AD8 A/D Converter
ROSTEC AD8
8-channel high performance A/D Converter
Front panel quick guide
Status menu (default start-up):
The operational status is displayed at the four corners of the display. The principle is "What You See Is What You Get"
Call menu cursor
Return to status menu
Set value up or down
1
Advertisement
Table of Contents
Related Manuals for ROSTEC AD8
Summary of Contents for ROSTEC AD8
- Page 1 AD8 A/D Converter ROSTEC AD8 8-channel high performance A/D Converter Front panel quick guide Status menu (default start-up): The operational status is displayed at the four corners of the display. The principle is “What You See Is What You Get”...
- Page 2 AD8 A/D Converter How to change parameters (example): Step 1: For example, you start with this status menu: Step 2: Press the MENU button Observe that the setting cursor appears. The arrows indicate that you now can change the value at the cursor position with the arrow buttons.
- Page 3 AD8 A/D Converter Step 4: Press the UP ARROW button Observe that the parameter changes from 48.000 to 88.200 Step 5: Press the RETN button All done. Remember that pressing RETN will always bring you back to the status menu SYNC: INTERNAL: The unit runs on its internal high grade clock oscillator.
