Summary of Contents for DFA 127

Page 1 DFA 127 Translation of the original manual...
Page 3: Table Of Contents
Table of contents Table of contents Glossary ................................1 Safety................................. Presentation of warning signs....................... Intended purpose of use ........................General hazards ........................... State of technology ..........................Spare parts and liability ........................2 General information ............................Purpose and use of the instructions ..................... Copyright ..............................
Page 4: Glossary
Glossary Glossary Control panel BDE-D Bedienungseinheit mit Display BDE-M Control panel mechanical Control unit with toggle switch BDI-M Print for mechanical control unit Power supply Key pivot contact Control unit 4 / 28 BAL_DFA_127_EN_1V0_OEM_102-127401806...
Page 5: Safety
Safety Safety Presentation of warning signs Various symbols are used in this guide for easier understanding: NOTICE Useful advice and information to ensure correct and efficient workflow of the system. IMPORTANT Specific details which are essential for trouble-free operation of the system. IMPORTANT Important details which must be read for proper function of the system.
Page 6 Safety The specific safety instructions in the other sections of this manual must also be observed. IMPORTANT The country-specific regulations must be observed and complied with! IMPORTANT To avoid malfunctions, moving objects such as flags or parts of plants must not be allowed to enter the detection range of the sensors.
Page 7 Safety CAUTION Risk of bruising and severing of limbs! a) If the system moves, careless behaviour can lead to serious injuries to limbs or severance of limbs. ð Do not reach in when parts of the system are moving. ð Keep a distance when parts of the system move. ð...
Page 8: State Of Technology
Safety DANGER Danger to life due to non-functioning safety devices of the fire protection system! a) If safety devices of the fire protection system do not function properly, there is a risk of serious or fatal injuries. ð Never disconnect the fire protection system from the power supply overnight. ð...
Page 9: General Information
General information General information Purpose and use of the instructions These instructions are an integral part of the system and enable efficient and safe handling of the sys- tem. In order to ensure proper functioning, the instructions must be accessible at all times and kept in the immediate area of the system.
Page 10: Target Groups
General information Target groups CAUTION Risk of injury if personnel are insufficiently qualified! If unqualified personnel work on the system or are in the danger zone of the system, dangers may arise which can cause serious injuries and considerable damage to property. a) All work must be carried out by qualified personnel only.
Page 11: Description
Description Description Overview The swing door operator DFA 127 (hereinafter referred to as operator), is a self-monitored, micropro- cessor-controlled swing door operator. It can be used in a multitude of ways thanks to its special and additional functions. The microprocessor analyzes the current door position, door speed, and target position and calcu- lates the movement sequence.
Page 12: Types Of Arm
Description Types of arm Power is transmitted from the operator to the door leaf by means of an arm. Depending on the install- ation situation, a standard arm or a sliding arm may be suitable. Standard arms are available in vari- ous lengths to adjust the recess depth.
Page 13: Primary / Secondary Application
Inactive leaf Active leaf For two-leaf fire doors, the mechanical door selector SFR 127 is additionally installed for the inactive leaf and the active leaf. The two operators communicate with each other via an interface so that the safety functions such as reversing and obstacle detection remain in place.
Page 14: Battery Pack (Optional)
Description Electronic BDE-D (2) and/or mechanical control panel BDE-M (4). The electronic control panel can be used to choose between five operation modes and set selected door parameters. – Automatic – Continuously open – One-way – Manual operation – Locked The control panels can be installed with corresponding attach- ments as a flush-mounted (1) or surface-mounted (3) version.
Page 15: Specifications
Specifications Specifications Tecnical data Operating voltage: 230VAC, 50/60 Hz Power consumption: Standby 13 W, rated power 67 W Max. torque: 50 Nm Max. Mass inertia door leaf: 65 kgm Opening angle: 70° - 115° Hold open time 0 to 60 seconds (40 steps) Opening speed: 3 to 20 seconds (40 steps) Closing speed:...
Page 16: Operation
Operation Operation Toggle switch BDI 5.1.1 Control elements and displays 1 Toggle switch BDI 2 Reset button 3 Status display LED 4 Connection for configuration tool Toggle switch BDI Three operation modes can be selected using the toggle switch: Manual operation: The operator works like a door closer.
Page 17 Operation Main menu Button Name Operation Function Display on LCD Automatic button Press button 1 x Automatic operation via sensors Automatic Continuously open Press button 1 x For sliding door operator button and swing door operator: continuously open, sensors disabled Continuously open Press button 2 x or hold it For sliding door operator:...
Page 18: Perform Reset
Operation Button Name Operation Function Display on LCD Enter button Press button 1 x to go to Select menu item, confirm Opening speed the next sub menu. entry 10 20 30 40 Plus button Press button 1 x to go Navigate downwards in the Parameter down.
Page 19: Display System Information
Button Operation Function Display on LCD The connection has been established DFA 127 V2.21 Basic operator 5.2.3 Display system information Information about the door system, such as software version, door type, or servicing status, can be shown on the display.
Page 20: Set Parameters
Operation Enable control lock with key Step Requirement Operation Function Display on LCD The desired Enable/disable the con- No settings can be made operation trol lock with the key on the control panel BDE- mode is set. Automatic 5.2.5 Set parameters IMPORTANT With the type "low energy", the parameters can only be changed by qualified personnel.
Page 21: Description Of Parameters
Operation Step Button Operation Function Display on LCD Press button 1 x Check settings (door opens and closes again) Press button 1 x Leave sub menu Parameter Driving cycle Press several times to jump to the beginning of the sub Time delay open menu Operator...
Page 22 Operation OPERATOR → opening angle The opening angle is determined during the teach-in run and corres- ponds to the value 40. 0 = minimum opening angle 40 = maximum opening angle – DIN: min. 95° 22 / 28 BAL_DFA_127_EN_1V0_OEM_102-127401806...
Page 23: Malfunctions
Malfunctions Malfunctions Status displays Malfunctions are shown on the LCD display. If there is a malfunction, the display changes between light and dark, as shown in the following figure. Multiple malfunctions can be displayed, e.g. 1 / 2. If there are multiple malfunctions, they are numbered as follows. AKI >...
Page 24 Malfunctions Malfunction Cause Measure Personnel Malfunction message still present Malfunction could not be rec- Qualified personnel are Qualified person- after restart. tified. required to rectify the mal- function. Show and read out sys- System operator tem information about the door on the display. Display system informa- tion [} 19] Notify service center.
Page 25: Maintenance And Servicing
Maintenance and servicing Maintenance and servicing Test log book The scope, result, and time of testing and servicing must be documented in a test log book and ser- vice book. The system operator must store the test log book until the next testing and servicing. Testing is carried out by qualified personnel using the manufacturer's testing instructions.
Page 26: Spare Parts And Wearing Parts
Maintenance and servicing System operator tasks Task Personnel When? Entered in test log book? Maintenance and cleaning System operator Weekly, or as required of the sensors for safety and triggering Function and safety check System operator Monthly Tasks of qualified person Task Personnel When?
