CREE LIGHTING CONNECTED MAX CMACC-SWD-12-WH Installation Instructions Manual

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety precautions should
always be followed including the following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
1. Before installing wall controls turn off the power at the circuit
breaker.
Couper l'alimentation avant l'installation.
2. These wall controls must be installed in accordance with the
national and local building codes and electrical wiring codes
including wiring methods and wiring connections. If you are not
familiar with these codes and requirements, consult a qualified
electrician.
Ce produit doit être installé conformément à NEC ou votre code
électrique local. Si vous n'êtes pas familier avec ces codes et ces
exigences, veuillez contacter un électricien qualifié.
3. Indoor use only and suitable for damp locations.
Pour usage interieur seulement et convient aux emplacements
humides.
4. Any changes or modifications to these devices not explicitly
approved by manufacturer could void your authority to operate this
equipment.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE

SPECIFICATIONS

• Type: Smart Wi-Fi Light Dimmer Switch
• Model: CMACC-SWD-12-WH
• Rated Current: 3A
• Input: 100V-240V,50/60Hz
• Wireless Frequency: 2.4GHz
• Wireless Standard: IEEE802.11 b/g/n
• Max Output: 300W INC
150W LED
1 of 3
Connected Max In Wall Dimmer

CONTENTS IN BOX

• Smart Dimmer Switch
• Faceplate
• (4) Wire Nuts
• (2) Screws
• Installation Sheet

REQUIREMENTS- SEE FIGURE 1

• Neutral wire required.
• Replaces single pole switch only.
• NOTE:
• If you're not familiar with basic electrical work, please don't
install dimmer by yourself, and call a professional electrician
to help you.
• Do not try to install dimmer without neutral wires and be
careful not to reverse the live and load wires; otherwise it will
not work.
• If a neutral line is not available in the switch box, please
contact a professional electrician to install the correct
electrical lines. Without a neutral line this switch can not be
installed.
• For a better connection, we recommend you twist wire nuts to
make sure the copper conductors are fully concealed.
for Standard Bulbs
Smart Dimmer Switch
Includes: CMACC-SWD-12-WH
Installation INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
LPN00838X0001A0_A
