Summary of Contents for Major Manufacturing HIT-66-274
- Page 1 1825 VIA BURTON ANAHEIM CA 92806 714-772-5202 / FAX 714-772-2302 EMAIL: MAIL@MAJORMFG.COM WEB: WWW.MAJORMFG.COM INSTRUCTIONS HIT-66-274 TEMPLATE SARGENT “IN” SERIES CYLINDRICAL LOCK WHEN USING POWER TOOLS ALWAYS WEAR EYE AND EAR PROTECTION!!
-
Page 2: Think Safety
Be sure all bits and cutters are sharp and in good condition and all power tools and extension cords are in good working order and properly grounded. AND MOST IMPORTANTLY, BE SURE TO WEAR, EYE AND EAR PROTECTION. Copyright 2016—Major Manufacturing PAGE 1... - Page 3 The lack of bearing surface will cause Shown above is a spade or paddle type the bit to jam. bit. Do not attempt to use this in any drill guide. There is no bearing surface and you will jam the bit. Copyright 2016—Major Manufacturing PAGE 2...
- Page 4 NOTE: The HIT-66 clamps shown are not part of the HIT-66-274 template set and must be purchased as a separate item. Install the drill guide for latch and optional external DPS to the front of the HIT-66 clamps as shown.
- Page 5 Sargent IN Cylindrical Lock install. lock. The HIT-66-274 can be used to do a new install on a blank door, as above, or retro fit an existing cylindrical prep as shown at left. If doing a new install the jig clamps to the door at the desired height and is ready to go.
- Page 6 Drill about 3/16” into a wood door. On a steel door you may need to open the hole into a notch with the use of a file prior to installing the lock. Copyright 2016 PAGE 5 Major Manufacturing Inc PAGE 5...
- Page 7 With a 3/8” twist drill, drill the holes for the thru bolts. Drill top and bottom holes half way from both sides of the door. Pull drill out several times when drilling to remove chips. Copyright 2016 Major Manufacturing Inc PAGE 6...
- Page 8 3/8” hole to 3/4” with the use of a step drill. To drill the wire raceway, remove the drill plate on the INSIDE of the door and replace with the auxiliary raceway drill guide. Copyright 2016 Major Manufacturing Inc PAGE 7 PAGE 7...
- Page 9 Drill the raceway hole to the cross bore. The drill bit must be pulled completely out of the drill bushing when drilling to clear chips. This is important when drilling this deep of a hole. Copyright 2016 Major Manufacturing Inc PAGE 8...
- Page 10 Visit our web site at www.majormfg.com for more information on lock templates and a complete listing of all the tools we have available. While there, sign up for our newsletter and we will email new product information directly to you. PAGE 9 Copyright 2016—Major Manufacturing Inc...
