Page 1 Installation & Operation Manual January 2022 Rev. 2.04...
Page 2: Table Of Contents
TABLE OF CONTENTS LIST OF TABLES AND ILLUSTRATIONS ................3 1. INTRODUCTION........................1 2. HOW TO USE THIS MANUAL .....................2 3. GETTING STARTED ......................3 Description ..........................3 Power Requirements .......................5 Installation ..........................5 Power-up Sequence .........................7 Start-up Programming ......................7 4. FRONT PANEL ........................11 5.
Page 3: List Of Tables And Illustrations
Figure 2 Programming Cable Wiring ...................4 Figure 3 ProTalk Plus Wiring Diagram ..................5 Figure 4 Alarm Input Connection ....................6 Figure 5 ProTalk Plus Front Panel ..................... 11 Figure 6 Activating an Annunciator Panel ................. 42 Figure 7 Concentrating Remote Alarms ..................43 Figure 8 Option 004 Connections ....................
Page 5: Introduction
Basic Operation The ProTalk Plus model B1290 is a device used to monitor alarms at an unattended site. If an alarm occurs, such as building intrusion, power failure, high or low temperature or equipment failure, the B1290 automatically dials out on the telephone line.
Page 6: How To Use This Manual
PAGE 2 HOW TO USE THIS MANUAL 2. HOW TO USE THIS MANUAL This manual is organized in such a way that, if you want the B1290 to function with its default settings as a simple telephone dialer, you only need to read the first two chapters of the manual covering the physical installation, basic programming and operation.
Page 7: Getting Started
The B1290 is housed in a metal case with plug-in terminal blocks and jacks for field wiring. Table 1 and Figure 1 show the connection points to the B1290. Figure 3 shows how wiring connections are made to the unit. Table 1 ProTalk Wiring Connections RADIO...
Page 8 SERIAL (RS232) FRONT SIDE (VERSION 1) PHONE LINE RADIO POWER EXPANDER SERIAL (USB) FRONT SIDE (VERSION 2) ALARMS RELAYS VOLUME PROGRAM BACK SIDE Figure 1 Connector Locations ProTalk Plus (Version 2) ProTalk Plus (Version 1) Figure 2 Programming Cable Wiring...
Page 9: Power Requirements
GETTING STARTED PAGE 5 ProTalk Plus Figure 3 ProTalk Plus Wiring Diagram Power Requirements The B1290 will operate from a supply of +11.5 VDC to +28 VDC (Version 1) or +10 VDC to +30VDC (Version 2). The typical current requirement is 100 mA plus 10 mA per relay. Each expander uses an additional 60 mA plus 10 mA per active relay.
Page 10 PAGE 6 GETTING STARTED ProTalk Plus Figure 4 Alarm Input Connection Relays Four form C relay outputs are available, rated for 1.0 A at 30 VDC, or 0.3 A at 120 VAC. Connect external devices to the contacts on the RELAY connector. When connecting to larger loads, connect an interposing relay between the B1290 and the load.
Page 11: Power-Up Sequence
All the expander’s programmed parameters, including the voice messages, are stored in the main ProTalk Plus and are downloaded on power-up. The expander database will be automatically transferred from the ProTalk Plus if an expander address is changed or an expander is replaced.
Page 12 PAGE 8 GETTING STARTED than most people think, and there is no need to rush when entering the code. If you enter the digits too fast, the telephone will only recognize one . You may get an Error message if this happens or else the B1290 will ignore the entry and wait for another .
Page 13 GETTING STARTED PAGE 9 B1290: "Alarm Two is... " Enter the voice message associated with the second alarm point, e.g. intrusion alarm. YOU: B1290: "beep-beep" YOU: "Intrusion Alarm" B1290: "Alarm Two is Intrusion Alarm" YOU: Next B1290: "Alarm Three is... " Repeat the above steps until all the alarm points have been programmed.
Page 14 PAGE 10 GETTING STARTED The B1290 is prompting you for a third telephone number to dial if it cannot get an acknowledgement from the first two. Continue entering telephone numbers up to a maximum of twenty. If you are not using twenty numbers, enter the Quit code ( ) at the prompt.
Page 15: Front Panel
The front panel of the B1290 is shown in Figure 5. The description of the front panel indicators will assist you in verifying the correct operation of the unit. Figure 5 ProTalk Plus Front Panel Alarm LEDs The Alarm LEDs light when the associated alarm input is in the alarm state. Unacknowledged alarms will be flashing and any that have been acknowledged will be on solid.
Page 16 PAGE 12 FRONT PANEL during pulse dialing. Version 1: The Run LED will be on steady when the B1290 is operating correctly; it will flash if an error condition is present. Version 2: The Run LED will flash when the B1290 is operating correctly. Ring When ringing is detected on the telephone line, the Ring LED illuminates.
Page 17: Operation
OPERATION PAGE 13 5. OPERATION This chapter gives a detailed description of exactly how the B1290 will operate after the start-up programming has been completed. Parameters which may be altered are pointed out, with reference to the appropriate Program Code section.
Page 18: Changing Telephone Directories
PAGE 14 OPERATION Enter Program Code. You may then program the B1290 from your telephone, the same as you would from a local programming phone. The B1290 will hang up whenever it has waited for more than ten seconds without receiving a DTMF code. Changing Telephone Directories Telephone directories can be changed remotely without entering the programming mode.
Page 19 OPERATION PAGE 15...
Page 20: Program Summary
PAGE 16 PROGRAM SUMMARY 6. PROGRAM SUMMARY The codes used in the main programming menu are given as a summary below. Voices (page 16) Directories (page 17) DTMF Codes (page 20) Timer Configuration (page 21) I/O Configuration (page 22) System Settings (page 25) Expanders (page 26) Reset Database (page 27) Audio Levels (page 27)
Page 21: Program Codes
PROGRAM CODES PAGE 17 7. PROGRAM CODES How to Enter the Programming Mode To begin programming, you must hear the prompt Enter Program Code from the B1290. One way to get to this prompt was discussed in the chapter on Getting Started. After you have entered the initial voice messages, telephone numbers and an Acknowledge Code, the B1290 will prompt you to begin programming.
Page 22: Directories
PAGE 18 PROGRAM CODES Entering Next advances to the alarm message section and the first alarm message will be spoken B1290: "Alarm One is …" YOU: Record Quit Enter/Next If you enter messages for all eight alarms, the B1290 will automatically exit to the Enter Voice Code prompt. Default: empty Record Relay Messages Record the voice messages associated with each relay.
Page 23 PROGRAM CODES PAGE 19 3. If there is a Directory Control Code (method 2): If the alarms are assigned only to Directory A and Directory C, when the Directory Control Code is received, all of the alarms that are assigned to Directory A will switch to use Directory B and all of the Alarms assigned to Directory C will switch to use Directory D.
Page 24 PAGE 20 PROGRAM CODES Change This Line To change the line, a complete sequence of commands and values must be entered. For example, if the setting was to be changed so that the wait time was 5 seconds instead of 3, the entry would be: YOU: Change this line B1290:...
Page 25: Dtmf Codes
PROGRAM CODES PAGE 21 such as paging terminals. The #, or pound digit, has no special meaning and is dialed as a pound. When calling a paging terminal or someone who cannot acknowledge the call from their phone, it may be useful to wait before starting the next telephone call.
Page 26: Timer Configuration
PAGE 22 PROGRAM CODES "Off Code is ... " YOU: ( x = 1 to 8 DTMF digits, # = clear ) Default: empty Alarm On/Off Output Codes These codes are used to control DTMF-operated devices at the receiving end when an alarm is reported. A typical example would be sending a message to a pager with a digital display.
Page 27 PROGRAM CODES PAGE 23 last one, “Times A”, it will go back to the Enter Program Code prompt. Rings Before Answering When the B1290 is dialed, this parameter sets the number of times it will let the telephone ring before it answers. B1290: "Answer rings is ...
Page 28: I/O Configuration
Note: A latched alarm should provide a short, predictable pulse to the input of the ProTalk Plus; otherwise, it may have to be acknowledged twice. If the alarm is acknowledged while the input is active, the alarm will not be cleared and new alarms will not activate that input.
Page 29 Setting the time to zero will make the relay an On/Off type of relay. Setting the timer with the # digit makes the relay operate as a ‘special function’ output. This function is only available on the main ProTalk Plus unit and not on the expanders.
Page 30: System Settings
PAGE 26 PROGRAM CODES B1290: "Relay One On Timer is _ _ seconds" YOU: Not timed, uses the Relay Off Code (x = 1 to 199 ) (Special function ) Default: 0 (On until turned Off) System Settings When you enter Program Code 6, the B1290 will automatically cycle through the following parameters as you hit Enter ( ).
Page 31: Expanders
PROGRAM CODES PAGE 27 Acknowledge Request This setting enables or disables the B1290’s voice prompt Enter Acknowledge Code. If the alarm announcement is over a public address system, for example, acknowledgment is not possible. The B1290 would be programmed for automatic acknowledge (see Interval Timer B, Program Code 4) and the request for an Acknowledge Code would be disabled.
Page 32: Reset Database
PAGE 28 PROGRAM CODES equipment. B1290: "Expander Site Voice is . . . " YOU: Site voice is not used Site voice is used Next Default: 0 (expander site ID disabled) To program the parameters within the expander, the PGM port on the B1290 is used. Programming is done exactly as though the main unit itself was being programmed, except that the expander number precedes the program code.
Page 33 PROGRAM CODES PAGE 29 YOU: Level setting ( x = 20 to 0 ) Exit Next Default: 0 B1290: "Telephone Code Five is . . . " (Telephone Receive Level) YOU: Level setting ( x = 20 to 0 ) Exit Next Default: 0...
Page 34: Programming Reference
8. PROGRAMMING REFERENCE The ProTalk Plus is capable of performing many functions other than those set by its default values. If you require these extended capabilities, they are accessed through the program codes. If the default operation of the unit as described in the Getting Started chapter of this manual is sufficient, then you may ignore this section.
Page 35 PROGRAMMING REFERENCE PAGE 31 Relay Timer Timebase (Program Code 5.3) Relay On Time (Program Code 5.3) Relay Voice (Program Code 6) Relay Special Functions (Program Code 5.3) 5. Telephone Specific Parameters This section describes the parameters used when the unit is required to transmit alarms or signaling over the telephone system.
Page 36: Programming Examples
PAGE 32 PROGRAMMING EXAMPLES 9. PROGRAMMING EXAMPLES Example 1: Reporting Alarms over Radio and Telephone In this example, assume that your company has a mobile radio system which is monitored by field personnel. Radio operators have DTMF pads on their mics so they can acknowledge an alarm from the B1290. They would like to have the alarm reported over the radio system three times with a 2 minute interval between transmissions, then dialed out over the telephone if it is not acknowledged.
Page 37 PROGRAMMING EXAMPLES PAGE 33 YOU: [RADIO] [VOICE] B1290: Directory A, Line Five is RADIO VOICE YOU: Next B1290: Directory A, Line Six is... YOU: Change ‘beep’ B1290: YOU: [WAIT]120 (seconds) B1290: Directory A, Line Six is WAIT 120 YOU: Next B1290: Directory A, Line Seven is...
Page 38 PAGE 34 PROGRAMMING EXAMPLES B1290: Dial Format is 0 YOU: Next B1290: Squelch is 0 YOU: Enter busy when high B1290: Squelch is 1 YOU: Next B1290: Relay Voice is On At this point you are finished programming and may hang up the telephone. The directory is programmed with the voice message repeated three times on the radio and then once on the phone line.
Page 39 PROGRAMMING EXAMPLES PAGE 35 two directories are programmed. When the Directory Control Code is received, the B1290 is directed to dial from the other directory. The directory may be switched with the Directory Control Code over the telephone, local programming phone, or two-way radio. There are specific rules governing how the alarms can be assigned to directories if the Directory Change Code is used.
Page 40 PAGE 36 PROGRAMMING EXAMPLES B1290: Directory B, Line Three is... YOU: Quit B1290: Enter Directory YOU: Quit The telephone numbers have now been programmed. Now enter the Directory Control Code B1290: Enter Program Code YOU: DTMF Codes B1290: Enter DTMF Code YOU: Directory Control Code B1290:...
Page 41 PROGRAMMING EXAMPLES PAGE 37 In this example, alarms 1 and 2 are connected to intrusion alarm and building high temperature respectively. These are building alarms, and are to dial the building maintenance people at 403-255-9544 and then 403-255-9598. Compressor failure and high tank level are fed to alarms 3 and 4. Since these are equipment problems, operations technicians at 403-255-4437 and then 403-255-9545 are to be alerted.
Page 42 PAGE 38 PROGRAMMING EXAMPLES B1290: Relay Two is... YOU: Quit B1290: Enter Voice Code YOU: Quit B1290: Enter Program Code YOU: Select DTMF Codes B1290: Enter DTMF Code YOU: Select Relay On and Off Codes B1290: Relay One On Code is empty YOU: (pause) Enter On code...
Page 43 PROGRAMMING EXAMPLES PAGE 39 YOU: Send the Relay On Code Ajax Compressor Station; Bypass Valve On (and Alarm - Enter Acknowledge Code). YOU: Send the Acknowledge Code B1290: Ajax Compressor Station; Alarms Acknowledged Example 5: Operating a Radio Pager In this example, when an alarm is received you want to contact the person on call, who is carrying a two-tone radio pager which operates on the company’s private radio system.
Page 44 PAGE 40 PROGRAMMING EXAMPLES YOU: Directory A B1290: Directory A, Line One is... YOU: Change ‘beep’ B1290: YOU: [DIAL]4032559544 [WAIT]4 [DTMF]734 B1290: Directory A Line One is DIAL 4032559544 WAIT 4 seconds DTMF 734 YOU: Next You are finished programming and may hang up the phone. When an alarm occurs, the B1290 will dial the number of the paging terminal, 255-9544;...
Page 45 PROGRAMMING EXAMPLES PAGE 41 In this example, the B1290 is used to announce alarms from an unattended location over a building’s public address system. You want the alarms to be announced twice, repeated again one minute later then repeated for the last time one minute after this.
Page 46 When a remote alarm occurs, the DTMF code for that alarm is transmitted to the central site. On receiving this code, the central site activates the relay associated with that alarm. When the alarm clears, the Off code is transmitted from the remote, and the central site’s associated relay is released. ProTalk Plus ProTalk Plus ProTalk Plus...
Page 47 As part of its alarm sequence over radio, the B1290 will send its alarm On output code. This code will be interpreted as an acknowledgment by the remote, and it will stop sending the alarm. The central unit will continue to report over radio and telephone until it is acknowledged. ProTalk Plus ProTalk Plus ProTalk Plus...
Page 48 PAGE 44 PROGRAMMING EXAMPLES YOU: Record Alarm Voices B1290: Expander One Site is... Next (Site ID is disabled - don’t need a voice message) YOU: B1290: Expander One, Alarm One is... YOU: Change this voice B1290: beep-beep YOU: Intrusion B1290: Expander One, Alarm One is Intrusion YOU: Next...
Page 49 PROGRAMMING EXAMPLES PAGE 45 etc.
Page 50: Troubleshooting
PAGE 46 TROUBLESHOOTING 10. TROUBLESHOOTING Problem: I’ve hooked up the B1290 as per the installation instructions but nothing happens. - Use a voltmeter to check that the power supply is properly connected. If an AC adapter is being used, it should have an output of at least 12 volts DC with a center-negative power connector.
Page 51 TROUBLESHOOTING PAGE 47 field wiring, one option is to “debounce” the alarms using the B1290 alarm delay parameter using Program Code 5. When this value is set, contacts must be closed for a specific period of time before they are recognized as alarms. - Check if any new alarms are announced when the B1290 continues to dial after it has been acknowledged.
Page 52 PAGE 48 TROUBLESHOOTING Problem: How can I prevent unauthorized personnel from calling up the B1290 and altering its programming? - In its default condition, the B1290 does not require any type of password. If you wish to enter one, refer to the Access Code in the DTMF Codes section (Program Code 3).
Page 53: Specifications
SPECIFICATIONS PAGE 49 11. SPECIFICATIONS Alarm Inputs 8, optically isolated, 2mA to operate, ground closure required. Control Outputs 4 independent form C outputs controlled by programmable codes or used as special function outputs. Rated: 1 Amp at 30 Volts DC, 0.3A at 120V AC Telephone Connection RJ11;...
Page 54: Appendix A - Programmable Features
APPENDIX A – PROGRAMMABLE FEATURES PAGE 50 12. APPENDIX A – PROGRAMMABLE FEATURES Alarm Messages Unique Site ID plus individual messages for each input. Message length is variable Alarm Polarity Selects NO or NC input format Alarm Latch Latches fleeting alarm inputs Alarm Debounce Selects the delay time before a change of state on the input is valid.
Page 55 APPENDIX A – PROGRAMMABLE FEATURES PAGE 51 Pulse Dial Forces dialing to be pulse instead of tone. Number of Expanders Sets the number of connected expanders. Disable Expander ID Stops the site ID in the expander from being spoken. Audio Levels Sets the gain for audio signals in the B1290...
Page 56: Appendix B - Options
Expander module. Adds 8 inputs and 4 relays. Maximum of 7 expanders Option 004 External power pack with 120 VAC power supply, sealed battery and charger, 12 hour capacity in standby. Connection of the Option 004 power supply is shown in Figure 8. ProTalk Plus Figure 8 Option 004 Connections...
Page 57: Appendix C - Programming Tree
APPENDIX C – PROGRAMMING TREE PAGE 53 14. APPENDIX C – PROGRAMMING TREE The parameters used to program the ProTalk Plus are given as a summary below. Where X appears, user data is entered Voices Site ID/Alarms Record Next Quit...
Page 58 APPENDIX C – PROGRAMMMING TREE PAGE 54 Clear Next Remote Alarm Change Clear Next Interrogate Change Clear Next Directory Control Change Clear Next Configuration Rings Before Answer Change Auto Ack Next Timer A Change Next Timer B Change Next Times A Change Next I/O Config.
Page 59 APPENDIX C – PROGRAMMING TREE PAGE 55 Relay Timebase Seconds Minutes Next Relay Timer Not timed Special Change Next System Dial Format Tone Pulse Next Squelch Polarity Busy low Busy high Next Relay Voices Next Ack Request Next Dial Tone (Call Progress) Next Expanders Number of Expanders...
Page 60 APPENDIX C – PROGRAMMMING TREE PAGE 56 Next...
Page 61: Appendix D - Mounting
APPENDIX D – MOUNTING PAGE 57 15. APPENDIX D – MOUNTING Figure 9 Mounting Detail...
Page 62: Notices
PAGE 58 ACTA/IC CUSTOMER INSTRUCTIONS 16. NOTICES CSA Certification The B1290 product has 60950-1 safety certification for Canada and USA. Compliance This Class A digital apparatus complies with Canadian ICES-003. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and, (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 63: Warranty Statement
Payment Terms Payment terms are Net30 days from the date of invoice. ProTalk, a division of Circa Enterprises Inc. reserves the right to request payment in full prior to shipping. A monthly service charge of 1% (12% per annum) will be added to past due balances.
Page 64 ProTalk, a division of Circa Enterprises Inc. will not be responsible for any costs related to any setting up this product, any adjustment of user controls or any programming required for a specific installation of this product.
