Summary of Contents for FRENETIK Core 8
- Page 1 Core 8 Dante™ PoE+ 8 x 30 W / Mid-Span Distributor User’s manual V1.1 - 03/2020...
- Page 2 User’s manual - Core 8 V1.1 03/2020...
- Page 3 CORE 8 - USER MANUAL Page 1. Carton Contents 2. Introduction 3. Example of use 4. Technical specifications 5. LED indicators 6. Operation of dip-switches for Power over Ethernet (PoE) function 7. Overview User’s manual - Core 8 V1.1 03/2020...
-
Page 4: Carton Contents
- 1 user manual 2. Introduction The Dante™ PoE+ Core 8 distributor offers two 10/100/1000 Mbit/s connection ports as well as eight 10/100 Mbit/s PoE+ ports on the rear panel. The power activation for each output is performed by dip-switches on the front panel. The available power on each port is 30 W. - Page 5 40 × 480 × 118 mm (H x W x D) Weight 1,70Kg Operating temperature range 0°C to 40°C Storage temperature range -20°C to 90°C Humidity 10 to 90% (non-condensing) Certifications FCC Classe A, CE User’s manual - Core 8 V1.1 03/2020...
- Page 6 5. LED indicators On the front panel of the Core 8, there are 10 LEDs that give a status on the operation of the device: Power SOLID GREEN Indicates that the unit is in operation Port Link GREEN ON indicates that the corresponding Ethernet port is (1 à...
- Page 7 Mains power indicator diode LEDs for individual indication of PoE power presence and operation of each output port PoE Activation Dip-Switch for each output port Mains power connector Output Connectors Input and copy connectors User’s manual - Core 8 V1.1 03/2020...
- Page 8 FRENETIK - 1 Allée d’Effiat - Le Parc de l’Événement - Bât. H 91160 Longjumeau - France +33 (0)1 69 10 50 81 frenetik.fr...
