Avee Bose QC35 Quick Start Manual

Problem solving

1. Bad ATC reception – reading you two
The most common problem for fresh aviators, is that the microphone is placed too far away
from the mouth. This makes the intercom and radio pick up little or no audio from you, and
this will of course lead to problems. Keep the microphone approx. 6mm from your mouth at
all times – and let the flat side & white dot face your mouth.
A good basic rule is that when you hear yourself well in the intercom, ATC and other aircrafts
hear you well. However – the aircraft intercom and the radio are usually two separate and
independent systems and they behave differently.
2. Intercom squelch setting.
On most GA aircrafts intercoms, the squelch is set manually.
If the first part of the word is clipped – or the intercom squelch is not opening at all – this
must be corrected by adjusting the squelch threshold in the aircraft.
3. Audio in left ear only:
The Avee microphone is set to stereo mode. Set to mono mode to fix this issue.

TECHNICAL SPECIFICATIONS

Document information
Document version:
Valid for products:
Connectors
Headphone connector:
Bose ™ QC35 ™
Connector to aircraft interface cable
Bias voltage accepted:
Microphone
Type: Noise reduction
Output signal: Adjustable with potentiometer
Output signal level: Adjustable between 0.5V RMS and 2V RMS
Default output level: 0.7 V RMS @ 1khz / 74dB SPL
Headphone speaker
Audio level: Adjustable with potentiometer (10-100%)
DISCLAIMER
Avee is an unlicensed third-party accessory and is not affiliated with Bose
Bose or Sony does not approve or endorse the products manufactured by Avee.
™ ™
4.4 - October 26 2021
Avee35 NG (for Bose ™ QC35 ™ ) ,
2.5mm - four pin audio
USB C
9-16VDC
™ or Sony ™ .
The Avee Aviation Microphone
Setup Instructions & User Guide
Tusen takk (which is thank you in Norwegian ) – for purchasing the Avee aviation
microphone ! We hope it gives you as much joy flying with it – as it gives us
designing it - and flying with it!
In this leaflet we will show you how to prepare and connect the Avee microphone
to your headset – and how to use it.

How to prepare your headphones

The Avee microphone is using an adhesive magnetic
stripe to attach safely to your Bose ™ or Sony
This solution makes it easy to attach and detach the
Avee microphone from the headphone in seconds, and
the Avee microphone stays safely in place whenever it is
connected to the headphones.
Please follow these instructions to install the magnetic
stripe properly to your headphones.

Step 1:

Using the cleaning wipe supplied, clean the base of your headphones
including the area surrounding the input jack. Ensure that you remove any residue
that is adhered to the headphones. Let dry for a minute or two.
Bose ™ QC35 Edition
™ headset.
E
