 1.9.2 Press speed +/-, you can adjust the speed 1.9.3 Press incline+/-, you can adjust the incline 1.9.4 Press stop, you can stop treadmill at working state 1.9.5 Press quick speed key, you can quickly adjust the speed you want 1.9.6 Press quick incline key, you can quickly adjust the incline you want...
  • Page 13 Age 10------99 Height 100----200 Weight 20-----150 FAT ≤19 Under weight FAT = (20---25) Normal weight FAT = (25---29) Over weight ≥30 Obesity 1.12 User Program Besides 15 pre-set programs, there are 3 user-defined programs, each user program has 16 segments, and the running time of each user’s program is equal.

  • Page 14: Safety Exercises

    SAFETY EXERCISE Please consult professional staff before exercise. They can help recommend exercise rate/intensity and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular Heartbeats, short of breath, dizziness or other unwell, please stop immediately! And consult professional before you want continually to do exercise.

  • Page 15: Warm-Up Exercises

    Warm-up Exercise It is better to do some warm-up exercise. Warm the muscle easy stretch, so use 5-10 mins to warm-up. Then stop and according below method to do stretch exercise for five times, and each foot do 10 seconds or more every time. After running, do those stretch exercises again 1.

  • Page 16: Maintenance Instructions

    Maintenance Instruction WARNING：Please make sure you pull out the treadmill's power plug before cleaning or maintaining the product. CLEANING：General cleaning of the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.

  • Page 17: Belt Adjustment

    Belt Adjustment Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviation. f the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill run, observe the running belt deviation.

  • Page 18: Exploded Drawing

    Exploded Drawing Parts list...

  • Page 19: Parts List

    A Welding parts Description Specification Main frame Base frame Left upright tube Right upright tube Computer bracket Incline bracket Filter bracket Running board support tube B Plastic parts Description Specification Console left cover Console right cover Console bottom panel Console chip set B3-1 Overlay B3-2...
  • Page 20 Bottle EVA cushion Bookcase C Electric and drive parts DC motor Controller Front roller Rear roller Motor belt 210-J7 Running belt Running board Incline motor Handle pulse left keyboard Handle pulse right keyboard Safety key Filter Inductor Cylinder Power line Overload protector Power switch Single line...
  • Page 21 Round head hex bolt M8*60 Round head hex bolt M8*20 Spring washer Round head hex bolt M10*20 Round head hex bolt M8*45 Bolt M5*8 Round head hex bolt M10*15 Round head hex bolt M10*55 Round head hex bolt M10*65 Round head hex bolt M8*45 Round head hex bolt M8*50...

  • Page 22: Error Code And Significance

    Error code and significance Fault Code Fault Description Fault Processing The controller is not working and going into fault. The machine can not run, the computer shows fault code “E1”, and the buzzle will ring three times. Communication abnormal: The control and computer has abnormal communication after Possible Reasons: Communication obstructed between controller...
  • Page 23 Remark: After replacing lower controller and replacing the parts for E5/E6 issue, please follow steps below to re-calibrate the machine 1.1 Press PROG and SPE+ KEY at the same time and POWER UP or reset SAFETY KEY entry. After entry, LCD will run display testing, all segment will lights up to show according.
