- Page 1 USER MANUAL MODELS: VA-101P12 Description 12V DC Power Supply VA-102P12 Description 12V DC Power Supply P/N: 2900-300200 Rev 4...
-
Page 3: Table Of Contents
Defining the VA-102P12 12V DC Power Supply Connecting the VA-101P12, VA-102P12 Technical Specifications Figures Figure 1: VA-101P12 5-Output 12V DC Power Supply Figure 2: VA-102P12 10-Output 12V DC Power Supply Figure 3: Connecting the VA-101P12, VA-102P12 Description VA-101P12, VA-102P12 – Contents... -
Page 4: Introduction
Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our... -
Page 5: Getting Started
Achieving the Best Performance To achieve the best performance: Use only good quality connection cables (we recommend Kramer high- performance, high-resolution cables) to avoid interference, deterioration in signal quality due to poor matching, and elevated noise levels (often associated with low quality cables) ... -
Page 6: Recycling Kramer Products
Requirements for EMC standard which is required when accessory devices are used at locations where medical personnel and patients are present. In this environment, the VA-101P12 and the VA-102P12 can be added to the system ONLY if the connecting equipment has been evaluated and meets the IEC 60601-1-2 EMC standards. -
Page 7: Overview
The VA-101P12 and VA-102P12 are 5- and 10-output power supplies used for powering 12V DC powered devices. The VA-101P12 can supply a maximum of 1A of current to each of five devices for a total of 5A current. The VA-102P12 can supply a maximum of 1A of current to each of ten devices for a total of 10A current. -
Page 8: Defining The Va-102P12 12V Dc Power Supply
Illuminates when the power is turned on 12V DC Output Connectors Supplies 12V DC to up to 10 devices Power Connector, Fuse and Connects to the mains supply and switches the Switch device on and off VA-101P12, VA-102P12 - Overview... -
Page 9: Connecting The Va-101P12, Va-102P12
To connect the VA-101P12, VA-102P12 as illustrated in the example in illustrates the VA-101P12. The VA-102P12 has 10 outputs. 1. Connect the 12V DC outputs to up to five (for the VA-101P12) or ten (for the VA-102P12) devices. 2. Connect the AC power cord to the AC receptacle and turn ON the power to the VA-101P12, VA-102P12. -
Page 10: Technical Specifications
Technical Specifications OUTPUTS: 5 (VA-101P12) and 10 (VA-102P12) 12V DC @1A max. current per output INDICATOR: Power ON LED POWER CONSUMPTION: 100-240V; 1.3A (VA-101P12), 2.3A (VA-102P12) OPERATING 0° to +40°C (32° to 104°F) TEMPERATURE: STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F) - Page 12 SAFETY WARNING Disconnect the unit from the power supply before opening and servicing For the latest information on our products and a list of Kramer distributors, visit our Web site to find updates to this user manual. We welcome your questions, comments, and feedback.
