  • Page 1 Spectra Logic BlackPearl Nearline Gateway User Guide SpectraLogic.com...
  • Page 2 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, BOTH OF WHICH ARE EXPRESSLY DISCLAIMED. In no event shall Spectra Logic be liable for any loss of profits, loss of business, loss of use or data, interruption of business, or for indirect, special, incidental or consequential damages of any kind, even if Spectra Logic has been advised of the possibility of such damages arising from any defect or error.
  • Page 3 Updated for the BlackPearl 5.4.1 release. Note: To make sure you have the most current version of this guide check the Spectra Logic Technical Support portal at support.spectralogic.com/documentations/user-guides/. To make sure you have the release notes for the most current version of the BlackPearl Release Notes, check the Spectra Logic Technical Support portal at support.spectralogic.com/documentations/software-release-notes.
  • Page 4 Software Product. 3. GENERAL The Software Product is licensed, not sold, to you by Spectra for use only under the terms of this EULA. The Software Product is protected by copyright laws and international copyright treaties, as well as other intellectual property laws and treaties.
  • Page 5 Software Product and subject to the terms and conditions of this EULA. C. Spectra retains all right, title, and interest in and to the Software Product, and any rights not granted to you herein are reserved by Spectra. You hereby expressly agree not to extract...
  • Page 6 9. INTELLECTUAL PROPERTY RIGHTS A. Spectra shall retain all right, title, and interest in the Software Product and to any modifications or improvements made thereto, and any upgrades, updates or Documentation provided to End User. End User will not obtain any rights in the Software Product, its updates, upgrades, and Documentation, as a result of its responsibilities hereunder.
  • Page 7 OF OR INABILITY TO USE THE SOFTWARE PRODUCT OR THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES, EVEN IF SPECTRA HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, SPECTRA'S ENTIRE LIABILITY UNDER ANY PROVISION OF THIS EULA SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE SOFTWARE PRODUCT;...
  • Page 8 Contacting Spectra Logic To Obtain General Information Spectra Logic Website: spectralogic.com United States Headquarters European Office Spectra Logic Europe Ltd. Spectra Logic Corporation 6285 Lookout Road 329 Doncastle Road Bracknell Boulder, CO 80301 Berks, RG12 8PE United Kingdom Phone:1.800.833.1132 or 1.303.449.6400 Phone:44 (0) 870.112.2150...

  • Page 9: Table Of Contents

    Table of Contents About This Guide Intended Audience BlackPearl User Interface Screens Related Information Related Publications Tape Library User Guides Online Forum Chapter 1 - Product Overview Overview Features Metadata Performance Drives Components Front Bezel Gen2 X Series Gen2 S Series and Gen2 V Series Gen1 S Series, Gen1 P Series, and Gen1 V Series Front View of the 44-Bay Expansion Node Rear View of the 44-Bay Expansion Node...
  • Page 10 Chapter 2 - Initial Configuration Before You Begin Rackmount the Chassis Installing Data Drives Ensure ESD Protection Install a Drive in a Gen2 S Series Chassis Install a Drive in a Gen2 V Series Chassis Install a Drive in a Gen2 X Series Chassis Install a Drive in a Gen1 Chassis Connect Ethernet Cables Automatically Import Activation Keys...
  • Page 11 Tape Partitions Tape Drive Reservation Tape Media Inspections Disk Partitions Special Considerations for Ejecting Tapes Special Considerations for Reading Tapes in a Non-BlackPearl Nearline Gateway Environment Example Configurations Single Copy on Tape Dual Copy on Tape Single Copy on Nearline Disk...
  • Page 12 Create a Replication Target Create a BlackPearl Target Create an Amazon S3 Target Create a Microsoft Azure Target Create a Storage Domain Add a Storage Domain Member to a Storage Domain Create a Data Policy New Data Policy ACL for a Group New Data Policy ACL for a User Add Data Persistence Rules and Replication Rules to a Data Policy Create a Bucket...
  • Page 13 Delete a Data Replication Rule Manage a Data Policy Edit a Data Policy Delete a Data Policy Delete a Data Policy ACL Edit a Data Persistence Rule Delete a Data Persistence Rule Change the BlackPearl gateway Cache Configuration Manage Replication Targets Edit a BlackPearl Replication Target Edit an Amazon Replication Target Edit an Azure Replication Target...
  • Page 14 Edit a Bucket Delete a Bucket Chapter 6 - Configuring Network Attached Storage Overview of NAS Storage Pools, Volumes, and Shares Storage Pools Volumes and Shares Naming Considerations Create a NAS Storage Pool Create a Volume Create a Share Create a CIFS Share Create an NFS Share Configure NAS Services Configure the CIFS Service...
  • Page 15 Delete a Volume Volume Snapshots Create a Snapshot Create a Snapshot Schedule Delete a Snapshot Schedule Delete Snapshots Restore to a Snapshot Retrieve a Single File from a Snapshot Manage Shares Edit a CIFS Share Edit an NFS Share Delete a Share Manage NAS Replication Manually Start NAS Replication Cancel a NAS Replication In Progress...
  • Page 16 Chapter 8 - Additional Configuration Options Configure Network Connections and Settings Configure Ethernet Ports Configure DNS Settings Configure SMTP Settings Configure Date and Time Edit the System Name Configure Networking Services Configure the DS3 Service Configure the Active Directory Service Configure the SNMP Service Configure a Vail Sphere Register with a Vail Sphere...
  • Page 17 Create an S3 Group Remove an S3 Group Member Edit an S3 Group Delete an S3 Group Configure Certificates Manually Enter Activation Keys Chapter 9 - Working with Tape Libraries and Media Tape Library Barcode Reporting Format Tapes Cancel Tape Format Inspect Tapes Eject Tapes Edit Tape Eject Information Eject a Single Tape...
  • Page 18 Tape Drive Reservation Offline a Tape Drive Online a Tape Drive Remove a Tape Drive from a Tape Partition Data Migration Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations Download an Object Cancel DS3 Jobs Edit an S3 Job...
  • Page 19 View the Status of NAS Volumes View the Status of NAS Shares View the Status of the System Pools View Bucket Contents View DS3 Jobs Information View Tape Media Information View Performance Metrics View Reports Database Backup & Restore Create a Database Backup Schedule Manually Generate a Database Backup Restore from a Database Backup Delete Backup...
  • Page 20 Manually Generate Log Sets Email a Log Set Download a Log Set Delete Log Sets Chapter 12 - Maintaining the BlackPearl Nearline Gateway Data Integrity Verification - Disk Media Cancel Data Integrity Verification Data Integrity Verification - Tape Media Cancel Tape Media Verification...
  • Page 21 How is Cache Used and Allocated? Why Does the BlackPearl User Interface Display 80% Cache Usage? Tape Partitions How Does a User Upgrade to Later Generations of Media in the Same Tape Library? What Happens When a Tape Partition is Placed in Standby/Quiesced? What Happens When a Tape Partition is Re-Activated? How do I Change the Tape Library Used by the BlackPearl gateway While Min- imizing the Impact, Management Time, and System Downtime?
  • Page 22 General BlackPearl Notes Tape Drive Failure Modes Move Failures/Tape Stuck in Drive Library, Drive, and Tape Failure Behavior in BlackPearl version 5.3 Enabling iSCSI For Use With the Spectra Swarm Troubleshooting Resolve a BlackPearl Management Port IP Address Conflict Using the Console...
  • Page 23 Connectivity to the Network Troubleshooting Tools Spectra Logic Technical Support Before Contacting Support Determine the Gateway Serial Number Opening a Support Ticket Remote Support Enabling Remote Support Disabling Remote Support Appendix A - IPMI Configuration Appendix B - Specifications Data Storage Specifications...
  • Page 24 Appendix C - BlackPearl 1.0 Chassis Overview & Specifications Components Front View Rear View Rear Panel Specifications System Specification Interface Specifications Appendix D - Regulatory & Safety Standards EU Declaration of Conformity Certifications CE Marking FCC Notice Class A Emissions Warning Safety Standards and Compliance Waste of Electronic and Electrical Equipment (WEEE) Directive Restriction of Hazardous Substances in Electrical and Electronic Equipment...
  • Page 25 Ruby on Rails Included Packages Index January 2022 User Guide-BlackPearl NearlineGateway - 25 -...

  • Page 26: About This Guide

    When instructions in this guide apply to both the BlackPearl Nearline Gateway master node and expansion nodes, the system is used to refer to both.

  • Page 27: Related Information

    Spectra BlackPearl Nearline Gateway The following documents related to the Spectra BlackPearl Nearline gateway are available on the Support Portal website at support.spectralogic.com, and from the Documentation screen in the BlackPearl user interface.
  • Page 28 Gen1 master node or 44-bay expansion node. • The Spectra 12-, 36- & 45-Drive Chassis Power Supply Replacement Guide provides instructions for replacing a failed power supply in a Gen1 master node or 44-bay expansion node.

  • Page 29: Tape Library User Guides

    About This Guide Online Forum Tape Library User Guides Spectra Logic Tape Libraries User Guides for Spectra Logic tape libraries are posted on the Support Portal website at: support.spectralogic.com/documentations/user-guides. IBM Tape Libraries ® User Guides for compatible IBM tape libraries are posted on the IBM Knowledge Center website at: ibm.com/support/knowledgecenter/products/.

  • Page 30: Chapter 1 - Product Overview

    Supported Browsers VERVIEW The BlackPearl Nearline gateway allows data to move seamlessly into tape storage in a way not previously possible. It enables users to deploy a tier of deep storage that is cost effective, easy to manage, and scalable to exabytes of data.

  • Page 31: Features

    The BlackPearl Nearline gateway can be configured over an Ethernet network using a standard web browser. Integration with a Spectra Logic Tape Library Fibre Channel and SAS HBAs can be installed to provide connectivity to a Spectra Logic tape library using LTO or TS11xx technology drives. ®...
  • Page 32 Microsoft Windows , macOS ® ® UNIX , and Linux . Solid state disk drives may be installed in your system to improve NFS performance. January 2022 User Guide-BlackPearl Nearline Gateway - 32 -...

  • Page 33: Metadata Performance Drives

    BlackPearl 4U master node, which allows the gateway to use the 44-bay expansion nodes as storage domain targets. Up to two 44-bay expansion nodes can be connected to a BlackPearl 2U master node. January 2022 User Guide-BlackPearl Nearline Gateway - 33 -...
  • Page 34 BlackPearl gateway. Gen2 Chassis 1 Gigabit Ethernet The Gen2 X Series chassis includes an integrated 1 Gigabit Ethernet port to access the BlackPearl User Interface. January 2022 User Guide-BlackPearl Nearline Gateway - 34 -...

  • Page 35: Components

    The following sections show the locations of and briefly describe the BlackPearl gateway's major front and rear panel components. For a description of the components on the BlackPearl 1.0 chassis, see BlackPearl 1.0 Chassis Overview & Specifications on page 479. January 2022 User Guide-BlackPearl Nearline Gateway - 35 -...

  • Page 36: Front Bezel

    In most cases, the front bezel includes a visual status beacon light bar which provides status information for the gateway. See Front Bezel Visual Status Beacon on page 343 information about the status indicated by each visual status beacon color/pattern. January 2022 User Guide-BlackPearl Nearline Gateway - 36 -...

  • Page 37: Gen2 X Series

    The LEDs are not visible with the bezel installed. Data drives The base Gen2 X Series BlackPearl Nearline gateway includes two 1.6 TB high-performance solid-state drives (SSDs) for database storage and four 6.4 TB high-performance solid-state drives for the object cache. Up to 18 additional drives can be added.
  • Page 38 Empty drive sleds are installed in the unused drive bays to prevent contaminants from entering the enclosure and to maintain proper air flow. Ensure each empty drive sled has a 'drive blank' installed in the sled for proper airflow and cooling. January 2022 User Guide-BlackPearl Nearline Gateway - 38 -...
  • Page 39 • Blue solid - The server module is being sent an identify command. • Blue blinking - A service action is allowed. • Amber - A server module fault has been detected. January 2022 User Guide-BlackPearl Nearline Gateway - 39 -...
  • Page 40 Spectra Logic tape library, or provides connectivity for up to four 107-bay expansion nodes. • Up to two four-port 16 GB or 32 GB Fibre Channel card provides connectivity to four Fibre Channel tape drives in a Spectra Logic or supported tape library. January 2022 User Guide-BlackPearl Nearline Gateway...

  • Page 41: Gen2 S Series And Gen2 V Series

    BlackPearl gateway with the front bezel removed. Figure 4 The front view of the Gen2 S Series BlackPearl 4U gateway (front bezel removed). Figure 5 The front view of the Gen2 V Series BlackPearl 2U gateway (front bezel removed). January 2022 User Guide-BlackPearl Nearline Gateway - 41 -...
  • Page 42 Use the user interface, not the power button, to power down the chassis. Reset button Only use the chassis reset button under direction of Spectra Logic Technical Support. System status The status LEDs indicate power status, disk and network activity, as well as LEDs hardware faults.
  • Page 43 Boot drives The boot drives provide storage for the operating system and BlackPearl user interface. The boot drives in the BlackPearl gateway are hot swappable which allows for uninterrupted operation during replacement. January 2022 User Guide-BlackPearl Nearline Gateway - 43 -...
  • Page 44 • Up to three optional four-port SAS cards provide connectivity to SAS drives in a Spectra Logic tape library, or provide connectivity for up to eight 107-bay expansion nodes. • Up to three four-port Fibre Channel card provides connectivity to Fibre Channel tape drives in a Spectra Logic or supported tape library.
  • Page 45 Monitor connector If necessary, you can connect a monitor to the VGA connector on the chassis for troubleshooting purposes. Only connect a monitor for initial configuration of the BlackPearl management port, or as directed by Spectra Logic Technical Support. Serial port The serial port is only used in a HotPair configuration.
  • Page 46 BlackPearl chassis. The S Series chassis also has one USB 3.1 Gen2 Port (not shown). If necessary, you can use these ports to connect a USB drive, or USB keyboard to the chassis for troubleshooting purposes as directed by Spectra Logic Technical Support.

  • Page 47: Gen1 S Series, Gen1 P Series, And Gen1 V Series

    Figure 9 The front view of the Gen1 S and P Series BlackPearl 4U master node (front bezel removed). Figure 10 The front view of the Gen1 V Series BlackPearl 2U master node (front bezel removed). January 2022 User Guide-BlackPearl Nearline Gateway - 47 -...
  • Page 48 The LEDs are not visible with the bezel installed. Empty drive sleds Empty drive sleds are installed in the unused drive bays to prevent contaminants from entering the enclosure and to maintain proper air flow. January 2022 User Guide-BlackPearl Nearline Gateway - 48 -...
  • Page 49 Gen1 V Series BlackPearl master node chassis. Figure 11 The rear view of the Gen1 S Series BlackPearl 4U master node. Figure 12 The rear view of the Gen1 V Series BlackPearl 2U master node. January 2022 User Guide-BlackPearl Nearline Gateway - 49 -...
  • Page 50 Empty drive sleds Empty drive sleds are installed in the unused drive bays to prevent (BlackPearl 4U contaminants from entering the enclosure and to maintain proper air flow. master node only) January 2022 User Guide-BlackPearl Nearline Gateway - 50 -...
  • Page 51 BlackPearl management port and cannot be used for data transfer. Notes: • The 10GBase-T ports auto-negotiate down to 1000Base-T. • Spectra Logic recommends using 40 GigE ports or the 10 GigE ports for data transfer to ensure maximum performance. Monitor connector If necessary, you can connect a monitor to the SVGA connector on the BlackPearl master node for troubleshooting purposes.
  • Page 52 Note: Unless your BlackPearl gateway includes a 40 GigE card or a 10GBase-T card, Spectra Logic recommends using the 10 GigE ports for data transfer to ensure maximum performance. Expansion slots...

  • Page 53: Front View Of The 44-Bay Expansion Node

    When fewer than the maximum number of drives are installed, empty drive sleds are installed in the unused drive bays to prevent contaminants from entering the enclosure and to maintain proper air flow. January 2022 User Guide-BlackPearl Nearline Gateway - 53 -...

  • Page 54: Rear View Of The 44-Bay Expansion Node

    When fewer than the maximum number of drives are installed, empty drive sleds are installed in the unused drive bays to prevent contaminants from entering the enclosure and to maintain proper air flow. January 2022 User Guide-BlackPearl Nearline Gateway - 54 -...

  • Page 55: 96-Bay Expansion Node

    96-bay expansion node. There are no components or status indicators on the front of the 96-bay expansion node. Figure 16 The front view of the 96-bay expansion node (front bezel removed). January 2022 User Guide-BlackPearl Nearline Gateway - 55 -...
  • Page 56 • Each power supply has a single LED that lights to indicate when the power is on and functioning normally. SAS connectors The rear panel of the 96-bay expansion node has two SAS ports used to connect an expansion node to BlackPearl master node. January 2022 User Guide-BlackPearl Nearline Gateway - 56 -...

  • Page 57: 107-Bay Expansion Node

    107-bay expansion node. There are no components or status indicators visible on the front of the 107-bay expansion node with the front bezel is attached. Figure 18 The front view of the 107-bay expansion node. January 2022 User Guide-BlackPearl Nearline Gateway - 57 -...
  • Page 58 • Each power supply has its own AC power connector. • Each power supply has a single LED that lights to indicate when the power is on and functioning normally. January 2022 User Guide-BlackPearl Nearline Gateway - 58 -...

  • Page 59: User Interface

    10 (MB, GB, TB). Starting with BlackPearl 5.3, the unit displayed are base 2 (MiB, GiB, TiB) to better reflect actual storage usage. Screen captures used in this guide may not match what is displayed in the BlackPearl user interface. January 2022 User Guide-BlackPearl Nearline Gateway - 59 -...

  • Page 60: Menus

    Clicking any of the panes on the Dashboard takes you to a details screen for that selection. The Dashboard screen also displays performance metrics for the gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 60 -...
  • Page 61 AutoSupport Log sets (ASLs) are generated by the gateway. • Users—Provides controls for creating new S3 user accounts that act as owners for buckets, editing the login password, and displaying the S3 credentials for each user January 2022 User Guide-BlackPearl Nearline Gateway - 61 -...
  • Page 62 • Documentation—Displays links to BlackPearl documentation. • Contact Information—Displays contact information for Spectra Logic Technical Support, as well as the part and serial numbers for the gateway. • Tools > Data Integrity Verification—Provides a tool for data integrity verification of storage pools.

  • Page 63: Status Icons

    Error A system component experienced an error condition. Check messages to determine the component and its error condition. Unknown The status of a system component cannot be determined. Check messages to determine the component and its status. January 2022 User Guide-BlackPearl Nearline Gateway - 63 -...

  • Page 64: Supported Browsers

    11 or later • Microsoft Edge version 79.0.309 or later ® • Opera Software Browser version 12 or later Note: Spectra Logic recommends using Google Chrome to access the BlackPearl user interface. January 2022 User Guide-BlackPearl Nearline Gateway - 64 -...

  • Page 65: Chapter 2 - Initial Configuration

    Chapter 2 - Initial Configuration This chapter describes the initial setup of the Spectra BlackPearl Nearline Gateway, necessary for operation in your environment. Before You Begin Rackmount the Chassis Installing Data Drives Ensure ESD Protection Install a Drive in a Gen2 S Series Chassis...

  • Page 66: Before You Begin

    Chapter 2 - Initial Configuration Before You Begin EFORE EGIN If your BlackPearl gateway was installed by Spectra Logic Professional Services the steps in this section are complete. They are provided here for reference. See Next Steps on page 91 begin using your BlackPearl gateway.

  • Page 67: Install A Drive In A Gen2 S Series Chassis

    3. Simultaneously press the top cover release buttons (1) on both sides of the chassis. Figure 21 Remove the front top cover. 4. Slide the front top cover toward the front of the chassis (2) and lift the cover upward to remove it. January 2022 User Guide-BlackPearl Nearline Gateway - 67 -...

  • Page 68: Install A Drive In A Gen2 V Series Chassis

    1. Disconnect the bezel USB connection and remove the front bezel from the chassis. The front bezel is held on by magnets. 2. Press the release buttons (1) on the ends of a tray inward to unlock it. January 2022 User Guide-BlackPearl Nearline Gateway - 68 -...

  • Page 69: Install A Drive In A Gen2 X Series Chassis

    3. Press the release catch (1) on the drive carrier in the direction of the arrow to open the handle (2). Rotate the drive sled handle upward (3) and extend the drive sled slightly out of the chassis by pulling the middle of the handle. January 2022 User Guide-BlackPearl Nearline Gateway - 69 -...
  • Page 70 9. Repeat these instructions, starting with Step 2 on page 69 for each additional drive. 10. Reattach the front bezel and the bezel USB connection. January 2022 User Guide-BlackPearl Nearline Gateway - 70 -...

  • Page 71: Install A Drive In A Gen1 Chassis

    Status Beacon control sled. The images below show a normal drive sled in slot 1 for clarity. 2. Slide the drive sled locking tab to the right to release the drive sled handle. Figure 29 Slide the tab to the right to release the drive sled handle. January 2022 User Guide-BlackPearl Nearline Gateway - 71 -...
  • Page 72 2. With the drive handle in the open position, slide the drive sled into the chassis until the front of the drive sled is flush against the chassis. The drive sled slides in easily; do not force it. Figure 31 Install the drive into the BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 72 -...

  • Page 73: Connect Ethernet Cables

    Activation keys enable features on the BlackPearl gateway. They are tied to the serial number of the gateway for which they are issued, and cannot be used on another gateway. Renewals of expired activation keys are obtained by contacting Spectra Logic Technical Support (see Contacting Spectra Logic on page 8).

  • Page 74: Power On The Gateway

    The expansion node immediately powers on. Wait approximately four minutes while the expansion node initializes before powering on the BlackPearl master node. January 2022 User Guide-BlackPearl Nearline Gateway - 74 -...
  • Page 75 5 to 10 minutes, depending on the configuration. Note: Do not use the front panel power button to power down the gateway. See Reboot or Shut Down a BlackPearl Gateway on page 378. January 2022 User Guide-BlackPearl Nearline Gateway - 75 -...

  • Page 76: Configure The Blackpearl Management Port

    If you cannot use one of the methods above to change the Management port IP address, see Resolve a BlackPearl Management Port IP Address Conflict on page 438 for an alternate method. January 2022 User Guide-BlackPearl Nearline Gateway - 76 -...
  • Page 77 • For a Gen1 P, S, or V Series, see Rear Panel on page 51. The Console screen displays. Figure 33 The Console screen. 2. Press CTRL-N. The Configure Management Network Interface screen displays. Figure 34 The Configure Management Network Interface screen. January 2022 User Guide-BlackPearl Nearline Gateway - 77 -...

  • Page 78: Log Into The Blackpearl User Interface

    Note: There is no limit to the number of users who can log in to the user interface. Spectra Logic recommends only one person use the interface at a time to avoid conflicting operations. 1. Using a standard web browser, enter the IP address for the BlackPearl management port...
  • Page 79 Find the serial number on the sticker positioned on the top of the chassis, on the right-hand side, toward the front. The fields are case sensitive. Figure 35 The BlackPearl serial number sticker. Notes: • Spectra Logic recommends that you change the default password for the primary administrator (see Edit a User on page 294).

  • Page 80: Configure The Data Connection

    The network switch connected to the BlackPearl gateway must be configured IMPORTANT for Level 3 LACP in order to support an aggregate data connection on the BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 80 -...
  • Page 81 Interface dialog box displays. Note: Depending on your hardware configuration, the New Aggregate Interface dialog box may look different than what is shown below. Figure 38 The New Aggregate Interface dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 81 -...
  • Page 82 8. Change the MTU (Maximum Transmission Unit) value, if desired. If you set the MTU value to something other than 1500, ensure that your switch configuration supports larger MTU settings, as well as all the hosts on the network. 9. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 82 -...

  • Page 83: Configure A Single Port Data Connection

    Figure 40 The Edit Data # dialog box. 3. Select DHCP to configure the gateway to automatically acquire an IPv4 address using DHCP. This setting does not apply to IPv6. January 2022 User Guide-BlackPearl Nearline Gateway - 83 -...

  • Page 84: Configure A Static Route

    BlackPearl gateway, a static route is required in order for the gateway to communicate to the additional network. January 2022 User Guide-BlackPearl Nearline Gateway - 84 -...

  • Page 85: Create A User

    Use the instructions in this section to create users, which act as S3 users when interacting with the BlackPearl gateway through a DS3 SDK (Software Development Kit) client, or the DS3 API. Each user has a unique S3 Access ID and Secret Key. January 2022 User Guide-BlackPearl Nearline Gateway - 85 -...

  • Page 86: Description Of User Types

    The default username and password are both monitor using all lowercase letters. Notes: • Spectra Logic recommends that you change the initial password for the default monitor account. See Edit a User on page 294.

  • Page 87: Create A User

    Chapter 2 - Initial Configuration Create a User Create a User 1. From the menu bar, select Configuration > Users. The Users screen displays. Figure 42 The Users screen. January 2022 User Guide-BlackPearl Nearline Gateway - 87 -...
  • Page 88 8. From the drop-down list, select a Default Data Policy for the user. If specified, the gateway uses the selected data policy for all buckets created by the user, unless a different policy is specified during bucket creation. January 2022 User Guide-BlackPearl Nearline Gateway - 88 -...

  • Page 89: View S3 Credentials

    There are two methods you can use to view S3 credentials, through the User screen, or the User Profile screen. Using the User Screen 1. From the menu bar, select Configuration > Users. The Users screen displays (see Figure 42 page 87). January 2022 User Guide-BlackPearl Nearline Gateway - 89 -...
  • Page 90 2. Select Action > Show S3 Credentials. The S3 Credentials dialog box displays. Figure 45 The S3 Credentials dialog box. 3. Use the S3 Access ID and S3 Secret Key to access the BlackPearl gateway using a DS3 client, DS3 API, or Vail sphere. January 2022 User Guide-BlackPearl Nearline Gateway - 90 -...

  • Page 91: Next Steps

    Additional Configuration Options on page 262 for information about the additional options that can be configured on the BlackPearl gateway. • See Operating the BlackPearl Nearline Gateway on page 335 for information about day-to- day monitoring and operation of the gateway. • See Using AutoSupport on page 381...

  • Page 92: Chapter 3 - Understanding Advanced Bucket Management

    Chapter 3 - Understanding Advanced Bucket Management This chapter explains the concepts of the BlackPearl Nearline gateway advanced bucket management. It is important to understand the information in this chapter before you begin designing the storage architecture of the BlackPearl gateway.

  • Page 93: Goals Of Advanced Bucket Management

    DS3 O VERVIEW The Spectra BlackPearl Nearline Gateway allows data to move seamlessly into deep storage in a way not previously possible. DS3 is the first native REST-based interface to deep storage which enables easy archiving of large amounts of bulk data. It enables users to deploy tape, nearline disk, and online disk storage that is cost effective, easy to manage, and scalable to exabytes of data.
  • Page 94 If the next write also has a small amount of data, then the drive writes the next portion and again stops, overshoots, and rewinds, causing a back and forth “shoe- shining” like action. DS3 caches data on the BlackPearl Nearline Gateway before starting the transfer to tape, which prevents the shoe-shining behavior from occurring.

  • Page 95: Ds3 Clients

    A data policy may be used by multiple buckets, but a bucket uses precisely one data policy. January 2022 User Guide-BlackPearl Nearline Gateway - 95 -...

  • Page 96: Data Persistence Rules

    • Bucket Isolated allocates an entire tape or pool to a bucket when needed. Allocating an entire pool to a bucket may use up resources quickly and is not recommended. January 2022 User Guide-BlackPearl Nearline Gateway - 96 -...

  • Page 97: Data Replication Rules

    Tape Eject Strategy A tape eject strategy must be considered as part of a data policy. Spectra recommends keeping at least one copy of all archived data in the library at all times. Libraries can be easily upgraded by purchasing more slot licenses, or, if the slots become completely full, upgrading the library itself to one with more slots using the exclusive Spectra TranScale technology.

  • Page 98: Tape Partitions

    Tape and Disk Partitions Tape Partitions Tape partitions refer to data partitions configured on Spectra Logic or other supported tape libraries. When you create a partition on a tape library attached to a BlackPearl gateway, the gateway automatically detects the tape library partition and adds it to the list of available partitions in the BlackPearl user interface.

  • Page 99: Tape Media Inspections

    Disk partitions are comprised of storage pools on external SAS expansion nodes. There are two types of disk partitions. Online disk partitions are created on Spectra 44-bay expansion nodes, while Nearline disk partitions are created on Spectra 96-bay expansion nodes. 107-bay expansion nodes provide either Online or Nearline storage, depending on the type of drives installed.

  • Page 100: Special Considerations For Ejecting Tapes

    ONSIDERATIONS FOR JECTING APES If you plan to eject tapes, Spectra Logic recommends the following storage domain and data policy settings: • Set the Write Optimization setting to Capacity when configuring a storage domain so that data is written to as few tapes as possible.

  • Page 101: Example Configurations

    1024 characters. If you are using a graphical language, such as Japanese, the limit is 512 characters. • Spectra Logic does not recommend the following characters in LTFS file names or BlackPearl object names for reasons of cross-platform compatibility: control characters such as carriage return (CR) and line feed (LF), double quotation mark (“), asterisk (*), question mark (?), less than sign (<), greater than sign (>), backslash...

  • Page 102: Single Copy On Tape

    BlackPearl cache if the gateway detects that more cache space is needed for incoming data. Note: This data policy is automatically created when the gateway detects a tape partition. Figure 46 The Single Copy on Tape workflow. January 2022 User Guide-BlackPearl Nearline Gateway - 102 -...
  • Page 103 Allows an object to be broken into multiple blobs. Enabled Minimize cleared Jobs larger than 1 TB are allowed to span across Spanning multiple tapes or pools as needed to maximize capacity utilization and performance. January 2022 User Guide-BlackPearl Nearline Gateway - 103 -...
  • Page 104 Note: When using a DS3 client, this setting can be overridden when sending a GET job by specifying a different priority in the Get Job command. See the Spectra BlackPearl DS3 API Reference for more information. Default PUT Normal...
  • Page 105 Bucket Standard Data from different buckets can be mixed on to the Isolation Level same piece of media. January 2022 User Guide-BlackPearl Nearline Gateway - 105 -...

  • Page 106: Dual Copy On Tape

    Note: This data policy is created automatically when the gateway detects the first and second tape partitions created on the tape library. Figure 47 The Dual Copy on Tape workflow. January 2022 User Guide-BlackPearl Nearline Gateway - 106 -...
  • Page 107 This domain is created automatically when the gateway detects a tape partition created on the tape library. Days to wait null Data integrity verification is not performed before verifying automatically. data January 2022 User Guide-BlackPearl Nearline Gateway - 107 -...
  • Page 108 Allows an object to be broken into multiple blobs. Minimize cleared Jobs larger than 1 TB are allowed to span across Spanning multiple tapes or pools as needed to maximize capacity utilization and performance. January 2022 User Guide-BlackPearl Nearline Gateway - 108 -...
  • Page 109 Note: When using a DS3 client, this setting can be overridden when sending a GET job by specifying a different priority in the Get Job command. See the Spectra BlackPearl DS3 API Reference for more information. Default PUT Job Normal...
  • Page 110 Bucket Isolation Standard Data from different buckets can be mixed on to the Level same piece of media. January 2022 User Guide-BlackPearl Nearline Gateway - 110 -...

  • Page 111: Single Copy On Nearline Disk

    Note: This data policy is automatically created when the gateway detects a nearline disk partition. Figure 48 The Single Copy on Nearline Disk workflow. January 2022 User Guide-BlackPearl Nearline Gateway - 111 -...
  • Page 112 High write preference and before a partition with Low or Never Select write preference. Data Policy - Single Copy on Nearline Disk Blobbing Enabled selected Allows an object to be broken into multiple blobs. January 2022 User Guide-BlackPearl Nearline Gateway - 112 -...
  • Page 113 Note: When using a DS3 client, this setting can be overridden when sending a GET job by specifying a different priority in the Get Job command. See the Spectra BlackPearl DS3 API Reference for more information. Default PUT Job Normal...
  • Page 114 Data is moved to disk and maintained on disk media until data is deleted from a bucket. Isolation Level Standard Data from different buckets can be mixed on to the same piece of media. January 2022 User Guide-BlackPearl Nearline Gateway - 114 -...

  • Page 115: Single Copy On Nearline Disk And Tape

    BlackPearl cache if the gateway detects that more cache space is needed for incoming data. Note: This data policy is automatically created when the gateway detects a disk partition and a tape partition. Figure 49 The Single Copy on Nearline Disk and Tape workflow. January 2022 User Guide-BlackPearl Nearline Gateway - 115 -...
  • Page 116 Storage Domain - Pool First Copy- Data is written to the primary nearline storage domain. This domain is created automatically after you create a nearline disk partition. Days to wait null Data integrity verification is not performed before verifying automatically. data January 2022 User Guide-BlackPearl Nearline Gateway - 116 -...
  • Page 117 Allows an object to be broken into multiple blobs. Minimize cleared Jobs larger than 1 TB are allowed to span across Spanning multiple tapes or pools as needed to maximize capacity utilization and performance. January 2022 User Guide-BlackPearl Nearline Gateway - 117 -...
  • Page 118 Note: When using a DS3 client, this setting can be overridden when sending a GET job by specifying a different priority in the Get Job command. See the Spectra BlackPearl DS3 API Reference for more information. Default PUT Job Normal...
  • Page 119 Data is moved to disk and maintained on disk media until data is deleted from a bucket. Isolation Level Standard Data from different buckets can be mixed on to the same media. January 2022 User Guide-BlackPearl Nearline Gateway - 119 -...

  • Page 120: Single Copy On Nearline Disk And Dual Copy On Tape

    Note: This data policy is automatically created when the gateway detects a disk partition and two tape partitions. Figure 50 The Single Copy on Nearline Disk and Dual Copy on Tape workflow. January 2022 User Guide-BlackPearl Nearline Gateway - 120 -...
  • Page 121 Data integrity verification is not performed before verifying automatically. data Secure Media cleared Media allocated to the storage domain may be reused Allocation by another storage domain if all data is deleted. January 2022 User Guide-BlackPearl Nearline Gateway - 121 -...
  • Page 122 Data integrity verification is not performed before verifying automatically. data Secure Media cleared Media allocated to the storage domain may be reused Allocation by another storage domain if all data is deleted. January 2022 User Guide-BlackPearl Nearline Gateway - 122 -...
  • Page 123 Note: When using a DS3 client, this setting can be overridden when sending a GET job by specifying a different priority in the Get Job command. See the Spectra BlackPearl DS3 API Reference for more information. January 2022 User Guide-BlackPearl Nearline Gateway...
  • Page 124 Note: When using a DS3 client, this setting can be overridden when sending a PUT job by specifying a different priority in the Put Job command. See the Spectra BlackPearl DS3 API Reference for more information. Default VERIFY When the storage domain receives a VERIFY job, it is...
  • Page 125 Data is moved to disk and maintained on disk media until data is deleted from a bucket. Isolation Level Standard Data from different buckets can be mixed on to the same media. January 2022 User Guide-BlackPearl Nearline Gateway - 125 -...

  • Page 126: Chapter 4 - Configuring Advanced Bucket Management

    Chapter 4 - Configuring Advanced Bucket Management This chapter provides instructions on how to configure Advanced Bucket Management features. It is difficult and time consuming to change a data policy once the gateway writes data to a bucket using the data policy. Make sure that you understand IMPORTANT the concepts in Understanding Advanced Bucket Management on page 92...

  • Page 127: Create A Disk Pool

    Nearline pools created on a 96-bay expansion node have a hard coded capacity utilization limit percentage. On gateways running BlackPearl 5.2 or later, this percentage is 95%. On gateways running BlackPearl 5.1.x or older, the capacity limit percentage is 87%. January 2022 User Guide-BlackPearl Nearline Gateway - 127 -...
  • Page 128 Create a Disk Pool 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management to display the Advanced Bucket Management screen. Figure 51 The Advanced Bucket Management screen. January 2022 User Guide-BlackPearl Nearline Gateway - 128 -...
  • Page 129 Note: The Storage Pool Preview pane does not display until you have selected the disks you want to use in the disk pool. Figure 52 The New Nearline Disk Pool dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 129 -...
  • Page 130 This type of RAID provides the most data protection. 4. Click Create Pool. The new nearline disk pool is listed on the Advanced Bucket Management screen. January 2022 User Guide-BlackPearl Nearline Gateway - 130 -...

  • Page 131: Create An Online Disk Pool

    Use the instructions in this section to create an online disk pool. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management to display the Advanced Bucket Management screen (see Figure 51 page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 131 -...
  • Page 132 Note: The Storage Pool Preview pane does not display until you have selected the disks you want to use in the disk pool. Figure 53 The New Online Disk Pool dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 132 -...

  • Page 133: Create A Disk Partition

    Use the instructions in this section to create a new disk partition. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management. The Advanced Bucket Management screen displays (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 133 -...

  • Page 134: Create A Tape Partition

    Use the Tape Library User Guides on page 29 for your Spectra Logic or other supported tape library to create a partition. Once the BlackPearl gateway detects a partition on a tape library connected to it, the tape partition is automatically listed on the Advanced Bucket Management screen.

  • Page 135: Create A Replication Target

    When you delete data from the source gateway, you can optionally specify to have the data deleted from the target gateway as well. Spectra Logic recommends using the same versioning settings on both the IMPORTANT source and target BlackPearl gateways.
  • Page 136 4. Enter the system name of the target gateway, or the IP address of the target gateway’s data port, as the Data Path End Point. Note: Do not use the IP address of the target gateway’s management port. January 2022 User Guide-BlackPearl Nearline Gateway - 136 -...
  • Page 137 Data Path Port setting automatically changes to 443. Repeat Step 5 if you want to change the data path port to 8443. Using HTTPS for data transfer greatly impacts data transfer speed. Spectra IMPORTANT Logic recommends leaving this disabled if it is not required for your data storage environment.
  • Page 138 Replicated User Default Data Policy. If configured, the gateway uses this target data policy as the default data policy for any users replicated to the target. January 2022 User Guide-BlackPearl Nearline Gateway - 138 -...

  • Page 139: Create An Amazon S3 Target

    Use the instructions in this section to configure an Amazon S3 target. 1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen (see Figure 55 on page 136). January 2022 User Guide-BlackPearl Nearline Gateway - 139 -...
  • Page 140 • Object ID - objects display a UUID when viewed on the Amazon target. • Object Name - objects display their name when viewed on the Amazon target. 4. Enter a name for the Amazon S3 target in the Name field. January 2022 User Guide-BlackPearl Nearline Gateway - 140 -...
  • Page 141 BlackPearl gateway uses to confirm valid credentials when a data path endpoint and region are entered in Step 5. Note: Spectra Logic recommends against using Restricted Access. 8. Enter the S3 Access Key of a user with administrator privileges for the Amazon S3 account in the Access Key field.
  • Page 142 This setting determines when data is read back from the Amazon S3 target, if needed. Note: Spectra Logic recommends that Default Read Preference be kept at the default of Last Resort. Name...

  • Page 143: Create A Microsoft Azure Target

    Use the instructions in this section to configure a Microsoft Azure target. 1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen(see Figure 55 on page 136). January 2022 User Guide-BlackPearl Nearline Gateway - 143 -...
  • Page 144 Cloud Bucket Suffix=suffix, and the bucket name=name, the resulting name of the bucket on the Azure target is prefix-name-suffix. Note: The prefix and/or suffix must adhere to the replication target naming requirements. January 2022 User Guide-BlackPearl Nearline Gateway - 144 -...

  • Page 145: Create A Storage Domain

    This setting determines when data is read back from the Microsoft Azure target, if needed. Note: Spectra Logic recommends that Default Read Preference be kept at the default of Last Resort. Name...
  • Page 146 • Disk pools are not subject to automatic data integrity verification. However, you can initiate data integrity verification for disk pools manually. See Data Integrity Verification - Disk Media on page 391 for more information. January 2022 User Guide-BlackPearl Nearline Gateway - 146 -...
  • Page 147 Note: Only use performance mode at the direction of Spectra Logic. For more information on capacity and performance modes, see Capacity Mode versus Performance Mode on page 421.
  • Page 148 LTFS file system (e.g. directory1/directory2/video1.mov). • Spectra Logic does not recommend the following characters in LTFS file names or BlackPearl object names for reasons of cross-platform compatibility: control characters such as carriage return (CR) and line feed (LF), double quotation mark (“), asterisk (*), question mark (?), less than sign (<), greater than sign (>),...
  • Page 149 Create an Hourly Schedule i. Select Hourly as the interval for the tape ejection schedule (see Figure 59 on page 146). January 2022 User Guide-BlackPearl Nearline Gateway - 149 -...

  • Page 150: Add A Storage Domain Member To A Storage Domain

    48, where tapes are ejected every two days. Note: Spectra Logic recommends offsetting the minutes after the hour for starting tape ejections so that there are not a large number of jobs starting at exactly the same time.
  • Page 151 You cannot add a disk partition to a storage domain that already uses a tape partition, and you cannot add a tape partition to a storage domain that already uses a disk partition. January 2022 User Guide-BlackPearl Nearline Gateway - 151 -...

  • Page 152: Create A Data Policy

    Use the instructions in this section to create a new data policy. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 152 -...
  • Page 153 1 TB, to use multi-part upload, or to break up an object into multiple blobs. Note: Disabling blobbing guarantees that an object will never span multiple tapes or disk pools, since a blob cannot span multiple media. January 2022 User Guide-BlackPearl Nearline Gateway - 153 -...
  • Page 154 • Selecting Default Verify After Write reduces gateway write throughput by up to 50%. • This setting does not apply to replication targets. e. Use the drop-down menu to select the Rebuild Priority. January 2022 User Guide-BlackPearl Nearline Gateway - 154 -...
  • Page 155 PUT of the latest version, the BlackPearl gateway believes CAUTION the latest version to be the same object as the earlier version and rejects it, and only the earlier version is retained. January 2022 User Guide-BlackPearl Nearline Gateway - 155 -...

  • Page 156: New Data Policy Acl For A Group

    ACL For Group dialog box displays. Figure 63 The New Data Policy ACL For Group dialog box. 4. Using the Name drop-down menu, select the group to be assigned to the data policy ACL. 5. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 156 -...

  • Page 157: New Data Policy Acl For A User

    Add a Data Persistence Rule to a Data Policy 1. If necessary, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 157 -...
  • Page 158 3. Select Action > New Data Persistence Rule. The New Data Persistence Rule dialog box displays. Figure 66 The New Data Persistence Rule dialog box. 4. Use the Storage Domain drop-down menu to select a storage domain from the list of previously created storage domains. January 2022 User Guide-BlackPearl Nearline Gateway - 158 -...
  • Page 159 (an 96-bay or 107-bay expansion node) must be 90 days or greater. • Minimum Days to Retain cannot be specified when using a Type of Permanent. 8. Click Create. The new data persistence rule displays on the Data Policy details screen. January 2022 User Guide-BlackPearl Nearline Gateway - 159 -...
  • Page 160 Permanent or Retired. Note: You cannot create a replication rule as Retired. You can only modify a rule from permanent to retired after the data policy is created. January 2022 User Guide-BlackPearl Nearline Gateway - 160 -...
  • Page 161 2. Double-click the data policy in the Data Policies pane, or select the data policy and select Action > Show Details from the menu bar. The Data Policy details screen displays (see Figure 65 on page 158). January 2022 User Guide-BlackPearl Nearline Gateway - 161 -...
  • Page 162 7. Select or clear the Replicate Deletes check box. When selected, any time a replicated file is deleted from the source gateway, it is also deleted from the target. January 2022 User Guide-BlackPearl Nearline Gateway - 162 -...
  • Page 163 Figure 69 The New Microsoft Azure Data Replication Rule dialog box. 4. Use the Microsoft Azure Target drop-down menu to select a Microsoft Azure replication target from the list of previously created replication targets. January 2022 User Guide-BlackPearl Nearline Gateway - 163 -...

  • Page 164: Create A Bucket

    If you are creating a bucket that is used in a BlackPearl replication IMPORTANT configuration, you must create the bucket on the source gateway, and let it replicate to the target gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 164 -...
  • Page 165 1. From the menu bar, select Configuration > Buckets. The Buckets screen displays. Figure 70 The Buckets screen. 2. Select Action > New from the menu bar. The New Bucket dialog box displays. Figure 71 The New Bucket dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 165 -...

  • Page 166: Create A New Bucket Acl For A Group

    Use the instructions in this section to create a new Access Control List (ACL) using the specified group for a bucket. 1. From the menu bar, select Configuration > Buckets. The Buckets screen displays (see Figure 70 on page 165). January 2022 User Guide-BlackPearl Nearline Gateway - 166 -...
  • Page 167 • OWNER — The users receives full access to the bucket, including all permissions listed above, and also receives permission to modify bucket ACLs for that bucket. January 2022 User Guide-BlackPearl Nearline Gateway - 167 -...

  • Page 168: Create A New Bucket Acl For A User

    3. Select Action > New Bucket ACL For User. The New Bucket ACL For User dialog box displays. Figure 75 The New Bucket ACL For User dialog box. 4. Using the Name drop-down list, select a user from the list of exiting users on the BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 168 -...

  • Page 169: Transfer Data

    • To transfer data using a DS3 client, consult the Spectra BlackPearl DS3 API Reference, and documentation specific to each DS3 client. Contact Spectra Logic Professional Services for assistance in setting up data IMPORTANT transfer. See Contacting Spectra Logic on page 8.

  • Page 170: Chapter 5 - Managing Advanced Bucket Management Settings

    Chapter 5 - Managing Advanced Bucket Management Settings This chapter describes using the BlackPearl user interface to manage storage domains, data policies, disk partitions, and buckets on the gateway after configuring Advanced Bucket Management. For initial Advanced Bucket Management configuration steps, see Configuring Advanced Bucket Management on page 126.

  • Page 171: Manage A Storage Domain

    Delete a Bucket ACL Edit a Bucket Delete a Bucket ANAGE A TORAGE OMAIN Use the instructions in this section to edit or delete a storage domain member or a storage domain. January 2022 User Guide-BlackPearl Nearline Gateway - 171 -...

  • Page 172: Edit A Storage Domain Member

    Note: When editing a storage domain member, the Partition and Tape Type settings are unavailable. 6. Click Save. The edited storage domain member displays on the Storage Domain details screen. January 2022 User Guide-BlackPearl Nearline Gateway - 172 -...

  • Page 173: Exclude A Storage Domain Member

    Do not click the partition name when selecting the data persistence rule row or the Partition details screen will open. The Cancel Storage Domain Member Exclusion dialog box displays. 4. Type CANCEL in the entry field and then click Cancel. January 2022 User Guide-BlackPearl Nearline Gateway - 173 -...

  • Page 174: Delete A Storage Domain Member

    Do not click the partition name when selecting the data persistence rule row or the Partition details screen will open. A confirmation dialog box displays. Figure 77 The delete storage domain member confirmation dialog box. 4. Type DELETE into the entry field, and then click Delete. January 2022 User Guide-BlackPearl Nearline Gateway - 174 -...

  • Page 175: Edit A Storage Domain

    Alternatively, select Action > Edit Storage Domain from the storage domain details screen. Figure 78 The Edit Storage Domain dialog box. 3. Edit the fields as necessary. See Create a Storage Domain on page 145 for a description of each field. January 2022 User Guide-BlackPearl Nearline Gateway - 175 -...

  • Page 176: Delete A Storage Domain

    If an edit is not allowed, an error message displays when you click Save. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 176 -...

  • Page 177: Edit An Amazon S3 Data Replication Rule

    If an edit is not allowed, an error message displays when you click Save. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 177 -...

  • Page 178: Edit A Microsoft Azure Data Replication Rule

    If an edit is not allowed, an error message displays when you click Save. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 178 -...

  • Page 179: Delete A Data Replication Rule

    2. Double-click the data policy with the replication rule that you want to delete, or select the data policy and then select Action > Show Details. The Data Policy details screen displays (see Figure 65 on page 158). January 2022 User Guide-BlackPearl Nearline Gateway - 179 -...

  • Page 180: Manage A Data Policy

    Checksum type if the data policy is used by a bucket. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 180 -...

  • Page 181: Delete A Data Policy

    1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 181 -...

  • Page 182: Delete A Data Policy Acl

    If an edit is not allowed, an error message displays when you click Save. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 182 -...
  • Page 183 Add Data Persistence Rules and Replication Rules to a Data Policy on page 157 for a description of each field. 6. Click Save. The edited data persistence rule displays on the Data Policy details screen. January 2022 User Guide-BlackPearl Nearline Gateway - 183 -...

  • Page 184: Delete A Data Persistence Rule

    Storage Domain details screen will open. A confirmation dialog box displays. Figure 87 The delete data persistence rule confirmation dialog box. 4. Type DELETE into the entry field, and then click Delete. January 2022 User Guide-BlackPearl Nearline Gateway - 184 -...

  • Page 185: Change The Blackpearl Gateway Cache Configuration

    Migrate any data you want to keep off of the system cache. 2. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management to display the Advanced Bucket Management screen (see Figure 51 page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 185 -...

  • Page 186: Manage Replication Targets

    9. The BlackPearl gateway creates a new system cache and reboots. ANAGE EPLICATION ARGETS Use the instruction in this section to manage existing replication targets. January 2022 User Guide-BlackPearl Nearline Gateway - 186 -...

  • Page 187: Edit A Blackpearl Replication Target

    Use the instructions in this section to modify the configuration of an existing Amazon replication target. 1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 187 -...

  • Page 188: Edit An Azure Replication Target

    Use the instructions in this section to modify the configuration of an existing Azure replication target. 1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 188 -...

  • Page 189: Verify A Replication Target

    Use the instructions in this section to verify connectivity to the target and optionally verify replicated data on the replication target. 1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 189 -...

  • Page 190: Put A Replication Target In Standby State

    1. From the menu bar, select Configuration > Advanced Bucket Management > Replication Targets to display the Replication Targets screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 190 -...

  • Page 191: Activate A Replication Target

    2. Select the replication target that you want to activate and then select Action > Activate Target. The Activate Target dialog box displays. Figure 94 The Activate Target dialog box. 3. Click Activate. The target is now in an active state. January 2022 User Guide-BlackPearl Nearline Gateway - 191 -...

  • Page 192: Delete A Replication Target

    Figure 95 The Delete target type Target dialog box. 3. Click Delete to delete the selected replication target. ANAGE A ARTITION Use the instructions in this section to edit or delete a disk partition. January 2022 User Guide-BlackPearl Nearline Gateway - 192 -...

  • Page 193: Edit A Disk Partition

    1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Data Policy Management to display the Advanced Bucket Management screen (see Figure 51 on page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 193 -...

  • Page 194: Manage Online And Nearline Disk Pools

    Configure the DS3 Service on page 274 for more information. 3. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management to display the Advanced Bucket Management screen (see Figure 51 page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 194 -...
  • Page 195 Using the drop-down menu, select the User to be the owner of the imported bucket(s). b. Using the drop-down menu, select the Data Policy to use for the imported bucket(s). January 2022 User Guide-BlackPearl Nearline Gateway - 195 -...

  • Page 196: Delete A Nearline Or Online Disk Pool

    UCKETS Use the instructions in this section to configure ACLs for a bucket, edit, or delete a bucket. For instructions on creating a new bucket, see Create a Bucket on page 164. January 2022 User Guide-BlackPearl Nearline Gateway - 196 -...

  • Page 197: Show Bucket Physical Placement

    1. From the menu bar, select Configuration > Buckets. The Buckets screen displays (see Figure 70 on page 165). 2. Select the bucket for which you want to edit an ACL and select Action > Show Details. The bucket details screen displays (see Figure 72 on page 167). January 2022 User Guide-BlackPearl Nearline Gateway - 197 -...

  • Page 198: Delete A Bucket Acl

    Use the instructions in this section to change the owner of a bucket or to change the data policy used by the bucket. 1. From the menu bar, select Configuration > Buckets. The Buckets screen displays (see Figure 70 on page 165). January 2022 User Guide-BlackPearl Nearline Gateway - 198 -...

  • Page 199: Delete A Bucket

    1. From the menu bar, select Configuration > Buckets. The Buckets screen displays (see Figure 70 on page 165). January 2022 User Guide-BlackPearl Nearline Gateway - 199 -...
  • Page 200 2. Select the bucket you want to delete and select Action > Delete. A confirmation dialog box displays. Figure 104 The bucket delete confirmation dialog box. 3. Type DELETE BUCKET into the entry field, and then click Delete. January 2022 User Guide-BlackPearl Nearline Gateway - 200 -...

  • Page 201: Chapter 6 - Configuring Network Attached Storage

    Chapter 6 - Configuring Network Attached Storage This chapter describes using the BlackPearl user interface to configure Network Attached Storage storage pools, volumes, and shares on a BlackPearl gateway. If you have not purchased a NAS activation key, these features do not display in the BlackPearl user interface.

  • Page 202: Storage Pools

    When creating a new NAS pool, keep the following in mind: • Each storage pool requires a minimum of one drive. Spectra Logic recommends using eight drives or more in a storage pool to reduce the impact of the overhead. Overhead is the space on the storage pool used to store parity data, and not used for data storage.
  • Page 203 Use the following steps to create a new NAS storage pool. 1. From the menu bar, select Configuration > NAS > Pools, or click the Pools pane on the Dashboard. The NAS Pools screen displays. Figure 105 The NAS Pools screen. January 2022 User Guide-BlackPearl Nearline Gateway - 203 -...
  • Page 204 Note: The Storage Pool Preview pane does not display until you have selected the disks you want to use in the storage pool Figure 106 The New Pool dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 204 -...
  • Page 205 Notes: • The combined storage pool and volume name must be 78 characters or fewer. To avoid problems sharing volumes, Spectra Logic recommends a pool name of 32 characters or fewer. • Each pool name must be unique. This field is case sensitive. Only the following special characters are allowed: hyphen (-), underscore (_), colon (:), and period(.).
  • Page 206 These drives are permanently part of the storage pool and cannot be removed. 4. Click Create. The NAS Pools screen displays. The storage pool is automatically created and is available for use immediately. January 2022 User Guide-BlackPearl Nearline Gateway - 206 -...

  • Page 207: Create A Volume

    If you want to configure the volume to use the NFI service (Network File Interface) to automatically transfer files from the NAS storage to the local gateway’s storage domains or to a remote BlackPearl Nearline gateway, configure the NFI service before configuring the volume. See Configure the NFI Service on page 224.
  • Page 208 For example, for a volume named Share One, the corresponding NFS share is named Share_One to external network computers, but it is named Share One in the BlackPearl user interface. January 2022 User Guide-BlackPearl Nearline Gateway - 208 -...
  • Page 209 If compression is enabled and non-compressible data is written to the volume, the compression process may use an excessive number of CPU cycles, slowing the overall performance of the gateway. This impact is less evident with Gen2 master nodes. January 2022 User Guide-BlackPearl Nearline Gateway - 209 -...
  • Page 210 Configure the NFI Volume Policy The NFI service is used to automatically transfer files from the NAS volume to the local gateway’s storage domains or to a remote BlackPearl Nearline gateway. If you do not want to configure NFI for this volume, continue with Step 4 on page 214.
  • Page 211 • Create a Daily Schedule on page 213—Transfer data every selected number of days. • Create a Weekly Schedule on page 214—Transfer data on certain days of the week. January 2022 User Guide-BlackPearl Nearline Gateway - 211 -...
  • Page 212 48, where the NAS volume transfers data every two days. The maximum setting for the minute field is 59. Note: Spectra Logic recommends offsetting the minutes after the hour for starting NFI transfers so that there are not a large number of jobs starting at exactly the same time.
  • Page 213 31st of the month (for months that have 31 days). To schedule data transfers on the first of every month, set the interval to 31 days. 4. Continue to Step 4 on page 214. January 2022 User Guide-BlackPearl Nearline Gateway - 213 -...
  • Page 214 3. Select one or more days for Every week on:. This determines the day(s) of each week the NAS volume copies data to the BlackPearl gateway. 4. Click Create. The Volumes screen refreshes to show the new volume. January 2022 User Guide-BlackPearl Nearline Gateway - 214 -...

  • Page 215: Create A Share

    Configure the Data Connection on page 80. Create a CIFS Share Spectra Logic recommends using Active Directory to control access to CIFS shares on the BlackPearl gateways. To do this, continue with Join an Active Directory Domain, below. However, if your Windows operating system environment does not use Active Directory, you can enable local administrator status on the gateway to allow a specified user to access the CIFS shares in a Windows workgroup environment.
  • Page 216 2. Double-click the row for the user for which you want to enable local administrator status, or select the user, and then select Action > Edit. The Edit User dialog box displays. Figure 113 The Edit User dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 216 -...
  • Page 217 3. Use the drop-down menu to select the Volume you want to share. Note: Creating a CIFS share on a case-sensitive volume reduces performance. 4. Set the Name for the CIFS share. This is the name that is displayed in Active Directory configurations. January 2022 User Guide-BlackPearl Nearline Gateway - 217 -...
  • Page 218 Active Directory Domain administrator password. 1. Mount the new CIFS share to your Microsoft Windows operating system host. January 2022 User Guide-BlackPearl Nearline Gateway - 218 -...
  • Page 219 Properties window displays. Note: You cannot use the Computer Management panel to set permissions on CIFS shares. Figure 116 The Properties window. 3. Click Security. The Security tab displays. Figure 117 The Security tab. January 2022 User Guide-BlackPearl Nearline Gateway - 219 -...

  • Page 220: Create An Nfs Share

    2. Select Action > New. The New NFS Share dialog box displays. Figure 119 The New NFS Share dialog box. 3. Use the drop-down menu to select the Volume you want to share. January 2022 User Guide-BlackPearl Nearline Gateway - 220 -...
  • Page 221 5. If desired, enter a comment in the Comment field. This comment only displays on the BlackPearl Nearline user interface. 6. In the Host Access Control pane, enter the IP address and permission level of all hosts that you want to access the volume.

  • Page 222: Configure Nas Services

    There are no configurable settings for the CIFS service at this time, but you can add an advanced parameter, if desired. Note: For information about using CIFS shares and joining an Active Directory domain, Create a CIFS Share on page 215. January 2022 User Guide-BlackPearl Nearline Gateway - 222 -...
  • Page 223 3. Select Action > Add Advanced Parameter. The Add Advanced Parameter dialog box displays. Figure 122 The Add Advanced Parameter dialog box. 4. Enter the desired Parameter and Value. 5. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 223 -...

  • Page 224: Configure The Nfi Service

    Figure 124 The Configure dialog box for a local BlackPearl gateway. a. Select Use local BlackPearl. b. Using the drop-down menu, select the S3 Username to use for the NFI service. c. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 224 -...

  • Page 225: Configure The Nfs Service

    1. Select Configuration > Services to display the Services screen (see Figure 121 on page 222). 2. Double-click the NFS service, or select the service, and then select Action > Show Details. The NFS service details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 225 -...

  • Page 226: Configure Nas Replication

    NAS replication targets. Replication uses the same data interface that the gateway uses for normal file storage operations, so replication to multiple targets may decrease transfer speeds. January 2022 User Guide-BlackPearl Nearline Gateway - 226 -...
  • Page 227 Figure 121 on page 222). 2. Double-click the Replication service, or select the service, and then select Action > Show Details. The Replication service details screen displays. Figure 127 The Replication service details screen. January 2022 User Guide-BlackPearl Nearline Gateway - 227 -...
  • Page 228 1. Log into the BlackPearl on the target system as described in Log Into the BlackPearl User Interface on page 78. 2. Create one or more storage pools as described in Create a NAS Storage Pool on page 202. January 2022 User Guide-BlackPearl Nearline Gateway - 228 -...
  • Page 229 6. Enter the name of the storage pool on the target you want to use for replication in the Destination Pool Name. This field is case sensitive. January 2022 User Guide-BlackPearl Nearline Gateway - 229 -...
  • Page 230 The maximum setting for the minute field is 59. Note: Spectra Logic recommends offsetting the minutes after the hour for starting replications so that there are not a large number of jobs starting at exactly the same time.
  • Page 231 Step 2. A value of 30 runs on the 1st of the month, and then again on the 31st of the month (for months that have 31 days). To schedule data replication on the first of every month, set the interval to 31 days. 4. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 231 -...
  • Page 232 3. Select one or more days for Every week on:. This determines the day(s) of each week the NAS volume replicates data. For example, based on the selections in Figure 131, the NAS volume replicates data every Monday, Wednesday, and Friday at 5:00 AM. 4. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 232 -...

  • Page 233: Chapter 7 - Managing Network Attached Storage

    Chapter 7 - Managing Network Attached Storage This chapter describes using the BlackPearl user interface to manage storage pools, volumes, and shares on the gateway after configuring NAS. For initial NAS configuration steps, see Configuring Network Attached Storage on page 201. Manage Storage Pools Edit a Storage Pool Expand a Storage Pool...

  • Page 234: Manage Storage Pools

    Use the following steps to edit a storage pool. 1. From the menu bar, select Configuration > NAS > Pools, or click the Pools pane on the Dashboard. The NAS Pools screen displays (see Figure 105 on page 203). January 2022 User Guide-BlackPearl Nearline Gateway - 234 -...

  • Page 235: Expand A Storage Pool

    1. From the menu bar, select Configuration > NAS > Pools, or click the Pools pane on the Dashboard. The NAS Pools screen displays (see Figure 105 on page 203). January 2022 User Guide-BlackPearl Nearline Gateway - 235 -...
  • Page 236 Spectra Logic recommends that you avoid mixing drive types in a pool. 4. Use the slider to increase the number of drives to use in the storage pool. As you make changes, the graphics beneath the slider update to show the impact your changes have on the storage pool.

  • Page 237: Delete A Storage Pool

    4. If desired, create a new storage pool that includes the disks no longer in use, as described Create a NAS Storage Pool on page 202. ANAGE OLUMES After creating one or more volumes, use the instructions in this section to move, edit, or delete a volume. January 2022 User Guide-BlackPearl Nearline Gateway - 237 -...

  • Page 238: Move A Volume

    3. Click Cancel Move to cancel the in-progress volume move. Note: The data on the target pool is deleted. Data on the source pool is unaffected and persists on the source pool after canceling the move. January 2022 User Guide-BlackPearl Nearline Gateway - 238 -...

  • Page 239: Edit A Volume

    Figure 107 on page 207). 2. Double-click the volume you want to edit, or select the volume and then select Action > Edit. The Edit Volume name screen displays. Figure 136 The Edit Volume screen. January 2022 User Guide-BlackPearl Nearline Gateway - 239 -...
  • Page 240 Selecting Access Time may slow performance. Read Only If desired, select the check box to configure the volume so that data can be read, but not written to the volume. January 2022 User Guide-BlackPearl Nearline Gateway - 240 -...

  • Page 241: Delete A Volume

    Deleting a volumes deletes all data in the volume. This action cannot be CAUTION undone. Figure 137 Confirm the volume deletion. 3. Type DELETE VOLUME in the entry field and click Delete to delete the volume. January 2022 User Guide-BlackPearl Nearline Gateway - 241 -...

  • Page 242: Volume Snapshots

    Use the following steps to create a snapshot. 1. From the menu bar, select Configuration > NAS > Volumes, or click the Volumes pane on the Dashboard. The Volumes screen displays (see Figure 107 on page 207). January 2022 User Guide-BlackPearl Nearline Gateway - 242 -...
  • Page 243 Figure 139 The New Snapshot dialog box. 4. Enter a name for the snapshot in the Name field. 5. Click Create. The Volume details screen displays showing the newly created snapshot. January 2022 User Guide-BlackPearl Nearline Gateway - 243 -...

  • Page 244: Create A Snapshot Schedule

    3. Change the default name of the snapshot schedule, if desired. 4. Enter a number for the Maximum Number of Snapshots. When the maximum number is reached, the gateway deletes the oldest snapshot. January 2022 User Guide-BlackPearl Nearline Gateway - 244 -...
  • Page 245 48, where the NAS volume creates a snapshot every two days. The maximum setting for the minute field is 59. Note: Spectra Logic recommends offsetting the minutes after the hour for starting snapshots so that there are not a large number of jobs starting at exactly the same time.
  • Page 246 6. Select one or more days for Every week on:. This determines the day(s) of each week the NAS volume generates snapshots. For example, based on the selections in Figure 142, the NAS volume creates a snapshot every Monday, Wednesday, and Friday at 5:00 AM. 7. Click Create. January 2022 User Guide-BlackPearl Nearline Gateway - 246 -...

  • Page 247: Delete A Snapshot Schedule

    Use the following steps to delete a one or more snapshots. 1. From the menu bar, select Configuration > NAS > Volumes, or click the Volumes pane on the Dashboard. The Volumes screen displays (see Figure 107 on page 207). January 2022 User Guide-BlackPearl Nearline Gateway - 247 -...
  • Page 248 A confirmation window displays. Figure 145 Confirm the snapshot deletion (Delete Snapshot window shown). 4. Type the indicated text in the entry field and click Delete to delete the selected snapshot, or all snapshots. January 2022 User Guide-BlackPearl Nearline Gateway - 248 -...

  • Page 249: Restore To A Snapshot

    Rollback deletes all data changes made after the snapshot was created, and CAUTION deletes any snapshots that were saved after the one you are using for the restore process. This action cannot be undone. January 2022 User Guide-BlackPearl Nearline Gateway - 249 -...

  • Page 250: Retrieve A Single File From A Snapshot

    4. Locate the file you want to restore and copy it to the appropriate location. ANAGE HARES After creating one or more shares, use the instructions in this section to edit, or delete a share. January 2022 User Guide-BlackPearl Nearline Gateway - 250 -...

  • Page 251: Edit A Cifs Share

    Edit an NFS Share After creating an NFS share, you can edit it to change the configuration. 1. From the menu bar, select Configuration > Shares > NFS. The NFS Shares screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 251 -...

  • Page 252: Delete A Share

    If you need to delete an NFS share, from the menu bar, select Configuration > Shares > NFS. The NFS Shares screen displays. 2. Select the share you want to delete, and then select Action > Delete. January 2022 User Guide-BlackPearl Nearline Gateway - 252 -...

  • Page 253: Manage Nas Replication

    1. On the source system’s BlackPearl user interface, select Configuration > NAS > Volumes. The Volumes screen displays. 2. Double-click the volume name you want to replicate, or select the volume and select Action > Show Details. The details screen for the volume displays. January 2022 User Guide-BlackPearl Nearline Gateway - 253 -...

  • Page 254: Cancel A Nas Replication In Progress

    2. Double-click the volume name for which you want to cancel replication, or select the volume and select Action > Show Details. The details screen for the volume displays. 3. Select Action > Cancel Replication. A confirmation window displays. Figure 152 The Cancel Replication confirmation window. January 2022 User Guide-BlackPearl Nearline Gateway - 254 -...

  • Page 255: Restoring Files From A Nas Replication Target

    3. If desired, write protect the replicated volume before you copy files from the volume. Note: Spectra Logic highly recommends that you write-protect the volume after sharing a. From the menu bar, select Configuration > NAS > Volumes. The Volumes screen displays.

  • Page 256: Disable Nas Replication For A Volume

    5. Click Configure. The volume no longer replicates to the target. Edit the NAS Replication Service 1. On the source gateway’s BlackPearl user interface, select Configuration > Services to display the Services screen (see Figure 171 on page 274). January 2022 User Guide-BlackPearl Nearline Gateway - 256 -...
  • Page 257 8. If desired, select the Enable Secure Transfer check box to configure the gateway to encrypt the replicated data before transferring it to the target, or clear the check box to transfer data without encryption. Data is encrypted using Secure Socket Layer (SSL). 9. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 257 -...

  • Page 258: Delete The Nas Replication Service Configuration

    1. From the menu bar, select Configuration > Services to display the Services screen. 2. Double-click the NFI service, or select the service, and then select Action > Show Details. The details screen for the NFI service displays. Figure 157 The NFI service details screen. January 2022 User Guide-BlackPearl Nearline Gateway - 258 -...

  • Page 259: Delete The Nfi Service Configuration

    Action > Show Details. The details screen for that volume displays. 3. Select Action > Initiate NFI Transfer. 4. Click Initiate NFI Transfer to begin the replication. January 2022 User Guide-BlackPearl Nearline Gateway - 259 -...

  • Page 260: Reinitialize Nfi Replication

    4. Type REINITIALIZE in the entry field and click Reinitialize to reinitialize the NFI transfer. Edit the NFI Volume Policy Use the instructions in Configure a Volume to change how data is copied from the NAS volume to a BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 260 -...

  • Page 261: Restoring Files From An Nfi Target Blackpearl Gateway

    BlackPearl storage domains using the Spectra EON Browser, Spectra Deep Storage Browser, or a DS3 client. If you only need to retrieve a small number of files, Spectra Logic recommends using the EON Browser.

  • Page 262: Chapter 8 - Additional Configuration Options

    Chapter 8 - Additional Configuration Options This chapter describes using the BlackPearl user interface to configure additional options for the Spectra BlackPearl Nearline Gateway. Configure Network Connections and Settings Configure Ethernet Ports Configure DNS Settings Configure SMTP Settings Configure Date and Time...

  • Page 263: Configure Network Connections And Settings

    Use the Network screen to edit the system name, configure Ethernet ports and DNS settings, and to enter SMTP and NTP information. Note: If configuring a HotPair system, see the Spectra BlackPearl HotPair Installation & Configuration Guide for instructions on configuring network connections. Figure 160 The Network screen.

  • Page 264: Configure Ethernet Ports

    Clear a Data Port Configuration on page 269 Configure the Management Port 1. From the menu bar, select Configuration > Network, or click the Network pane from the Dashboard screen. The Network screen displays (see Figure 160 on page 263). January 2022 User Guide-BlackPearl Nearline Gateway - 264 -...
  • Page 265 • If you selected DHCP in Step 3 on page 265, this option is unavailable. • The gateway entered for the last configured IPv4 connection sets the default gateway for the BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 265 -...
  • Page 266 2. Select the row of the data connection you want to edit and select Action > Edit. The Edit Aggregate Data Connection dialog box displays. Figure 162 The Edit Aggregate Data dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 266 -...
  • Page 267 If desired, you can edit a data connection after it is created. 1. From the menu bar, select Configuration > Network, or click the Network pane from the Dashboard screen. The Network screen displays (see Figure 160 on page 263). January 2022 User Guide-BlackPearl Nearline Gateway - 267 -...
  • Page 268 7. Change the MTU (Maximum Transmission Unit) value, if desired. If you set the MTU value to something other than 1500, ensure that your switch configuration supports larger MTU settings, as well as all the hosts on the network. January 2022 User Guide-BlackPearl Nearline Gateway - 268 -...
  • Page 269 2. Select the row of the configuration you want to clear and select Action > Clear from the menu bar. A confirmation window displays. 3. Click Delete to clear the Ethernet configuration. January 2022 User Guide-BlackPearl Nearline Gateway - 269 -...

  • Page 270: Configure Dns Settings

    Enter the IP address of one or more name servers in the Name Servers field. b. Enter the URL of one or more search domains in the Search Domains field. 5. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 270 -...

  • Page 271: Configure Smtp Settings

    This email address should uniquely identify the BlackPearl gateway to assist in troubleshooting and be recognized by the SMTP server as a valid domain address. January 2022 User Guide-BlackPearl Nearline Gateway - 271 -...

  • Page 272: Configure Date And Time

    A calendar appears. Select the current date. b. If you select NTP, enter the NTP server information for the Primary NTP Server. If desired, enter the NTP server information for the Secondary NTP Server. 4. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 272 -...

  • Page 273: Edit The System Name

    • Invalid - BlackPearlGateway.domain.com • If your gateway is using firmware BlackPearl 3.2.2, or earlier, there are no character restrictions on system names. However, Spectra Logic recommends limiting system names to letters, numbers, and hyphens to maintain compatibility with the RFC 1123 standard.

  • Page 274: Configure Networking Services

    1. From the menu bar, select Configuration > Services to display the Services screen (see Figure 93 on page 164). 2. Double-click the S3 service, or select the S3 service and select Action > Show Details. The S3 details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 274 -...
  • Page 275 • To manually start the data path backend, see Reboot or Shut Down a BlackPearl Gateway on page 378. • If the Auto-Activate Timeout is set to 0, the data path backend will never auto- activate. January 2022 User Guide-BlackPearl Nearline Gateway - 275 -...
  • Page 276 IOM Start Time and IOM Stop Time. Note: If you set the start and stop time to the same value, IOM operations do not run. Disabled The BlackPearl gateway does not perform any IOM operations. January 2022 User Guide-BlackPearl Nearline Gateway - 276 -...
  • Page 277 Chapter 8 - Additional Configuration Options Configure Networking Services Notes: • IOM is enabled by default. Spectra Logic recommends leaving the feature enabled. • Automatic tape compaction is configured on a per tape partition basis (see Tape Partition Drive Reservation on page 328 for more information).

  • Page 278: Configure The Active Directory Service

    1. From the menu bar, select Configuration > Services. The Services screen displays (see Figure 171 on page 274). 2. Double-click the Active Directory row, or select the Active Directory row and select Action > Show Details. The Active Directory details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 278 -...
  • Page 279 Active Directory domain. The gateway does not save this information. 8. If desired, select Allow Trusted Domains if the Active Directory domain you want to join is a trusted domain. 9. Click Join Domain. January 2022 User Guide-BlackPearl Nearline Gateway - 279 -...
  • Page 280 1. From the menu bar, select Configuration > Services. The Services screen displays (see Figure 171 on page 274). 2. Double-click the Active Directory row, or select the Active Directory row and select Action > Show Details. The Active Directory details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 280 -...
  • Page 281 1. From the menu bar, select Configuration > Services. The Services screen displays (see Figure 171 on page 274). 2. Double-click the Active Directory row, or select the Active Directory row and select Action > Show Details. The Active Directory details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 281 -...
  • Page 282 2. Double-click the Active Directory row, or select the Active Directory row and select Action > Show Details. The Active Directory details screen displays. 3. Select Action > Leave Domain. A confirmation window displays. 4. Click Leave Domain. January 2022 User Guide-BlackPearl Nearline Gateway - 282 -...

  • Page 283: Configure The Snmp Service

    6. Enter the physical location of the gateway in the Location field. 7. If desired, add clients that are allowed to access the gateway using SNMP. Figure 178 The Edit SNMP Service dialog box. a. Click the + sign to add a client. January 2022 User Guide-BlackPearl Nearline Gateway - 283 -...
  • Page 284 8. Click Save. Download the MIB File If you want to communicate with the gateway using SNMP, you must first download the BlackPearl Nearline MIB (Management Information Base) file, and load the file into a ® ® compatible network node manager program, such as HP OpenView 1.

  • Page 285: Configure A Vail Sphere

    Register with a Vail Sphere The Vail service configures a BlackPearl gateway for use with a Spectra Vail sphere. The Vail service only displays in the Services menu after an activation key is entered. Use the instructions in this section to register a Vail sphere with a BlackPearl gateway.
  • Page 286 S3 service is not currently using. If necessary, see the S3 service details screen to determine the ports currently in use by the S3 service. • For new BlackPearl gateways, Spectra Logic recommends using the 80/443 pair of ports.

  • Page 287: Configure And Use Encryption

    Tape Library User Guides on page 29 information about tape encryption. • The encryption provided by SEDs is 'encryption at rest'. If a drive is stolen the data on it is unreadable. January 2022 User Guide-BlackPearl Nearline Gateway - 287 -...

  • Page 288: Configure The Encryption Service

    Details. The details screen for the Encryption service displays. Figure 183 The Encryption service details screen. 3. Select Action > Edit Service. The Edit Encryption Service dialog box displays. Figure 184 The Edit Encryption Service dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 288 -...

  • Page 289: Change The Encryption Password

    1. From the menu bar, select Configuration > Services to display the Services screen (see Figure 171 on page 274). 2. Double-click the Encryption service, or select the service, and then select Action > Show Details. The details screen for the Encryption service displays. January 2022 User Guide-BlackPearl Nearline Gateway - 289 -...

  • Page 290: Unlock The Self-Encrypting Drives

    1. From the menu bar, select Configuration > Services to display the Services screen (see Figure 171 on page 274). 2. Double-click the Encryption service, or select the service, and then select Action > Show Details. The details screen for the Encryption service displays. January 2022 User Guide-BlackPearl Nearline Gateway - 290 -...

  • Page 291: Create An Encryption Password Usb Key

    1. From the menu bar, select Configuration > Services to display the Services screen (see Figure 171 on page 274). 2. Double-click the Encryption service, or select the service, and then select Action > Show Details. The details screen for the Encryption service displays. January 2022 User Guide-BlackPearl Nearline Gateway - 291 -...

  • Page 292: Psid Erase An Encryption Drive

    2. Click Data Drives. The hardware screen refreshes and displays all disk drives present in the gateway. 3. Record the slot number and serial number for each drive you want to PSID erase. January 2022 User Guide-BlackPearl Nearline Gateway - 292 -...
  • Page 293 Performing a PSID Erase on a drive permanently erases all data on the drive. CAUTION 15. Click Erase. 16. Repeat Step 12 through Step 15 for any additional drives you want to erase. January 2022 User Guide-BlackPearl Nearline Gateway - 293 -...

  • Page 294: Configure Users

    Using the Users Screen 1. From the menu bar, select Configuration > Users. The Users screen displays a list of all configured users (see Figure 42 on page 87). January 2022 User Guide-BlackPearl Nearline Gateway - 294 -...
  • Page 295 6. If desired, edit the value for the Session Timeout in minutes. This value cannot exceed 999 minutes. 7. Select or clear one or more User Access permissions. See Description of User Types on page 86 for information on each level of user access permission. January 2022 User Guide-BlackPearl Nearline Gateway - 295 -...
  • Page 296 13. Click Save. Using the User Profile Screen 1. From the right side of the menu bar, select Current User> User Profile. The User Profile screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 296 -...

  • Page 297: Change S3 Secret Key

    S3 credentials, through the User screen, or the User Profile screen. Using the Users Screen 1. From the menu bar, select Configuration > Users. The Users screen displays a list of all configured users (see Figure 42 on page 87). January 2022 User Guide-BlackPearl Nearline Gateway - 297 -...

  • Page 298: Delete A User

    5. Click Change to change the S3 secret key for the user. Delete a User 1. From the menu bar, select Configuration > Users. The Users screen displays a list of all configured users and S3 groups (see Figure 42 on page 87). January 2022 User Guide-BlackPearl Nearline Gateway - 298 -...

  • Page 299: Configure S3 Groups

    2. Select Action > New S3 Group from the menu bar. The New S3 Group dialog box displays. Figure 194 The New S3 Group dialog box. 3. Enter the desired Name for the group. January 2022 User Guide-BlackPearl Nearline Gateway - 299 -...
  • Page 300 2. Double-click the S3 group to which you want to add a different S3 group as a member, or select the group and from the menu bar select Action > Show Details. January 2022 User Guide-BlackPearl Nearline Gateway - 300 -...
  • Page 301 3. From the menu bar, select Action > Add User Member. The Add Group Member dialog box displays. Figure 196 The Add User Member dialog box. 4. Using the User drop-down menu, select the user to add as a member. 5. Click Add. January 2022 User Guide-BlackPearl Nearline Gateway - 301 -...

  • Page 302: Remove An S3 Group Member

    4. Under Global Data Policy Access Control List, select Enabled to allow the user access to any data policy created on the gateway. 5. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 302 -...

  • Page 303: Delete An S3 Group

    1. From the menu bar, select Configuration > Certificates. The Certificates screen displays. Figure 198 The Certificates screen. 2. Select either the Management or Data row, depending on for which port you want to install a new SSL certificate. January 2022 User Guide-BlackPearl Nearline Gateway - 303 -...

  • Page 304: Manually Enter Activation Keys

    7. Click Save. ANUALLY NTER CTIVATION If this is an initial installation and your BlackPearl documentation kit included a USB device, Automatically Import Activation Keys on page 73 for instructions for importing activation keys. January 2022 User Guide-BlackPearl Nearline Gateway - 304 -...
  • Page 305 Glacier SSD Count the system for cache, database, OSD. DS3 & on-premise Enables the specified number of tape slots Glacier Tape Count present in the attached Spectra Logic or supported tape library. b. Product key(s) January 2022 User Guide-BlackPearl Nearline Gateway...
  • Page 306 On-premise Glacier Enables tape for a BlackPearl S3. Third party tape library Enables object storage on a non-Spectra library. enabled c. All other keys - Any additional keys included on the Software Activation Key Certificate, such as the Product Key, Software Update key, or the NAS and Pools product key, can be entered in any order.

  • Page 307: Chapter 9 - Working With Tape Libraries And Media

    Chapter 9 - Working with Tape Libraries and Media This chapter describes using the BlackPearl user interface to perform tasks relating to tape libraries and tape media. Tape Library Barcode Reporting Format Tapes Cancel Tape Format Inspect Tapes Eject Tapes Edit Tape Eject Information Eject a Single Tape Cancel Tape Ejection Eject Tapes from a T50e or T120 Library with Multiple Partitions...

  • Page 308: Tape Library Barcode Reporting

    EPORTING Once a tape library and associated tape media are under the control of the BlackPearl gateway, it is important that you do not change the barcode reporting option on the Spectra Logic tape library. If you must change the barcode reporting on the tape library for any reason, IMPORTANT contact Spectra Logic Technical Support before proceeding.
  • Page 309 Unknown, select Action > Format All Unmanaged Tapes. A confirmation dialog box displays. Figure 203 The Format Tape confirmation Figure 204 The Format All Unmanaged dialog box. Tapes confirmation dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 309 -...

  • Page 310: Cancel Tape Format

    Pending Inspection state (see State on page 351) and become unusable by the gateway. To return the cartridge to a usable state, manually request an inspection of the cartridge. January 2022 User Guide-BlackPearl Nearline Gateway - 310 -...

  • Page 311: Eject Tapes

    Once tapes are ejected from the gateway, they can be imported into another BlackPearl gateway, or stored off site. Do not use the Spectra Logic or supported tape library front panel or RLC connection to move tape cartridges while the tape library is under the control of the BlackPearl gateway.
  • Page 312 TS4500 User Guide. • Spectra T50e and T120 libraries must be configured in Standard eject mode in order for the BlackPearl gateway to automatically eject tapes. If your library has only one partition, it is already in Standard eject mode. If there is more than one...

  • Page 313: Edit Tape Eject Information

    3. Enter information in the Eject Label and Eject Location fields. This information is stored on the BlackPearl database and is visible when re-importing the tape into a BlackPearl gateway. 4. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 313 -...

  • Page 314: Eject A Single Tape

    Eject Tapes Eject a Single Tape Ejecting a tape moves that tape to the Entry/Exit pool of a Spectra Logic tape library, or the I/O slots of an IBM tape library. Any objects on the exported tape are inaccessible until the tape is re-imported into a storage pool.

  • Page 315: Cancel Tape Ejection

    If you requested a tape eject but it has not yet started, you can cancel the ejects in progress. Any tapes not already moved to the Entry/Exit pool of a Spectra Logic tape library, or the I/O slots of an IBM tape library are left in the storage partition and are usable by the BlackPearl gateway.

  • Page 316: Import Tapes

    Note: The BlackPearl gateway and Spectra Logic make a best effort to import foreign LTFS tapes. The BlackPearl support contract does not guarantee import of, nor cover any issues while importing foreign LTFS tapes. For the subset of LTFS tapes that cannot be imported, the Spectra Logic Professional Services team can help with the migration process.

  • Page 317: Import Tape Media

    Use the instructions in this section to import tape media into the BlackPearl gateway database. 1. If necessary, import the tape media into the Entry/Exit pool of a Spectra Logic tape library, or the I/O slots of an IBM tape library associated with the BlackPearl gateway as...

  • Page 318: Import Blackpearl Foreign Tape(S)

    1. Select Status > Tape Management from the menu bar. The Tape Management screen displays. Figure 209 The Tape Management screen with BlackPearl foreign tapes listed. January 2022 User Guide-BlackPearl Nearline Gateway - 318 -...
  • Page 319 Note: This option is unavailable if you selected Verify Data Prior to Import in Step 6. 8. Click Import. The foreign tape(s) are imported into the BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 319 -...

  • Page 320: Import Ltfs Foreign Tape(S)

    Figure 211 The Edit S3 Service dialog box. d. Use the IOM Mode drop-down menu to select the behavior for Intelligent Object Management to Disabled. e. Leave all other settings unchanged, and click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 320 -...
  • Page 321 5. If the bucket’s data policy includes dual copy on tape, use the Storage Domain drop- down list to specify into which storage domain to import the foreign LTFS tape. Otherwise, continue with Step 6. January 2022 User Guide-BlackPearl Nearline Gateway - 321 -...

  • Page 322: Compact A Tape Cartridge

    Use the instructions in this section to add a tape cartridge to the next auto compaction cycle. 1. Select Status > Tape Management from the menu bar. The Tape Management screen displays (see Figure 202 on page 309). January 2022 User Guide-BlackPearl Nearline Gateway - 322 -...

  • Page 323: Manage Tapes Not In Inventory

    3. Select the tape with a status of “Not in Inventory” and select Action > Mark Tape Not In Inventory As Ejected. A confirmation window displays. 4. In the confirmation window, click Confirm. The Tape Management screen updates the tape status to “Ejected”. January 2022 User Guide-BlackPearl Nearline Gateway - 323 -...

  • Page 324: Delete Lost Or Ejected Tape

    BlackPearl gateway can automatically detect the new tape library. 1. From the menu bar, select Configuration > Advanced Bucket Management > Storage & Policy Management to display the Advanced Bucket Management screen (see Figure 51 page 128). January 2022 User Guide-BlackPearl Nearline Gateway - 324 -...

  • Page 325: Put A Tape Library Partition Into Standby

    2. Select the tape partition in the Tape Partitions pane, and select Action > Put Tape Partition in Standby. The Put Tape Partition in Standby confirmation window displays. Figure 215 The Put Tape Partition in Standby confirmation window. January 2022 User Guide-BlackPearl Nearline Gateway - 325 -...

  • Page 326: Delete A Tape Partition

    3. Enter DELETE in the entry box. 4. Click Delete. RIVE PTIONS The following sections describe reserving tape drives, setting a drive to an online or offline state, and removing a tape drive from a partition. January 2022 User Guide-BlackPearl Nearline Gateway - 326 -...

  • Page 327: Tape Drive Reservation

    BlackPearl gateway with a 20 (or more) disk drive cache pool, reserving four of the tape drives for writes provides maximum throughput for writes. Those four tape drives cannot be used for GET or restore jobs that need to read data from tape. January 2022 User Guide-BlackPearl Nearline Gateway - 327 -...
  • Page 328 Tape Partitions pane, and select Action > Show Details. The Tape Partition details screen displays. 3. Select Action > Edit. The Edit dialog box displays. Figure 216 The Edit dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 328 -...
  • Page 329 2. Select the tape partition that contains the drive(s) you want to reserve in the Tape Partitions pane, and select Action > Show Details. The Tape Partition details screen displays. January 2022 User Guide-BlackPearl Nearline Gateway - 329 -...
  • Page 330 • At least one drive in the tape partition must be configured with a Minimum Task Priority of Any or Low. If only one drive is configured for Any or Low, you cannot change the tape drive reservation. 6. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 330 -...

  • Page 331: Offline A Tape Drive

    4. Click Deactivate. The tape drive is now offline. Once you complete service on the tape drive, make the tape drive available to the BlackPearl gateway using the steps in Online a Tape Drive on page 332. January 2022 User Guide-BlackPearl Nearline Gateway - 331 -...

  • Page 332: Online A Tape Drive

    • Offline drives with a Quiesced value of "No" indicate that the BlackPearl gateway cannot communicate with the drive. Examine your tape library to determine the cause of the problem, or contact Spectra Logic Technical Support (see "Contacting Spectra Logic" on page 8).

  • Page 333: Remove A Tape Drive From A Tape Partition

    Figure 222 The Tape Partition details screen. 3. Click Remove on the row of the tape drive you want to remove from the tape partition. A confirmation window displays. 4. Click Delete. January 2022 User Guide-BlackPearl Nearline Gateway - 333 -...

  • Page 334: Data Migration

    The data migration is now complete. 7. If desired, using the list of tapes you recorded in Step 2, eject tapes from the source tape partition (see Eject Tapes on page 311). January 2022 User Guide-BlackPearl Nearline Gateway - 334 -...

  • Page 335: Chapter 10 - Operating The Blackpearl Nearline Gateway

    Chapter 10 - Operating the BlackPearl Nearline Gateway This chapter describes procedures for day-to-day monitoring and operation of the Spectra BlackPearl Nearline Gateway. S3 Operations Download an Object Cancel DS3 Jobs Edit an S3 Job Clear All Canceled or Completed Jobs...

  • Page 336: S3 Operations

    Download an Object Objects present on the BlackPearl gateway can be downloaded using the BlackPearl user interface, a DS3 client, or the Spectra Eon Browser. For information on using the Spectra Eon Browser, see the BlackPearl Eon Browser User Guide.

  • Page 337: Cancel Ds3 Jobs

    Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations 2. Double-click the bucket that contains the object you want to download. The Bucket Details screen displays a list of all objects in the bucket. Figure 223 The Bucket details screen.

  • Page 338: Edit An S3 Job

    Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations 2. Cancel one or more in-progress jobs. a. Select the job to cancel and then select Action > Cancel or select Action > Cancel All Jobs. The Cancel Job or Cancel All Jobs screen displays.

  • Page 339: Clear All Canceled Or Completed Jobs

    Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations 2. Select the row of the S3 job for which you want to change the name, and select Action > Edit Job. The Edit Job dialog box displays. Figure 227 The Edit Job dialog box.

  • Page 340: Manually Starting The S3 Data Path Backend

    Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations Manually Starting the S3 Data Path Backend If the BlackPearl gateway is powered off for longer than the timeout value specified in the S3 service options, the data path backend must be manually started. Use the instructions in this section to manually start the data path backend.

  • Page 341: Allow New Jobs

    Chapter 10 - Operating the BlackPearl Nearline Gateway S3 Operations 3. On the S3 service details screen, select Action > Disallow New Jobs. The Disallow New Jobs confirmation window displays. Figure 230 The Disallow New Jobs confirmation window. 4. Click Submit.

  • Page 342: Monitor The Blackpearl Gateway

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway ONITOR THE LACK EARL ATEWAY The Visual Status Beacon on the front bezel, and the BlackPearl user interface, combine to provide a number of tools for monitoring the health and performance of the BlackPearl gateway and its components.

  • Page 343: Front Bezel Visual Status Beacon

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Front Bezel Visual Status Beacon The Visual Status Beacon light bar in the front bezel provides an at-a-glance status of the gateway to which it is mounted. The light bar changes color to indicate the status of the gateway.

  • Page 344: Configuring The Visual Status Beacon Color

    Optionally, you can enter an HTML color code in the entry field. Note: Spectra Logic recommends against using yellow or red, so that you can more easily determine if the gateway is in a warning or error state. 5. Click Choose to set the color of the Visual Status Beacon.
  • Page 345 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Gen2 X Series Chassis The table below lists each system status LED, in order from left to right, and its function. Figure 233 The top left section of the front of the Gen2 X chassis (front bezel removed) showing system status LEDs.
  • Page 346 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Gen2 S Series and Gen2 V Series Chassis The table below lists each system status LED, in order from left to right, and its function. Figure 234 The top right section of the front Figure 235 The top left section of the front of the...
  • Page 347 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Gen1 S Series and Gen1 V Series Chassis The table below lists each system status LED and its function. Figure 236 The left side of the front of the Gen1 S Series chassis showing system status LEDs.

  • Page 348: Check System Messages

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Check System Messages Check the system messages regularly. These messages provide important information about the BlackPearl gateway and its operation. Reviewing the messages is the first step in troubleshooting.

  • Page 349: View The Status Of Hardware Components

    Figure 238 The Messages screen. Pay extra attention to any messages flagged with the Warning or Error icon (see Status Icons on page 63), and follow any recommended steps. Contact Spectra Logic Technical Support if you need assistance (see Contacting Spectra Logic on page 8).
  • Page 350 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Use the following instructions to check the status of hardware components. 1. From the menu bar, select Status > Hardware or click the Hardware pane on the Dashboard, or click the Hardware link on the status bar. The Hardware screen displays.

  • Page 351: View The Status Of Services

    Shows... Name The name of the service running on the gateway. State The status of the service on the BlackPearl Nearline gateway. • Starting—The service is starting up. • Operational—The service is running. • Stopped—The service is not running. Enabled Whether or not the service is enabled at system startup.
  • Page 352 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway 2. The status of each storage pool is indicated by the status icons on the left side of the screen. Figure 241 The Pools screen. The Pools screen displays the following information.
  • Page 353 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway 3. To view additional information about a NAS pool, select the pool and then select Action > Show Details. The pool name details screen displays. Figure 242 A NAS Pool details screen.

  • Page 354: View The Status Of Nas Volumes

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway This row... Shows... Used The amount of used storage space in the pool. Overhead The amount of disk space used for overhead, such as parity data. Drives The size, RPM, type, and number of drives assigned to the pool.
  • Page 355 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway 2. The status of each share is indicated by the status icons on the left side of the screen. Figure 244 The CIFS Shares screen. January 2022 User Guide-BlackPearl Nearline Gateway...

  • Page 356: View The Status Of The System Pools

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway View the Status of the System Pools The System Pools pane of the Advanced Bucket Management screen provides status information about the database and cache pools configured on the BlackPearl gateway, as well as status information for each system pool.
  • Page 357 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway The System Pools pane displays the following information. This column... Shows... Name The name of each system pool. This name cannot be edited. Health The current health of each system pool.

  • Page 358: View Bucket Contents

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway This row... Shows... Power Saving Indicates if power saving mode is enabled or disabled. Mode Data The protection level for the pool. Configuration Fault Tolerance The number of drives that can fail before data is lost.

  • Page 359: View Ds3 Jobs Information

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway 2. Double-click the name of the bucket for which you want to view the contents. The details screen for the bucket displays. Figure 247 The details screen for a selected bucket.
  • Page 360 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway Use the job status drop-down menu to select Active Jobs, Canceled Jobs, or Completed Jobs as desired. The S3 Jobs screen displays the following information: This column... Shows...

  • Page 361: View Tape Media Information

    View Tape Media Information The Tape Management screen allows you to view the status of all tapes in the associated Spectra Logic or supported tape library, or in a specified bucket. 1. Display the Tape Management Screen: • To view the status of all tapes in the associated tape library, from the menu bar, select Status >...
  • Page 362 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway This Shows... column... Type The media type. Values: LTO-5, LTO-6, LTO-7, LTO-7 Type M, LTO-8, LTO-9, TS1140, TS1150, TS1155, TS1160 State The status of the tape: During normal operation, the tape state is MANAGED. Other possible states are: •...
  • Page 363 The amount of unused space that is available for data on the tape cartridge. Used The amount of space on the tape cartridge containing data. Tape The serial number of the partition on the Spectra Logic or supported tape library Library containing the tape cartridge. Partition Storage The storage domain to which the tape is assigned.
  • Page 364 The amount of unused space that is available on the tape cartridge. Used The amount of space on the tape containing data. Tape The serial number of the partition on the Spectra Logic or other supported tape Library library containing the tape cartridge. Partition...
  • Page 365 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway This row... Shows... Assigned to Whether the tape is allocated to a storage domain. Values: Yes, No Storage Domain Storage The storage domain to which the tape is assigned.

  • Page 366: View Performance Metrics

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway View Performance Metrics The Performance screen displays performance metrics for the BlackPearl cache, individual data drives, network traffic, and CPUs. Performance graphs can be configured to display either the last 5 minutes of activity, or the last 25 hours.
  • Page 367 Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway 7. To see the performance data in greater detail, select the desired section you want to magnify in either the main or range indicator graph. Using the mouse, click and drag the cursor horizontally over the section of the detail graph that you want to magnify.

  • Page 368: View Reports

    Chapter 10 - Operating the BlackPearl Nearline Gateway Monitor the BlackPearl Gateway View Reports The Reports screen allows you to generate reports on all aspects of the BlackPearl gateway, including component status, and configuration. Reports can be saved in either JSON or XML format.

  • Page 369: Database Backup & Restore

    The bucket used for database backups is automatically created when the first backup is generated, either manually, or on a schedule. The database backup bucket is listed on the Buckets screen of the BlackPearl user interface with the name “Spectra-BlackPearl-Backup- system name-product serial number“. This bucket cannot be used for data storage.

  • Page 370: Create A Database Backup Schedule

    The default schedule on the BlackPearl gateway generates a backup once per day, and retains a maximum of two backups. Creating a backup of the database is a process intensive procedure. Spectra Logic recommends configuring a backup schedule to run during periods of IMPORTANT low gateway activity.
  • Page 371 The maximum setting for the minute field is 59. Note: Spectra Logic recommends offsetting the minutes after the hour for starting database backups so that there are not a large number of jobs starting at exactly the same time.
  • Page 372 Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore 3. Select Daily. The Modify Database Backup Schedule screen changes to display the options for a daily backup schedule. Figure 256 The Modify Database Backup Schedule screen. 4. Enter a number for the Minimum backups to keep on tape. When the gateway generates a backup, it determines the number of fully persisted backups and automatically deletes the oldest backups exceeding this number.
  • Page 373 Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore 3. Select Weekly. The Modify Database Backup Schedule screen changes to display the options for a daily backup schedule. Figure 257 The Modify Database Backup Schedule screen. 4. Enter a number for the Minimum backups to keep on tape. When the gateway generates a backup, it determines the number of fully persisted backups and automatically deletes the oldest backups exceeding this number.

  • Page 374: Manually Generate A Database Backup

    Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore Manually Generate a Database Backup Use the instructions in this section to create a database backup manually. 1. From the menu bar, select Configuration > Database Backup. The Database Backup screen displays.
  • Page 375 Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore There are two ways to restore from a database backup; restoring from a manual or automatic database backup, or restoring from an arbitrary file. Restoring from an arbitrary file is useful if you have copied your database backup files to another bucket.

  • Page 376: Delete Backup

    Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore 3. Enter RESTORE in the entry field, and then click Restore. The database is restored to the state it was in when the backup was generated. Restore Using an Arbitrary File...

  • Page 377: Edit Backup Data Policy

    Chapter 10 - Operating the BlackPearl Nearline Gateway Database Backup & Restore 2. Select the backup you want to delete in the Backups pane, and then select Action > Delete. A confirmation dialog box displays. 3. Enter DELETE BACKUP in the entry field and click Delete. The backup is deleted.

  • Page 378: Reboot Or Shut Down A Blackpearl Gateway

    Chapter 10 - Operating the BlackPearl Nearline Gateway Reboot or Shut Down a BlackPearl Gateway 2. From the list of existing backups, select the backup for which you want to view physical placement and select Action > Show Backup Physical Placement. The screen refreshes to show you the storage pool or tape media the backup currently occupies.

  • Page 379: Using The Blackpearl User Interface

    Chapter 10 - Operating the BlackPearl Nearline Gateway Reboot or Shut Down a BlackPearl Gateway Using the BlackPearl User Interface Use the following instructions to reboot or shutdown a gateway using the BlackPearl user interface. 1. Click the power icon in the lower right-hand corner of any screen in the BlackPearl user interface.

  • Page 380: Power-Cycle Reset

    Exit the BlackPearl User Interface Power-Cycle Reset Under some circumstances, Spectra Logic Technical Support may direct you to perform a power-cycle reset of a BlackPearl gateway to recover from an error. To power-cycle reset a BlackPearl gateway, remove the front bezel, and then press and hold the front panel power button (Figure 32 on...

  • Page 381: Chapter 11 - Using Autosupport

    It is also used to generate AutoSupport Log (ASL) sets for use by Spectra Logic Technical Support. You can configure the gateway to email ASL sets when critical events occur, or on a monthly basis. You can also choose to have mail recipients receive ASL sets.

  • Page 382: Enter Contact Information

    NTER ONTACT NFORMATION Contact information helps Spectra Logic in contacting the administrator of the BlackPearl gateway during troubleshooting. Entering the contact information is typically a one-time-only process. 1. From the menu bar, select Support > Contact Information to display the Contact Information screen.

  • Page 383: Configure Mail Recipients

    1. From the menu bar, select Configuration > Mail Recipients. The Mail Recipients screen displays. 2. Select Action > New. The New Mail Recipient dialog box displays. Figure 268 The New Mail Recipient dialog box. January 2022 User Guide-BlackPearl Nearline Gateway - 383 -...

  • Page 384: Edit A Mail Recipient

    Choose the Select from the listed message types which severities of message this mail message severities recipient should receive. The BlackPearl Nearline gateway automatically you want to sends email messages of the selected severity to the recipient when they are receive generated.

  • Page 385: Send A Test Email

    2. From the list of mail recipients, select the name of the recipient you want to receive a test email, and then select Action > Send test email. Figure 270 The Mail Recipients screen. The BlackPearl gateway immediately sends a test email to the selected account. January 2022 User Guide-BlackPearl Nearline Gateway - 385 -...

  • Page 386: Delete A Mail Recipient

    Spectra Logic Technical Support. • Statistic Log Sets contain performance data about the gateway and are used by Spectra Logic Technical Support for in-depth troubleshooting. Statistic log sets are too large to be mailed directly from the gateway and must be downloaded.

  • Page 387: Configure A Log Set Schedule

    Log Sets • Data Path Log Sets are used to determine if there is a problem in the data planner code. This logset contains no customer data and is used by Spectra Logic Technical Support. Use the Logs screen to generate, email, or download log sets, as well as to configure a log set schedule.

  • Page 388: Manually Generate Log Sets

    Although the BlackPearl gateway auto generates log sets whenever errors occur, you may want to create log sets manually for troubleshooting purposes, or at the request of Spectra Logic Technical Support. Use the following instructions to manually generate a log set.

  • Page 389: Email A Log Set

    Statistic Log Sets are too large to be emailed from the gateway, and must be downloaded. See Download a Log Set, below. Figure 275 The Email Log Set dialog box. 3. Select the mail recipients you want to receive the log set, and click Email. January 2022 User Guide-BlackPearl Nearline Gateway - 389 -...

  • Page 390: Download A Log Set

    Sets Action > Delete All Kernel Logs Deletes all kernel log sets on the gateway. Action > Delete All Data Path Logs Deletes all data path log sets on the gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 390 -...

  • Page 391: Chapter 12 - Maintaining The Blackpearl Nearline Gateway

    Chapter 12 - Maintaining the BlackPearl Nearline Gateway This chapter describes the maintenance procedures for the Spectra BlackPearl Nearline Gateway. Data Integrity Verification - Disk Media Cancel Data Integrity Verification Data Integrity Verification - Tape Media Cancel Tape Media Verification...
  • Page 392 Chapter 12 - Maintaining the BlackPearl Nearline Gateway Data Integrity Verification - Disk Media Data integrity verification is a sector by sector check of the entire storage pool, not just the data contained on the pool. The duration of a data integrity verification varies based on the size of the disk pool, and in some cases can take a very long time to complete.

  • Page 393: Cancel Data Integrity Verification

    Performing a data integrity verification on a tape cartridge is useful when you want to ensure the data on the tape is stored correctly. Spectra Logic recommends verifying any tape you plan to export from your BlackPearl gateway and store off-site.

  • Page 394: Cancel Tape Media Verification

    Large libraries can take a very long time to complete the verification. A confirmation window displays. Click Verify to begin the data integrity verification. In the event that the data integrity verification fails, contact Spectra Logic Technical Support (see Contacting Spectra Logic on page 8) for assistance in...

  • Page 395: Initiate Rsc Backup

    BlackPearl software, or to open a support ticket. Note: If you own multiple Spectra Logic products, the serial numbers for all products are associated with your account. If you do not see the serial numbers for all of your...
  • Page 396 Chapter 12 - Maintaining the BlackPearl Nearline Gateway Access the Technical Support Portal 2. On the home page, click create an account. Figure 278 The Spectra Logic Technical Support portal home page. January 2022 User Guide-BlackPearl Nearline Gateway - 396 -...

  • Page 397: Log Into The Portal

    Access the Technical Support Portal 3. Enter your registration information. Your account is automatically associated with the serial numbers of all Spectra Logic products owned by your site. • If you have an invitation, follow the link and enter the invitation code.

  • Page 398: Configure Automated Software Upload

    5. Optionally, select the Email Notifications Only check box to only receive an email when an updated software package is available instead of automatically download the file. 6. Select either Spectra Logic or Use Proxy as the Upload From location. Spectra Logic recommends using the Spectra Logic package server.

  • Page 399: Update The Software

    OFTWARE Some problems with the BlackPearl gateway may be fixed by updating the gateway’s software. Spectra Logic provides complete support for the most current release of software and one revision back. Customers using previously released software packages are asked to update to the current release as soon as possible.

  • Page 400: Check The Currently Released Software Version

    Technical Support portal. 2. Select Downloads > Product Software. 3. On the Product Software page, locate the the BlackPearl gateway in the Spectra Product column. The currently released BlackPearl software version is listed in the Current Version column.

  • Page 401: Download And Stage The Updated Software

    Chapter 12 - Maintaining the BlackPearl Nearline Gateway Update the Software Download and Stage the Updated Software Use the instructions in this section to download and stage the updated software for the the BlackPearl gateway. 1. Log into your account on the Technical Support portal at support.spectralogic.com.

  • Page 402: Install The Update

    Chapter 12 - Maintaining the BlackPearl Nearline Gateway Update the Software 5. From the BlackPearl menu bar, select Support > Software to display the Software screen. Click Choose File. Using your web browser, browse to the location of the update file and select the file to upload.

  • Page 403: Replace A Failed Component

    Chapter 12 - Maintaining the BlackPearl Nearline Gateway Replace a Failed Component 3. Click Update. A progress bar shows the progress of the update. Figure 286 The Software Update screen showing the progress of an update. 4. When the update is complete, the BlackPearl gateway automatically reboots to begin using the latest software.
  • Page 404 4. After you locate the unit in your data center, click Turn Beacon Off to stop the lights from flashing. 5. For specific part replacement procedures, refer to one of the following guides, which can be found after logging into the Spectra Logic support portal at support.spectralogic.com. • The Spectra 12- & 36-Drive Chassis HBA Installation Guide provides instructions for installing an HBA in a Gen1 master node.
  • Page 405 Chapter 12 - Maintaining the BlackPearl Nearline Gateway Replace a Failed Component • The Spectra 96-Bay Chassis Drive Replacement Guide provides instructions for replacing a failed data drive in the 96-bay expansion node. • The Spectra 96-Bay Chassis Fan Replacement Guide provides instructions for replacing a failed fan in the 96-bay expansion node.

  • Page 406: Chapter 13 - Faq, Troubleshooting, And Support

    Chapter 13 - FAQ, Troubleshooting, and Support Use the information in this appendix to troubleshoot problems on the Spectra BlackPearl Nearline Gateway as they arise, before contacting Spectra Logic Technical Support. BlackPearl Cache How is Cache Used and Allocated? Why Does the BlackPearl User Interface Display 80% Cache Usage?
  • Page 407 General BlackPearl Notes Tape Drive Failure Modes Move Failures/Tape Stuck in Drive Library, Drive, and Tape Failure Behavior in BlackPearl version 5.3 Enabling iSCSI For Use With the Spectra Swarm Troubleshooting Resolve a BlackPearl Management Port IP Address Conflict Using the Console...

  • Page 408: Blackpearl Cache

    If IOM is impacting normal production use, the Schedule IOM feature in the S3 service allows you to set a schedule to minimize downtime. January 2022 User Guide-BlackPearl Nearline Gateway - 408 -...

  • Page 409: Why Does The Blackpearl User Interface Display 80% Cache Usage

    LTO-6 drives and media. If the existing media is compatible with the new drives, the tape partition is upgraded to the new drive generation, and the old drives are removed. January 2022 User Guide-BlackPearl Nearline Gateway - 409 -...

  • Page 410: What Happens When A Tape Partition Is Placed In Standby/Quiesced

    BlackPearl S3 service stays enabled and active while the tape partition is in standby, which allows any DS3 applications, such as the Eon Browser or Spectra StorCycle application, to write data into, or to request data from the BlackPearl gateway. The write jobs go into the BlackPearl cache and wait until the tape partition is ready.

  • Page 411: How Do I Change The Tape Library Used By The Blackpearl Gateway While Minimizing The Impact, Management Time, And System Downtime

    If you plan to upgrade the library used by the BlackPearl gateway, for example change from a Spectra T120 to a Spectra Stack, it is advised to work with Spectra Logic Technical Support before changing the tape partition used by the BlackPearl gateway, and before moving any tapes to the new tape library or partition.

  • Page 412: Can Worm Media Be Used With The Blackpearl Gateway

    Users with adequate permissions for a bucket could also use the BlackPearl user interface, a BlackPearl client, or an S3 browser tool like the Spectra Eon Browser to delete objects from a bucket. When all objects on a tape have been deleted, the tape is automatically reformatted and put back into the blank media pool.

  • Page 413: What Happens If A User Ejects A Tape From The Library Before Ejecting The Tape In The Blackpearl User Interface

    Messages screen. Inspect the messages to determine the barcode of the missing tape. See the Tape Library User Guide for instructions for importing the tape into a Spectra Logic tape library. For instructions on importing a tape into an IBM TS4500 tape library, see the see the TS4500 User Guide.

  • Page 414: How Does A User Configure Their T50E Or T120 Library To Support Ejecting Tapes From The Blackpearl Gateway

    Standard mode for the Entry/Exit port. Note: The Spectra Stack, T200, T380, T680, T950 and TFinity libraries do not have limitations on the partition count or Entry/Exit mode for BlackPearl tape ejection. RIVE...

  • Page 415: Have A Cleaning Partition

    The default database backup schedule generates a backup once per day, and retains a maximum of two backups. January 2022 User Guide-BlackPearl Nearline Gateway - 415 -...

  • Page 416: How Does A User Verify The Database Backup Schedule

    3. Select Configuration > Database Backup. The Database Backup screen displays. 4. Select Action > Edit Data Policy. The Modify Data Policy window displays. 5. Using the Data Policy to Use drop-down menu, select the data policy you created in Step 2. January 2022 User Guide-BlackPearl Nearline Gateway - 416 -...

  • Page 417: Blackpearl Disk Storage Data Retention

    BlackPearl gateway still writes to all 10 pools in parallel when there are lots of chunks flowing through the cache. Capacity mode just prevents BlackPearl from adding additional disk pools to the storage domain (until all 10 disk pools are full). January 2022 User Guide-BlackPearl Nearline Gateway - 417 -...

  • Page 418: Blackpearl Component Hardware

    Use the information in the message emails, and the Messages screen in the BlackPearl user interface, and the Spectra Logic tape library’s BlueScale user interface, along with the Troubleshooting on page 429 section to correct any issues.

  • Page 419: Best Practices

    Intelligent Object Management (IOM) Best Practices Spectra Logic recommends running IOM on a subset of data when possible. • Migration Example - If there are five storage domains where each domain is isolated from the other storage domains, use IOM to migrate one storage domain at a time.

  • Page 420: Using A Blackpearl Gateway With The Vail Application

    (80) or secure port (443) Outbound 443 Outbound access is needed for port 443 to allow data transfer to the Vail sphere, or other S3 endpoint nodes. January 2022 User Guide-BlackPearl Nearline Gateway - 420 -...

  • Page 421: Special Firewall Feature For Connecting To The Bluescale User Interface

    NTERFACE Introduction The BlackPearl gateway can act as a gateway for a Spectra Logic tape library network management interface. This feature enables a private network behind the BlackPearl gateway, where Proxy/NAT information is entered into the BlackPearl gateway to allow a connection to either a BlueScale library or BlueVision library with the BlackPearl gateway.

  • Page 422: Performance Mode

    It is recommended to use performance mode only at the direction of Spectra Logic. There may be other methods to increase performance while using capacity mode based on workloads and use cases.

  • Page 423: Tape Drive Failure Modes

    BlackPearl gateway detects these events through the tape library management subsystem. Currently, the BlackPearl gateway responds to sense codes from the media changer device as recommended in the Spectra TSeries Developer Guide. When a move failure occurs, the BlackPearl gateway is limited to just retrying the move.

  • Page 424: Library, Drive, And Tape Failure Behavior In Blackpearl Version

    IOCTLs, or via SCSI pass-through. LTFS specifies whether or not it retries SCSI pass-through commands. For read/write, the sa(4) driver does not retry. January 2022 User Guide-BlackPearl Nearline Gateway - 424 -...
  • Page 425 (using strikes from failures with tapes B, C, D), and the BlackPearl gateway quiesces the tape drive. d. The default number of strikes (three) can be changed by Spectra Logic Technical Support. If set to zero, the BlackPearl gateway will not automatically quiesce the tape drive.

  • Page 426: Enabling Iscsi For Use With The Spectra Swarm

    The instructions below assume an understanding of creating and editing files in the FreeBSD environment. You must also have the BlackPearl gateway and Spectra Swarm installed and configured. This procedure is to be used only at the direction of Spectra Logic Technical Support (see Contacting Spectra Logic on page 8).
  • Page 427 In the Enter a CLI Commmand dialog box, enter iscsitargetnamedisplay and click Submit. The list of iSCSI targets displays. The name of each target is based on the WWN of each partition connected to the Spectra Swarm bridge. See Spectra Swarm Install and Configuration Guide the if you need to determine which WWN is associated with each partition.
  • Page 428 Chapter 13 - FAQ, Troubleshooting, and Support Enabling iSCSI For Use With the Spectra Swarm b. Select the desired data port to display the IP Address for the port. 4. Access the BlackPearl gateway FreeBSD command line interface. 5. Create the file /etc/iscsi.conf.

  • Page 429: Troubleshooting

    Troubleshooting steps below that describe actions that involve a tape library apply only to Spectra Logic tape libraries. If your problem is not addressed by any of the below entries, contact Spectra Logic Technical Support for assistance (see Contacting Spectra Logic on page 8).
  • Page 430 Troubleshooting Issue Resolution An email is sent If the BlackPearl gateway is connected to a Spectra T200, T380, T680, T950, from the tape or TFinity library, the library should be configured with a cleaning partition, library indicating which automatically cleans drives when cleaning is requested by the drive.
  • Page 431 3. Once the tape drives are returned to good status, retry the job. Note: If you cannot return your tape drives to good status, contact Spectra Logic Technical Support (see Contacting Spectra Logic on page 8).
  • Page 432 4. See “Use DLM to Test an LTO Drive” in your Tape Library User Guide test the drive. If the drive test fails, contact Spectra Logic Technical Support for assistance (see Contacting Spectra Logic on page 8).
  • Page 433 If you continue to experience problems with the tape library, gather an AutoSupport log as described in your Tape Library User Guide, and contact Spectra Logic Technical Support (see Contacting Spectra Logic on page 8). January 2022 User Guide-BlackPearl Nearline Gateway...
  • Page 434 2. Examine the Hardware screen for any failed components, which are designated by a red X in a circle. 3. Contact Spectra Logic Technical Support to request a part replacement (see Contacting Spectra Logic on page 8). Spectra Logic provides you with the replacement part.
  • Page 435 If the database reaches full capacity, the BlackPearl gateway is no longer from the usable. Additional drives must be installed to accommodate the database BlackPearl size. Contact Spectra Logic Technical Support for assistance (see Contacting gateway Spectra Logic on page 8).
  • Page 436 See Database Backup & Restore on page 369 for more information. The BlackPearl Although a Spectra tape library allows duplicate barcodes within the same gateway does not partition, the BlackPearl gateway does not allow duplicate barcodes. Any display tapes with...
  • Page 437 Network Setup Tips on page 440 troubleshooting information. If you cannot resolve the network issue, use the steps below to collect logs and open a ticket with Spectra Logic Technical Support. 1. In the client software, collect a set of logs, if available.

  • Page 438: Resolve A Blackpearl Management Port Ip Address Conflict

    BlackPearl gateway to your network. Using the Console Using the BlackPearl Nearline console is the recommended way to change the BlackPearl management port IP address. For instructions on using the console to configure the management port IP address, see Configure the BlackPearl Management Port on page 76.
  • Page 439 • The absence of the certificate does not affect functionality. 6. Enter the login username and password. The default username is Administrator and password is spectra. 7. From the menu bar, select Configuration > Network, or click the Network pane from the Dashboard screen.

  • Page 440: Network Setup Tips

    The basic steps for configuring the management and data ports for access to the network are simple and straight-forward. However, each network environment is unique and may require some additional troubleshooting in order to properly connect to the BlackPearl gateway and utilize the Ethernet interfaces correctly. January 2022 User Guide-BlackPearl Nearline Gateway - 440 -...

  • Page 441: Configuration

    • For the 100 GigE optical card: (Gen2 only): • Single 100 GigE logical connection using one of the 100 GigE physical ports —OR— • Single 200 GigE logical connection using two 100 GigE physical ports (link aggregation) January 2022 User Guide-BlackPearl Nearline Gateway - 441 -...
  • Page 442 Switches must support link aggregation using LACP (Link Aggregation Control Protocol), and the switches must hash the destination IP addresses. Manually configure LACP on the switch ports. LACP does not get enabled automatically. January 2022 User Guide-BlackPearl Nearline Gateway - 442 -...
  • Page 443 IP address for the BlackPearl management port or data port. If this is not successful, use the following troubleshooting tips to ascertain if the problem is a network setup issue. January 2022 User Guide-BlackPearl Nearline Gateway - 443 -...

  • Page 444: Troubleshooting

    A response of 0 msec means that the time was less than 1 ms. If the request times out, then check the settings on the switch to which the BlackPearl gateway is connected. January 2022 User Guide-BlackPearl Nearline Gateway - 444 -...

  • Page 445: Spectra Logic Technical Support

    PECTRA OGIC ECHNICAL UPPORT Spectra Logic Technical Support provides a worldwide service and maintenance structure. Before Contacting Support If you have a problem with your BlackPearl gateway, use the information in this section to attempt to resolve the problem. System Messages...

  • Page 446: Determine The Gateway Serial Number

    2. The gateway serial number is listed in the Product Information pane. Figure 292 The gateway serial number. Opening a Support Ticket You can open a support ticket using the Spectra Logic Technical Support portal or telephone. 1. Make notes about the problem, including what happened just before the problem occurred.
  • Page 447 Select Incidents & Inventory > Open or View Incidents, or on the Home page, click Open a Support Incident. Figure 293 Select Incidents & Inventory > Open or View Incidents to open a support incident. January 2022 User Guide-BlackPearl Nearline Gateway - 447 -...
  • Page 448 Open a New Incident. Note: You must perform a search before you are able to open a new support incident. Figure 294 The Open or View Incidents page. January 2022 User Guide-BlackPearl Nearline Gateway - 448 -...

  • Page 449: Remote Support

    When you are finished, click Create Incident. Figure 295 The Create Incident page. • If it is within the hours of coverage provided by your support contract, contact Spectra Logic Technical Support by telephone. See Contacting Spectra Logic on page 8.

  • Page 450: Enabling Remote Support

    4. Select the Enable Remote Support check box. Note: The Enable Remote Support check box does not display until you enter a Remote Support activation key. See Configure Network Connections and Settings on page 263 for more information. January 2022 User Guide-BlackPearl Nearline Gateway - 450 -...

  • Page 451: Disabling Remote Support

    Chapter 13 - FAQ, Troubleshooting, and Support Remote Support 5. Click Save. After Spectra Logic Technical Support informs you that they no longer require root access to the gateway, you should disable Remote Support to prevent any potential unauthorized access. See...
  • Page 452 2. Double-click the Administrator account, or select the Administrator account, and then select Action > Edit. The Edit User dialog box displays. Figure 297 The Edit User dialog box. 3. Clear the Enable Remote Support check box. 4. Click Save. January 2022 User Guide-BlackPearl Nearline Gateway - 452 -...

  • Page 453: Appendix A - Ipmi Configuration

    DO NOT make any changes in the BIOS other than changing the IPMI settings CAUTION as described below. Changing any other setting is not supported by Spectra Logic and may cause adverse gateway performance. 1. If the BlackPearl gateway is currently powered on, shut down the gateway as described in Reboot or Shut Down a BlackPearl Gateway on page 378.
  • Page 454 Figure 299 The BMC Configuration screen. 7. Using the keyboard, select Update IPMI LAN Configuration. A confirmation window displays. Select YES to continue. The current IPMI settings display. Figure 300 Current IPMI settings. January 2022 User Guide-BlackPearl Nearline Gateway - 454 -...
  • Page 455 12. Configure the Station IP address, Subnet mask, and Router IP address with the desired address values. Note: Only IPv4 addresses are valid. 13. Press F4 to exit the BIOS and save the entered settings. The BlackPearl gateway reboots. January 2022 User Guide-BlackPearl Nearline Gateway - 455 -...

  • Page 456: Appendix B - Specifications

    Appendix B - Specifications This appendix provides detailed specifications for the BlackPearl gateway, the 44-bay expansion node, 96-bay expansion node, and the 107-bay expansion node. The specifications listed here pertain to the currently shipping BlackPearl chassis. Note: For specifications that differ for the BlackPearl 1.0 chassis, see BlackPearl 1.0 Chassis Overview &...

  • Page 457: Blackpearl

    • 12 TB Spinning-Disk Self-Encrypting Drives Storage Pools or NAS • 4, 8, or 12 TB Spinning-Disk SAS • 12 or 16 TB Spinning-Disk SATA • 12 TB Spinning-Disk Self-Encrypting Drives January 2022 User Guide-BlackPearl Nearline Gateway - 457 -...
  • Page 458 • 4, 8, 12, or 16 TB Spinning-Disk SAS • 12 or 16 TB Spinning-Disk SATA • 12 TB Spinning-Disk Self-Encrypting Drives 96-Bay Expansion Node Drive Purpose Specification Storage Pools or NAS 8, 12, or 16 TB Spinning-Disk SATA January 2022 User Guide-BlackPearl Nearline Gateway - 458 -...
  • Page 459 • 4, 8, 12, or 16 TB Spinning-Disk SAS • 12 or 16 TB Spinning-Disk SATA • 12 TB Spinning-Disk Self-Encrypting Drives ) 16 TB SAS drives only supported in a HotPair configuration. January 2022 User Guide-BlackPearl Nearline Gateway - 459 -...

  • Page 460: System Specification

    ) Each Fibre Channel card is used to connect the BlackPearl master node to Fibre Channel tape drives. ) One port is available for data transfers, one port is dedicated to the BlackPearl user interface for gateway management. January 2022 User Guide-BlackPearl Nearline Gateway - 460 -...
  • Page 461 ) Each SAS card is used to connect the BlackPearl master node to disk expansion nodes or SAS tape drives. ) Each Fibre Channel card is used to connect the BlackPearl master node to Fibre Channel tape drives. January 2022 User Guide-BlackPearl Nearline Gateway - 461 -...
  • Page 462 ) Each SAS card is used to connect the BlackPearl master node to disk expansion nodes or SAS tape drives. ) Each Fibre Channel card is used to connect the BlackPearl master node to Fibre Channel tape drives. January 2022 User Guide-BlackPearl Nearline Gateway - 462 -...

  • Page 463: Size And Weight

    • Additional for each disk drive 0.8 lb (0.4 kg) • Additional for each Solid- State drive ) Includes chassis, drives, box, and packaging. ) Includes the front bezel. ) Weights are approximate. January 2022 User Guide-BlackPearl Nearline Gateway - 463 -...
  • Page 464 • 4 HDDs & 2 SSDs 55.7 lb (25.3 kg) 76.7 lb (34.8 kg) • 9 HDDs & 2 SSDs ) Includes chassis, drives, box, and packaging. ) Includes the front bezel. ) Weights are approximate. January 2022 User Guide-BlackPearl Nearline Gateway - 464 -...
  • Page 465 270 lb (122.5 kg) 302 lb (137 kg) • Fully loaded chassis ) Includes chassis, drives, box, and packaging. ) Includes the front bezel. ) Weights are approximate. ) Includes chassis and packaging. January 2022 User Guide-BlackPearl Nearline Gateway - 465 -...
  • Page 466 21 lb (9.5 kg) mounting kit • Fully loaded chassis 270 lb (122.5 kg) 336 lb (152.4 kg) ) Includes the front bezel. ) Weights are approximate. ) Includes chassis and packaging. January 2022 User Guide-BlackPearl Nearline Gateway - 466 -...

  • Page 467: Environmental Specifications

    (27° F per hour or 15° C per hour, or more). ) Maximum operating temperature is specified at sea level and is 2 percent lower per 1,000 ft (305 m) of increased altitude. January 2022 User Guide-BlackPearl Nearline Gateway - 467 -...
  • Page 468 ) Specifications are for the BlackPearl gateway or expansion node in its original packaging. The packaging protects the BlackPearl gateway from condensation caused by extreme temperature variations (27° F per hour or 15° C per hour, or more). January 2022 User Guide-BlackPearl Nearline Gateway - 468 -...

  • Page 469: Heat Generation

    ) Specifications are for the expansion node is in its original packaging. The packaging is designed to protect the expansion node from condensation caused by extreme temperature variations (27° F per hour or 15° C per hour, or more). January 2022 User Guide-BlackPearl Nearline Gateway - 469 -...

  • Page 470: Power Requirements

    200–240 VAC, 20 A peak, 800 watts maximum Input Frequency 50–60 Hz Gen2 S Series BlackPearl Gateway Parameter Requirements Input Voltage 200–240 VAC, 40 A peak, 1600 watts maximum Input Frequency 50–60 Hz January 2022 User Guide-BlackPearl Nearline Gateway - 470 -...
  • Page 471 Parameter Requirements Input Voltage 90-264 VAC, 1100 watts maximum Input Frequency 47–63 Hz 107-Bay Expansion Node Parameter Requirements Input Voltage 200–240 VAC, 15 A, 2000 watts maximum Input Frequency 50–60 Hz January 2022 User Guide-BlackPearl Nearline Gateway - 471 -...

  • Page 472: Power Cord Specifications

    Cables provided by Spectra Logic are between 6 ft (1.8m) to 6.5 ft (2m) in length. If you need to use a longer cord, make sure it conforms to the specifications listed below.
  • Page 473 • Male: Connector must be of the proper type, rating, and safety approval. • Female: Right-angled notched IEC 60320 C14 107-Bay Chassis Expansion Node: • Male: Connector must be of the proper type, rating, and safety approval. • Female: IEC 60320 C19 January 2022 User Guide-BlackPearl Nearline Gateway - 473 -...

  • Page 474: Interface Specifications

    This section provides information about the interfaces used to connect a BlackPearl gateway to expansion nodes, tape drives, and host systems. Note: For “Interface Specifications” for the BlackPearl 1.0 chassis, see BlackPearl 1.0 Chassis Overview & Specifications on page 479. January 2022 User Guide-BlackPearl Nearline Gateway - 474 -...

  • Page 475: System Interface Connectors

    Four SFP+ optical modules with LC connectors per Fibre Channel card (8 Gb or 16 Gb) provide connections to four Fibre Channel tape drives in the tape library, using one port for each tape drive. (Optional) January 2022 User Guide-BlackPearl Nearline Gateway - 475 -...

  • Page 476: Expansion Node And Tape Drive Interface Connectors

    BlackPearl gateway. 96-Bay Expansion Two SFF-8644 ports per 96-bay expansion node. Only a single port is Node required to connect the expansion node to a BlackPearl gateway. January 2022 User Guide-BlackPearl Nearline Gateway - 476 -...

  • Page 477: Network Interface Cables

    Cables to be provided by the customer. Ethernet (40 GigE) QSFP+ transceiver MPT optical cables with duplex LC connectors, or copper cables with QSFP+ connector. Note: Cables to be provided by the customer. January 2022 User Guide-BlackPearl Nearline Gateway - 477 -...

  • Page 478: Universal Serial Bus (Usb) Support

    Cables to be provided by the customer. Universal Serial Bus (USB) Support Spectra Logic supports using the USB ports on the gateway for the following: • USB mass storage devices (for example, flash drives) • Keyboards & pointer devices (for example, a computer mouse) •...

  • Page 479: Appendix C - Blackpearl 1.0 Chassis Overview & Specifications

    Appendix C - BlackPearl 1.0 Chassis Overview & Specifications This chapter provides an overview and specifications for the Spectra Logic BlackPearl Nearline Gateway 1.0 chassis. Components Front View Rear View Rear Panel Specifications System Specification Interface Specifications OMPONENTS The following sections show the locations of and briefly describe the BlackPearl 1.0 chassis major front and rear panel components.
  • Page 480 System Status LEDs on page 344 for more information. The base BlackPearl Nearline 4U gateway includes one high-performance solid-state drive, and five spinning-disk drives mounted on individual drive sleds in the front of the chassis. Additional drives are installed in the rear of the chassis.

  • Page 481: Rear View

    The boot drives for the BlackPearl 4U gateway are located inside the chassis and are not accessible from the outside. The base BlackPearl Nearline 4U gateway includes one high-performance solid-state drive, and five spinning-disk drives mounted on individual drive sleds in the rear of the chassis. Additional drives are installed in the front of the chassis.

  • Page 482: Rear Panel

    (BlackPearl 4U contaminants from entering the enclosure and to maintain proper air flow. gateway only) Rear Panel Figure 306 shows the components on the rear panel of the BlackPearl Nearline 4U and 2U gateways. Figure 306 The BlackPearl rear panel components. Component Description IPMI management Not currently supported.

  • Page 483: Specifications

    10 GigE network. 10 GigE ports Note: Spectra Logic recommends using the 10 GigE ports for data transfer to ensure maximum performance. Depending on your configuration, there may be a SAS card installed in an SAS ports available expansion slot.

  • Page 484: Interface Specifications

    Interface Type Number of Ports and Connector Type Ethernet (GigE) Four RJ-45 sockets Ethernet (10 GigE) Two SFP+ optical modules with a duplex LC connector Four SFF-8644 sockets per optional SAS card January 2022 User Guide-BlackPearl Nearline Gateway - 484 -...
  • Page 485 Shielded Category 5 (10/100BaseT connection) data-grade cable with an RJ-45 connector Ethernet (10 GigE) Multimode optical cable with duplex LC connectors 6 Gbps 4-lane cable with SFF-8644 and SFF-8088 connectors Fibre Channel 50 micron—400-M5-SN-I classification January 2022 User Guide-BlackPearl Nearline Gateway - 485 -...

  • Page 486: Appendix D - Regulatory & Safety Standards

    Appendix D - Regulatory & Safety Standards The Spectra BlackPearl Nearline Gateway complies with the safety and regulatory agency standards listed below when installed by a Spectra Logic certified engineer or third-party provider. EU D ECLARATION OF ONFORMITY Spectra Logic Corporation...
  • Page 487 Essential health and safety requirements relating to electrical equipment Directive designed for use with certain violate limits. 72/336/EEC EN 60950-1 Safety requirements of information technology equipment including (EN 60950-1) electrical machines. January 2022 User Guide-BlackPearl Nearline Gateway - 487 -...
  • Page 488 Appendix D - Regulatory & Safety Standards EU Declaration of Conformity January 2022 User Guide-BlackPearl Nearline Gateway - 488 -...
  • Page 489 Appendix D - Regulatory & Safety Standards EU Declaration of Conformity January 2022 User Guide-BlackPearl Nearline Gateway - 489 -...

  • Page 490: Certifications

    ) The BlackPearl 4U System is regulatory model number "826-9", The BlackPearl 2U System is regulatory model number "847-12". The 44-Bay Expansion Node is regulatory model number "847JBOD-14", The 96-Bay Expansion Node is regulatory model number "BSP-5". The 107-Bay Expansion Node is regulatory model number "JBOD 108" January 2022 User Guide-BlackPearl Nearline Gateway - 490 -...

  • Page 491: Fcc Notice

    MISSIONS ARNING AFETY TANDARDS AND OMPLIANCE The Spectra BlackPearl Nearline gateway complies with the following domestic and international product safety standards. • EN 60950-1 Second Edition • UL 60950-1 Second Edition • CSA-C22.2 No. 60950-1-03 • Low Voltage Directive (EU: CE Mark)

  • Page 492: Waste Of Electronic And Electrical Equipment (Weee) Directive

    The RoHS marking indicates that this product is in compliance with European Council Directive 2011/65/2008, on the restriction of the use of certain hazardous substances in electrical and electronic equipment. ECYCLING YSTEM For information on recycling your Spectra gateway, check the Spectra Logic website at: spectralogic.com/environment. ONFLICT INERALS OLICY...
  • Page 493 Appendix D - Regulatory & Safety Standards Conflict Minerals Policy Affected suppliers to Spectra Logic will be required to commit to being or becoming “conflict-free” (which means that such supplier does not source conflict minerals) and sourcing, where possible, only from conflict-free smelters. Each affected supplier to Spectra...

  • Page 494: Appendix E - Open Source Code Acknowledgments & Package List

    This appendix contains the licenses and notices for open source software used in the BlackPearl Nearline gateway. If you have any questions or want to receive a copy of the free/open source software to which you are entitled under the applicable free/open source...

  • Page 495: Java

    YOU DO NOT WISH TO BE BOUND BY THE TERMS, THEN SELECT THE "DECLINE LICENSE AGREEMENT" (OR THE EQUIVALENT) BUTTON AND YOU MUST NOT USE THE SOFTWARE ON THIS SITE OR ANY OTHER MEDIA ON WHICH THE SOFTWARE IS CONTAINED. January 2022 User Guide-BlackPearl Nearline Gateway - 495 -...
  • Page 496 Programs. THE LICENSE SET FORTH IN THIS SECTION 2 DOES NOT EXTEND TO THE COMMERCIAL FEATURES. YOUR RIGHTS AND OBLIGATIONS RELATED TO THE COMMERCIAL FEATURES ARE AS SET FORTH IN THE SUPPLEMENTAL TERMS ALONG WITH ADDITIONAL LICENSES FOR DEVELOPERS AND PUBLISHERS. January 2022 User Guide-BlackPearl Nearline Gateway - 496 -...
  • Page 497 Upon termination, you must destroy all copies of Software. January 2022 User Guide-BlackPearl Nearline Gateway - 497 -...
  • Page 498 Agreement. No modification of this Agreement will be binding, unless in writing and signed by an authorized representative of each party. SUPPLEMENTAL LICENSE TERMS January 2022 User Guide-BlackPearl Nearline Gateway - 498 -...
  • Page 499 Programs and/or Software. The license set forth in this Section C does not extend to the Software identified in Section G. January 2022 User Guide-BlackPearl Nearline Gateway - 499 -...
  • Page 500 Programs and/or Software. The license set forth in this Section D does not extend to the Software identified in Section G. January 2022 User Guide-BlackPearl Nearline Gateway - 500 -...
  • Page 501 G. LIMITATIONS ON REDISTRIBUTION. You may not redistribute or otherwise transfer patches, bug fixes or updates made available by Oracle through Oracle Premier Support, including those made available under Oracle's Java SE Support program. January 2022 User Guide-BlackPearl Nearline Gateway - 501 -...

  • Page 502: Samba

    You can find more information about the data Oracle collects as a result of your Software download at http://www.oracle.com/technetwork/java/javase/documentation/index.html. AMBA Samba is provided under the terms of the GNU General Public License (GPL version 3) January 2022 User Guide-BlackPearl Nearline Gateway - 502 -...

  • Page 503: Nginx

    Ruby is copyrighted free software by Yukihiro Matsumoto <matz@netlab.jp>. You can redistribute it and/or modify it under either the terms of the 2-clause BSDL (see the file BSDL), or the conditions below: January 2022 User Guide-BlackPearl Nearline Gateway - 503 -...
  • Page 504 6. THIS SOFTWARE IS PROVIDED “AS IS” AND WITHOUT ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. January 2022 User Guide-BlackPearl Nearline Gateway - 504 -...
  • Page 505 CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE SOFTWARE. COMMON DEVELOPMENT AND DISTRIBUTION LICENSE (CDDL) Version 2.1 NCLUDED ACKAGES alsa-lib-1.1.2_2 apache-commons-daemon-1.2.3 apr-1.7.0.1.6.1_1 atf-0.21 avahi-app-0.8 bash-5.1.4_1 black_pearl-2.3_2 bluestorm_backend-2.0.2867631_7 bluestorm_frontend-2.1.2869777 bluestorm_gui-2.0.2867631_3 bluestorm_mgmt-2.0.2867631 bluestorm_tests-2.0.2867631_1 bluestorm_workers-2.0.2867631_6 January 2022 User Guide-BlackPearl Nearline Gateway - 505 -...
  • Page 506 January 2022 User Guide-BlackPearl Nearline Gateway - 506 -...
  • Page 507 January 2022 User Guide-BlackPearl Nearline Gateway - 507 -...
  • Page 508 January 2022 User Guide-BlackPearl Nearline Gateway - 508 -...
  • Page 509 January 2022 User Guide-BlackPearl Nearline Gateway - 509 -...
  • Page 510 January 2022 User Guide-BlackPearl Nearline Gateway - 510 -...
  • Page 511 Official rubygem-aws-sdk-codestarconnections-1.13.0 rubygem-aws-sdk-codestarnotifications-1.9.0 rubygem-aws-sdk-cognitoidentity-1.30.0 rubygem-aws-sdk-cognitoidentityprovider-1.49.0 rubygem-aws-sdk-cognitosync-1.25.0 rubygem-aws-sdk-comprehend-1.43.0 rubygem-aws-sdk-comprehendmedical-1.24.0 rubygem-aws-sdk-computeoptimizer-1.14.0 rubygem-aws-sdk-configservice-1.58.0 rubygem-aws-sdk-connect-1.41.0 January 2022 User Guide-BlackPearl Nearline Gateway - 511 -...
  • Page 512 January 2022 User Guide-BlackPearl Nearline Gateway - 512 -...
  • Page 513 Official rubygem-aws-sdk-fms-1.34.0 rubygem-aws-sdk-forecastqueryservice-1.11.0 rubygem-aws-sdk-forecastservice-1.15.0 rubygem-aws-sdk-frauddetector-1.16.0 rubygem-aws-sdk-fsx-1.34.0 rubygem-aws-sdk-gamelift-1.41.0 rubygem-aws-sdk-glacier-1.36.0 rubygem-aws-sdk-globalaccelerator-1.29.0 rubygem-aws-sdk-glue-1.84.0 rubygem-aws-sdk-gluedatabrew-1.5.0 rubygem-aws-sdk-greengrass-1.38.0 rubygem-aws-sdk-greengrassv2-1.2.0 rubygem-aws-sdk-groundstation-1.16.0 rubygem-aws-sdk-guardduty-1.44.0 rubygem-aws-sdk-health-1.33.0 rubygem-aws-sdk-healthlake-1.2.0 rubygem-aws-sdk-honeycode-1.5.0 rubygem-aws-sdk-iam-1.48.0 rubygem-aws-sdk-identitystore-1.4.0 rubygem-aws-sdk-imagebuilder-1.19.0 rubygem-aws-sdk-importexport-1.25.0 rubygem-aws-sdk-inspector-1.33.0 rubygem-aws-sdk-iot-1.66.0 January 2022 User Guide-BlackPearl Nearline Gateway - 513 -...
  • Page 514 January 2022 User Guide-BlackPearl Nearline Gateway - 514 -...
  • Page 515 January 2022 User Guide-BlackPearl Nearline Gateway - 515 -...
  • Page 516 Official rubygem-aws-sdk-personalizeevents-1.16.0 rubygem-aws-sdk-personalizeruntime-1.21.0 rubygem-aws-sdk-pi-1.26.0 rubygem-aws-sdk-pinpoint-1.51.0 Official rubygem-aws-sdk-pinpointemail-1.25.0 rubygem-aws-sdk-pinpointsmsvoice-1.22.0 rubygem-aws-sdk-polly-1.39.0 rubygem-aws-sdk-pricing-1.25.0 rubygem-aws-sdk-prometheusservice-1.2.0 rubygem-aws-sdk-qldb-1.12.0 rubygem-aws-sdk-qldbsession-1.12.0 rubygem-aws-sdk-quicksight-1.43.0 rubygem-aws-sdk-ram-1.23.0 rubygem-aws-sdk-rds-1.115.0 rubygem-aws-sdk-rdsdataservice-1.24.0 rubygem-aws-sdk-redshift-1.54.0 rubygem-aws-sdk-redshiftdataapiservice-1.5.0 rubygem-aws-sdk-rekognition-1.48.0 rubygem-aws-sdk-resourcegroups-1.34.0 rubygem-aws-sdk-resourcegroupstaggingapi-1.36.0 rubygem-aws-sdk-resources-3.94.0 rubygem-aws-sdk-robomaker-1.33.0 rubygem-aws-sdk-route53-1.46.0 rubygem-aws-sdk-route53domains-1.29.0 rubygem-aws-sdk-route53resolver-1.23.0 rubygem-aws-sdk-s3-1.89.0 rubygem-aws-sdk-s3control-1.28.0 rubygem-aws-sdk-s3outposts-1.1.0 January 2022 User Guide-BlackPearl Nearline Gateway - 516 -...
  • Page 517 January 2022 User Guide-BlackPearl Nearline Gateway - 517 -...
  • Page 518 January 2022 User Guide-BlackPearl Nearline Gateway - 518 -...
  • Page 519 January 2022 User Guide-BlackPearl Nearline Gateway - 519 -...
  • Page 520 January 2022 User Guide-BlackPearl Nearline Gateway - 520 -...
  • Page 521 January 2022 User Guide-BlackPearl Nearline Gateway - 521 -...
  • Page 522 January 2022 User Guide-BlackPearl Nearline Gateway - 522 -...
  • Page 523 January 2022 User Guide-BlackPearl Nearline Gateway - 523 -...
  • Page 524 Appendix E - Open Source Code Acknowledgments & Package List Included Packages rubygem-zfs-0.0.12.2864176 samba413-4.13.7_1 sedutil-1.12.2267418 sg3_utils-1.45_1 smartmontools-7.2_1 smp_utils-0.98_1s source-highlight-3.1.9_1 spectra_ltfs-2.5.0.0.2867631 sqlite3-3.34.1,1 staf-3.4.26_1 stress-1.0.4_1 stress-ng-0.12.05 t5seeprom-0.0.1366684_1 talloc-2.3.1 tdb-1.4.3,1 tevent-0.10.2_1 tidy-html5-5.7.28 tmux-3.1c tomcat-native-1.2.24_1 tomcat85-8.5.64 verde_hotpair-2.1.2867631 vim-8.2.2569 zip-3.0_1 zsh-5.8 January 2022 User Guide-BlackPearl Nearline Gateway - 524 -...
  • Page 525 Index BlackPearl software current available version 400 BlackPearl target about 135 create 135 Activation keys BlackPearl user interface entering manually 304 about 59 importing automatically 73 current version 399 Active Directory, join 215 exit 380 Amazon S3 data replication rule log in 78 about 161 menus 60...
  • Page 526 63 contacting Spectra Logic 8 Ethernet ports, configure 264 contacting, Technical Support 445 EU Declaration of Conformity 486 corporate headquarters, Spectra Logic 8 fax numbers, Spectra Logic 8 data drive FCC Notice 491 install new 72 Free BSD...
  • Page 527 NAS volumes add 383 about 202 configure 383 configure 207 mailing address, Spectra Logic 8 create new CIFS share 215 maintenance, replace component 403 create new NFS share 220 management port, use 264 create snapshot 242 MIB file, download 284...
  • Page 528 Ruby on rails 505 ZFS 505 S3 group create 299 S3 service performance metrics 366 configure 274 phone numbers, Spectra Logic offices 8 Safety Standards and Compliance 491 pools, see NAS storage pools, nearline sales, contacting 8 - 528 -...
  • Page 529 472 where to find 446 size and weight 463 services system 460, 483 CIFS 222 Spectra Logic configuring 222, 274, 285 contacting 8 NAS replication 226 status lights 344 NFI 224 storage domain NFS 225 about 145...
  • Page 530 294 types 294, 299 Visual Status Beacon, lights 343 volumes, see NAS volumes 202 warning icon 63 website Spectra Logic 8 WEEE Directive 492 WORM tape media, not supported 98, 135, 308 ZFS, open source acknowledgement 505 - 530 -...

Table of Contents
