Summary of Contents for ADX DualSense APS5CS22
- Page 1 DUAL CHARGING STATION INSTRUCTION MANUAL APS5CS22 NOT INCLUDED PS5® DualSense™ Wireless Controller...
-
Page 3: Table Of Contents
Contents Safety Warnings ....................4 Unpacking ....................... 6 Product Overview ................... 7 Top View ..........................7 Side View ..........................7 Charging the Charging Dock ................. 8 Charging Indicator ..................9 Maintenance ....................10 Hints and Tips....................10 Specifications ....................11... -
Page 4: Safety Warnings
Safety Warnings • Do not drop the product or • Read all the instructions carefully subject it to undue shock. before using the unit and keep them for future reference. • This product contains small parts. Keep out of reach of children. •... - Page 5 This unit is designed for indoor use only. This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth. AC voltage: This symbol indicates that the rated voltage marked with the symbol is AC voltage.
-
Page 6: Unpacking
Thank you for purchasing your new product. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. -
Page 7: Product Overview
Product Overview Top View LED Charging Indicators (Charging Dock A) LED Charging Indicators (Charging Dock B) Charging Connector Connecting Cable Side View Charging Dock A Charging Dock B... -
Page 8: Charging The Charging Dock
Charging the Charging Case 1. Connect the Charging Station to your PS5™ console (not included) or USB charging device (not included). The indicators show blue and then red light Charging Station PS5™ console USB Charging Device (not included) (not included) Use a standard USB adaptor (5V, 2A or above) for charging. -
Page 9: Charging Indicator
Charging Indicator Charging indicator Status Light up red Charging Light up blue Fully charged Fast flash in red Charging over current • Remove the Controller(s) from the charging dock and unplug the USB cable from input and then re-connect. • It takes 4 hours (approximately) to fully charge an official PS5™... -
Page 10: Maintenance
Maintenance Ensure the USB cable is fully unplugged from the unit before cleaning. • To clean the unit, wipe the case with a slightly moist, lint free cloth. • Do not use any cleaning fluids containing alcohol, ammonia or abrasives. •... -
Page 11: Specifications
Specifications Model APS5CS22 DC 5V Input Voltage DC 2A (Max.) Input Current 750 mA (Max.) Single Group Conductive Charging Current 1500 mA (Max.) Dual Group Conductive Charging Current 22.45 mm × 63.65 mm × 47.1 mm Dimension (L × W × H) (cable excluded) Net Weight Charging Station: 163 g... - Page 12 The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
