Summary of Contents for Techalogic FHD 1080P DC-1
-
Page 2: Product Specification
Welcome to the Techalogic Family Thank you for your purchase of our Techalogic DC-1 Dual Lens Helmet/Riding Hat Camera. We want to help getting to know and using the camera system as easy and enjoyable as possible. Please read through this user guide, refer to our standard questions and answers plus comprehensive video tutorials on support page. -
Page 3: Product Structure
Product Structure Product Operation Charging the Battery 1. Ensure that the Micro USB charging cable provided with the camera is used. Not all cables are suitable The red LED will light during charging. This will automatically shut off when the camera is 100% charged. 2. - Page 4 DOWNLOAD the APP iOS and Android - roadcam Android Only - viidure Insert the Micro SD Card Open the rubber cover of the SD card slot Insert the SD card (rated class 10 plus) maximum of 128GB and recover the card slot. Please don’t remove the SD card whilst the camera is recording.
- Page 5 Each camera has a unique identifier.. They all start with DC-1 with a series of numbers afterwards...
- Page 6 RoadCam App guide...
- Page 7 Select the Orange RoadCam Logo Button and you will be taken to the screen below...
- Page 8 Options available on this screen. Live view in a split screen front and rear. Great to use when aligning the camera on your helmet/Riding Hat Exit – Go back to the App main connection page Settings Cog (Top right Corner). Section A below Video –...
- Page 9 Wi-Fi Connection Password – Personalise your Wi-Fi password. We recommend leaving as pre set Sound Recording – Turn video sound recording on/off Camera Watermark Time/Date – Turn date/time on/off on your recordings Cycle Record Time – Loop record segment sizes. 1, 3, 5 or 10mins. Select ‘off’ camera will stop recording when the card is full and the segment length will be 15 mins.
- Page 10 Section C - Video – Select/View/Save your Video File. Loop Video – All of your standard video files stored here Emergency Video – Any video file saved when you use the emergency button on the remote saved here Touch the video file you wish to play or hit select top Right to save to your mobile device/phone Touch the video file –...
- Page 11 Section D Photo – Select/View/Save Photo Files. Touch the photo file you wish to view or hit select top Right to save to your mobile device/phone Touch the photo file – You will review the full-size photo Save to your mobile device/phone – When you choose select you will get 3 options at the bottom of the screen. Download to you phone on the left, Bin the file in the middle and return back to previous page on the right..
-
Page 12: Low Battery Indicator
4. To turn your camera OFF - Hold down the key button for a few seconds. Low Battery Indicator ● The green battery light shows the camera battery status. ● Green light steady: battery power is at least 50%. ● Green light slowly flashing battery power is 30–50%. ●... -
Page 13: Microphone Sensitivity Setting
Changing the sensitivity level can easily be done by performing a firmware update and selecting the desired sensitivity level. https://techalogic.co.uk/support/dc-1-support/ Viewing video files on your computer A - Remove the SD card, place in the TF adapter and insert direct into your computer B - Connect the camera to a computer by using the USB cable provided. - Page 16 Extend Your Camera’s Battery Life...
- Page 17 The camera has a 2.5 hour battery life. This can easily be extended by attaching the Techalogic Power Bank(optional extra) via the micro USB lead(provided).. Weather Proof your USB connection If you are using the USB battery extension lead in wet weather you will require the ‘USB waterproof Rubber Pack’ to...
- Page 18 Thank you for choosing Techalogic If you have any questions regarding the operation of your camera, please don’t hesitate to contact us and we will be more than happy to assist you 0330 2233108...
Need help?
Do you have a question about the FHD 1080P DC-1 and is the answer not in the manual?
Questions and answers
when I turn on my techalogic, the white LED flashes, but the camera switches off a few minutes into my ride. What am I doing wrong? I understand what the flashing green light means in terms of different battery levels, but should the white light be steady? What does it mean when the blue wifi light is flashing?
The flashing white LED is not mentioned in the provided context, so its meaning cannot be determined.
The camera turns off after a few minutes in standard recording mode if it stays static for 3 minutes. This is part of its intelligent energy-saving system to conserve battery power. This feature is disabled when using an external power supply or when WiFi is connected and the app is operating.
This answer is automatically generated
