Altwork SIDE-BY-SIDE MONITOR Assembly Instructions Manual

Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

mount
SIDE-BY-SIDE MONITOR
Assembly Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIDE-BY-SIDE MONITOR and is the answer not in the manual?

Questions and answers

Related Manuals for Altwork SIDE-BY-SIDE MONITOR

Summary of Contents for Altwork SIDE-BY-SIDE MONITOR

  • Page 1 SIDE-BY-SIDE MONITOR Assembly Instructions...
  • Page 2 The new way to work Tools & Hardware Side-by-Side Mount (1) Stand-offs 14mm (8) Thumb Screw (8) Stand-offs 30mm (8) Phillips Screw (5) Dual Monitor Power Cord (1)
  • Page 3 The new way to work Preparation STEP 1: STEP 2: Place the monitor facedown on a soft surface. Then place the monitor mount on Use four thumb screws to attach the monitor to the mount. top of the monitor, align the holes and ensure the edge of the monitor is in the middle of the mount.
  • Page 4 The new way to work Align The Monitors STEP 3: STEP 4: Attach the second monitor To check for levelness, stand the monitors up as shown. Look to make sure the monitors line up with each other. If the monitors are not aligned, loosen the screws and shift the monitor mount to the right or left then retighten screws.
  • Page 5 Now rout the cords and make sure all signal and power wires are placed in a Tip: It is best to have a second person hold the monitor mount while you place way that they will not get pulled during any of the adjustments made to the Altwork the screws.
