Components:
Legs
x 4
'Long Horizontal'
x 8
'Short Side'
x 8
•
Layout the four legs.
•
Join each pair together with the 'Long Horizontal'
parts to form the two main frame sections of the
overall frame.
•
Place one of the main frame sections up against a wall
(for stability) and attach the 'Short horizontal' parts. It
will be unstable at this stage due to the un-tightened nuts
and bolts.
•
Attach the other main frame in a similar manner forming
the cage.
•
Nuts / Bolts &
•
Black caps
•
4 Tier
Please read all before you begin.
Tip your nuts, bolts and caps into
one of the seed trays.
Throughout initial assembly the
nuts and bolts need only be finger
tight. The structure will be squared
out on a level floor later on.
In this model the nuts need to face
away from the frame to allow for
the black caps to be inserted in the
final stages.
PTO
Aluminium Seed Tray unit.
INSTRUCTIONS
Advertisement
Summary of Contents for The Greenhouse People 4 Tier
- Page 1 4 Tier Aluminium Seed Tray unit. INSTRUCTIONS Please read all before you begin. Components: • Tip your nuts, bolts and caps into one of the seed trays. Nuts / Bolts & Legs • Black caps Throughout initial assembly the nuts and bolts need only be finger tight.
- Page 2 Check that the frame is square, diagonal measurements should be equal. Adjust If necessary. • Push the 'black caps' onto each nut. If you would like a brochure containing our extensive product range then please contact us at, ‘The Greenhouse People’, Unit 9B Blythe Park, Cresswell Lane, Cresswell, Stoke—On—Trent. Staffs. ST11 9RD.
