Basalte EVE Plus Table base 0150-CC Installation Manual

Made in Belgium
Basalte is a registered trademark of Basalte bvba.
EVE Plus is a registered trademark of Basalte bvba.
EVE Plus is a registered design of Basalte bvba.
iPad 5 th and 6 th generation are registered trademarks of Apple Inc.
basalte bvba
hundelgemsesteenweg 1a I 9820 merelbeke I belgium
tel +32 9 385 78 38 I info@basalte.be I www.basalte.be
All manuals and user guides at all-guides.com
Identification of the parts
1
EVE Plus Table base 0150-CC
A Table base
B Plus connector
C Adjustable angle
D Cable route
E USB connector
F
G Charging cable
H Table mount
2
Mounting the table base
1. Mark the location of the table mount using the provided template.
2. Screw the table mount on the table
3. Place the table base over the table mount.
4. a. Start with placing one corner in position
EVE Plus table base
Installation Manual
Lock for the table mount
B
C
A
b. Push the other corner into a locked position.
D
E
G
F
H
