- Page 1 BROBY 3674157 18.10.2019 - Rev. 1 1/16...
- Page 2 2/16...
- Page 3 IMPORTANT INFORMATION! Please read the entire manual carefully before starting to assemble and/or using this product. Follow the manual thoroughly and keep it for further reference. VIGTIG INFORMATION! Læs hele manualen grundigt igennem før samling og/eller brug af dette produkt. Følg manualen nøje, og opbevar den til senere brug. VIKTIG INFORMATION! Läs bruksanvisningen i sin helhet innan du börjar att montera och/eller använda produkten.
- Page 4 WARNING TO AVOID SCRATCHES! In order to avoid scratching this furniture should be assembled on a soft layer - could be a rug. ADVARSEL FOR AT FORHINDRE RIDSER! For at forhindre ridser skal dette møbel samles på et blødt underlag, f.eks. et tæppe. VARNING OM HUR DU UNDVIKER REPOR! För att undvika repor ska denna möbel monteras på...
- Page 5 ANTI-TOPPLE WARNING! This product has to be permanently fixed to the wall with the bracket(s) included, to avoid fatal injury in case it topples over. The pack only contains screws for fastening the anti-topple bracket(s) itself to the product. Please contact your DIY or hardware store for advice on the correct type of screws/raw plugs for your type of wall.
- Page 6 IMPORTANT! It is important that any product which is assembled using any kind of screw is re-tightened 2 weeks after assembly, and once every 3 months - in order to assure stability through-out the lifespan of the product. VIGTIGT! Det er vigtigt, at alle produkter, der samles med alle former for skruer, efterspændes to uger efter samling samt hver tredje måned for at sikre, at produktet er stabilt i hele dets levetid.
- Page 7 GENERAL INSTRUCTION FOR FURNITURE MADE OF WOOD OR WOOD COMPOSITES SUCH AS MELAMINE, LAMINATE OR VENEER SURFACES! Wipe clean with a damp cloth. Use only water or a gentle detergent. Wipe dry with a clean cloth. GENEREL VEJLEDNING TIL MØBLER FREMSTILLET AF TRÆ ELLER TRÆKOMPOSITMATERIALER SOM MELAMIN, LAMINAT ELLER FINER! Rengøres med en fugtig klud.
- Page 8 A × 16 B × 16 C × 1 D × 1 Ø7.7×10mm Ø5×40mm Ø4×12mm 75×30×15mm F × 4 G × 24 H × 24 I × 3 Ø8×7mm Ø3.5×25mm Ø6×8mm 14×23mm J × 3 Ø3×20mm 8/16...
- Page 9 9/16...
- Page 10 Box 1/1: 300×335×30mm 240×29×15mm 240×35×15mm 845×320×23mm 236×234×15mm 845×320×23mm 279×227×3mm 290×235×9mm 218×235×9mm 10/16...
- Page 11 C × 1 D × 1 Ø4×12 mm 75×30×15 mm 15mm Ø3.5×25 mm Ø3×20 mm Ø4×12 mm I × 3 J × 3 Ø6×8 mm Ø3×20 mm 10mm 11/16...
- Page 12 A × 8 B × 8 Ø7.7×10 mm Ø5×40 mm 12/16...
- Page 13 A × 8 B × 8 Ø7.7×10 mm Ø5×40 mm F × 4 14×23 mm 13/16...
- Page 14 14/16...
- Page 15 G × 12 H × 12 Ø8×7 mm Ø3.5×25 mm G × 12 H × 12 Ø8×7 mm Ø3.5×25 mm 15/16...
- Page 16 5 kg 16/16...
