- Page 1 OWNER'S MANUAL MOTOR BOAT COASTER 600 DAY CRUISER Manufacturer Corsiva Yachting http://coaster-boats.com/...
-
Page 2: Table Of Contents
INDEX 1. INTRODUCTION ............................. 2 2. STAGE OF DANGER ............................3 3. GENERAL SAFTY RULES ........................... 4 3.1. Safety ................................4 3.2. Passengers on board ........................... 4 3.3. Life-saving equipment ..........................5 3.4. Reboarding ..............................5 4. IDENTIFICATION OF BOAT ..........................6 4.1. -
Page 3: Introduction
The Owner’s manual, which you received together with a boat, will help you to operate your motor boat COASTER 600 DAY CRUISER safely and appropriately so you may use it with a pleasure. Manual contains the description of the boat, its equipment and installation systems as well as practical information about their use and maintenance. -
Page 4: Stage Of Danger
2. STAGE OF DANGER The manual contains three kinds of sign, which are supposed to turn your attention to the actions and situations which may cause danger for health or life if not realized. Following: DANGER The sign warns before appearing the highest danger, which can cause the durable damage of body or death unless the appropriate safety actions are taken. -
Page 5: General Safty Rules
3. GENERAL SAFTY RULES 3.1. Safety Even if it all planned the safety of the sailing remains heavily dependent on the weather, sea conditions and the experience and knowledge of the crew. Always check to-date weather forecast before leaving and see that the circumstances should be expected to the category of construction of the boat. -
Page 6: Life-Saving Equipment
3.3. Life-saving equipment On the boat should be appropriate safety equipment (life jackets, safety harnesses, etc.) as appropriate to the type of boat, weather conditions, etc. In some countries it is Required equipment. Carefully read the manual of a life raft. The crew should be familiar with the use of all equipment safety and emergency maneuvering (man overboard, towing, etc.). -
Page 7: Identification Of Boat
Annex I to Directive 2013/53/UE of European Parliament and of the Council, Recreational craft and personal watercraft. The boat COASTER 600 DAY CRUISER was put to the test by Polish Register of Shipping according with applicable requirements of Annex I to Recreational Craft Directive 2013/53/UE for design category C. -
Page 8: Builder's Plate
4.2. Builder's plate In the cockpit of COASTER 600 DAY CRUISER there is placed the builder’s plate. The builder’s plate includes: Yacht design category – „INSHORE”. Max. number of people and personal equipment which cannot max. x 6 + cross the boat capacity definite by the manufacturer, which includes: 6 people + personal equipment Max. -
Page 9: Stability And Buoyancy
5. STABILITY AND BUOYANCY... - Page 10 DANGER Information about stability and freeboard, floatation and buoyancy is fulfilled only when: The weight of empty boat with equipment (with engine) does not exceed 1365 kg, The maximum power of engine does not exceed 128,7 kW Remember: any change in arrangement of the masses on the side (eg. The addition of a fishing tower, a change in the engine etc.) can significantly affect the stability, trim and behavior of the boat, amount of bilge water should be as small as possible,...
-
Page 11: Weight Of Boat And Maximum Capacity
CAUTION Never cross the safety limit definite by constructor in reference to the maximum load of boat. COASTER 600 DAY CRUISER can accommodate maximum 6 people + fuel, + water + equipment + gear + outboard engine maximum 1050 kg. -
Page 12: Description Of Boat
The yacht is made of durable glass-reinforced laminate as a monolithic construction and of high class materials, guaranteeing trouble-free use of boat for years. COASTER products are applied with such technical solutions which allow to get the optimal stability, reliability and control at the swerves as well as safety at overcoming waves. -
Page 13: Engine
7. ENGINE If a customer wishes, the boat is sold with outboard engine placed in the well in cockpit. In other cases, the manufacturer leaves routed wiring in the engine sump to the dealer or customer in the future he could connect the motor (photo). -
Page 14: Steering System
8. STEERING SYSTEM 8.1. System of steering the boat System of steering the boat’s rudder by the steering-wheel. Steering with an engine is regulated with the engine throttle, which is placed on the right side in cockpit. The throttle changes the speed and the direction of driving screw. - Page 15 Navigational aids. Current receiver. Engine switch of The emergency switch which stop the engine in moment of danger, for example: in moment of overboard the helmsman. You can’t it use in normal stop of the engine. Navigation lights. Navigation lighting is the same as positional lamps, which is: side lights, stern light, top light and anchor light.
-
Page 16: System Of Steering
8.2. System of steering Boat COASTER 600 DAY CRUISER is equipped with a mechanical or hydraulic control boat, depending on the customer's order. Mechanical control system for the boat consists of: Hydraulic control system for the boat consists of: steering wheel,... -
Page 17: Fuel System
9. FUEL SYSTEM The boat is equipped with a stationary fuel tank made of plastic with capacity of 116L, which is placed under the deck. Inspection of the tank can be made through the aft compartment. The fuel tank has a fuel gauge on pulpit. -
Page 18: Electric Installation
10. ELECTRIC INSTALLATION The boat is equipped with electric installation of direct current = 12V. The main source of the boat is the battery with a capacity of 30 Ah to 72 Ah. As an option, is on board the second battery when on boat is mounted a anchor winch. The batteries are located in the back locker, on the right and left. - Page 19 CAUTION Never: work on the live electric installation, modify the craft’s electric system or relevant schemes; any modifications and maintenance should be performed by a qualified marine electric technician, leave the boat unattended with the working electric system. CAUTION Remember, before starting work, turn off the main power switch! Main switch of batteries It includes electric circuits or it switches off it in emergency situations.
-
Page 21: Sanitary System
11. SANITARY SYSTEM On the boat is provided a chemical toilet in bow compartment. The suggested storage location for a chemical toilet is aft compartment. The rules of its use and maintenance are described in the manual book of WC manufacturer CAUTION Before using the toilet make sure it is open water intake valve. -
Page 22: Bilge Instalation
12. BILGE INSTALATION The bilge system is installed in the galley under the floor. Bilge pump suction nozzle Hand bilge pump inside engine compartment 1. Electric bilge pump, 2. Bilge pump suction nozzle, 3. Bilge houses, 4. Bilge pump outlet, On the boat is equipped with two automatic bilge pumps and one manual bilge pump. -
Page 23: Bottom, Side Sea Openings
13. BOTTOM, SIDE SEA OPENINGS The openings in deck, bottom and side may pose a danger as water can get into the boat. Sea valves are served manually, therefore they should be controlled. 1 The outlet of anchor lockers 2 The outlet from sink 3 The outlet from the deck on the port side 4 The outlet from the deck on the starboard... - Page 24 5 The outflow from the port side compartment outlet in the well of engine compartment 6 The outflow from the starboard compartment outlet in the well of engine compartment 7 The outflow from the bilge with a manual bilge pump outlet in the engine compartment 8 The outflow from the bilge with an automatic bilge pump to the engine compartment 9 10 The outflow from the engine compartment on the outside of the transom...
-
Page 25: Ventings
DANGER Never: leave the unattended yacht with open valves, change the construction of valves connection. 13.1. Vents 1 – the vent of the fuel tank 2 – the vent of the water tank 3 – the vent of battery box 4 –... -
Page 26: Fire Protection
14. FIRE PROTECTION The main source of fire on the boat is open fire such as a lighter or candle. WARNING Before using you should: get to know with manufacturer’s instruction in detail equip the boat with fire extinguisher and extinguishing blanket, pay attention to the usage of evacuation exits. -
Page 27: Sundeck
15. SUNDECK According with customer's wish the boat of superstructure can stand the place to sunbathing for crew. You should turn the special attention on behaviors of principles of safety and proper care of mattresses. DANGER Forbidding of transport the children's less 5 years old on stern sundeck and juvenile without lifejackets and parents or the guardians control. -
Page 28: Upholstery
15.1. Upholstery The upholstery should be installed according to the scheme as pictured. Each pillow mattresses has its own designation - it will help you to replacement of individual cushions, when it will be destroyed. Maintenance Upholstered elements will be protected well enough through regular cleaning with a solution of tepid water and gentle detergents or car vinyl cleaning agents. - Page 29 Upholstery marked with the letter E - backrest Upholstery marked with the letter A - seats Upholstery marked with the letter B - sun deck And for that there is a small pocket.
-
Page 30: Maintenance, Painting, Cleaning
16. MAINTENANCE, PAINTING, CLEANING Your boat – the deck, hull and some interior parts were made of fiberglass. To keep the boat in good condition, wash the fiberglass regularly. Wash the boat with clean water with soft detergents, e.g. water with soap. Do not use abrasive cleaning, solvents, ammonia, chlorine or acetone as these will damage the gel-coat surface. -
Page 31: Stainless Steel
16.1. Stainless steel Constructions of bow and stern railings, as well as other metal elements were made of corrosion resistant steel, which means polished stainless steel. WARNIG If you want to keep stainless steel fitting in good state, you should: clean all fittings only with soap and water, use a good quality car wax to protect the stainless steel, wash the deck fitting with sweet water and clean from salt deposits after... -
Page 32: Trailering
17. TRAILERING During the boat transportation it is very important to keep the boat in the horizontal position. Lifting belts should be in the places appointed with the red triangle on a hull according to the following drawing. However, depending on the equipment of the boat, lifting places may change about several centimeters to stern or bow. - Page 33 During placement the hull on trailer one should pay attention that axis of symmetry of hull will be the same like trailer, because trailer rollers are the same support of boat. Take care that the supports will be in places of fences boat. Bow should be placed in limiter of movement tightly and provide for across fastening to the tow ear placed on bow of boat.
-
Page 34: Anchoring, Mooring And Towing
18. ANCHORING, MOORING AND TOWING The owner of a boat / helmsman is responsible for equipping the boat with an anchor, anchor chain / anchor rope, mooring and towing lines ready to use. Anchorahe eguipment Place the anchor in the anchor compartment. Anchor rope is secured to the cleats. Recommended eguipment anchor: 7-8 kg Material... -
Page 35: Environmental Protection
19. ENVIRONMENTAL PROTECTION The chapter contains the indispensable information how you should protect the natural environment during sailing, as well from the crew as from the boat side. There are strict requirements concerning the respect of natural environment not only in many parts of Europe but also all over the world. -
Page 36: Removing Failures
WARNING If the bilge water are dirty avoid the the work of automatic bilge pump, do not remove the illegal plants. Do not remove the contaminated bilge water overboard. WARNING In case if you lack the place for storing waste on the boat, you can remove only organic waste to water. -
Page 37: Warranty
21. WARRANTY 1. Manufacturer CORSIVA YACHTING Artur Grugel with headquarters in Ciechocin it gives guarantee on motor boat COASTER 600 DAY CRUISER number CIN: - C O R − 5-years for the hull structure, eg. no laminate cracks, no delamination of the laminate, no blisters on the laminate, the guarantee does not enclose mechanical damage −... - Page 38 10. Warranty does not include materials and maintenance, belonging to the normal operational service, eg. cleaning, maintenance, inspection, etc. 11. These warranties only include damage and defects resulting from causes inherent in the sold boat. Warranty does not include damage caused as a result of external factors, such as, for example.
- Page 39 Records warranty. Date Note about repair Date Guarantee Date, raising the realization sinature and claim the repair prolonged stamp...
