- Page 1 MODEL: T23...
- Page 2 Li-Polymer 7.4V 14:1 INTRODUCTION Thank you for purchasing this product,please read this maunal carefully before use and retain it for future reference. 1.Coaxical-rotor design,built-in gyro and unique function of digital speed setting and operation of the helicopter.It is the best choice for beginner. 2.Adopt aluminum alloy outer casing,attractive design and elegant appearance.
- Page 3 PRODUCT/SPARE PARTS INCLUDED IN THIS PACKAGING Main Units & Accessories Main Units & Accessories QT Y ( pc) QT Y ( pc) Description Description Helicopter Remote control Rechargeable battery pack Charge controller Charger Antenna Manual Control stick Indicator Light Power Switch Charging Socket Tail Light Battery Charging Plug...
- Page 4 To meet the different demands from different customers worldwide, two different charging devices have been designed for charging. One is split charging device (1 piece charger +1 piece charge controller), the other one is all-in-one charging device (one charger only)The product is included with either of the two charging devices. User should check the package to confirm which charging device is included before reading the charging method.
-
Page 5: Flight Mode Selection
THE REMOTE CONTROLLER’S PARAMETER SETTING 1. Activate the LCD remote controller Install the batteries into the battery compartment with correct polarity and slide the power switch to “ON” position. The indicator light will start to blink and the signal icon display as“ ”(Pic.5). To activate the remote control, slowly push up the throttle control stick to top and then push it down to the bottom. -
Page 6: Preparation For Flight
Step.2 – ( Setting of the leftward/rightward turning sensitivity) Press the “parameter setting” knob to access the leftward/rightward turning speed setting Display will show the blinking “ FbCS” ( pic. 9 ), turn the “parameter setting” knob , you have entered the left /right turning sensitivity setting interface. Wording “LRCS” is blinking.(pic.10 ) Step.2 A –... - Page 7 OPERATING When the LCD is displayed as pic 5, press "EXIT/LIGHT" to turn on or turn off the searchlight. The light makes the helicopter look more attractive at night flight.
- Page 8 If the helicopter keeps self-rotating in the air even there is no control signal given, you could adjust the gyro regulation button to keep the helicopter balanced. If the helicopter nose is rotating counter clockwise, you could tuning the gyro regulation button to the right.
