A note about wiring: In addition to the tools listed, your amp
installation will require power and ground wiring, plus RCA
cables, terminals, and a remote turn-on lead. The easiest way
to get all of these items is in an amplifier wiring kit, available
at crutchfield.com.
As with any car audio/video installation, your first
!
step is to disconnect the negative terminal of your
car battery to prevent short circuits. Check your Crutchfield
MasterSheet™ (available for most vehicles) or vehicle owner's
manual for specific directions. In some vehicles, disconnecting
the battery may require you to re-enter a security code or have
the dealer reset the internal computer.
®
Copyright 2005 Crutchfield Corporation
Amplifier Installation Guide
IMPORTANT
Before starting, compare items on your invoice with items received. Carefully check through packaging material. If
any item is missing, please call: Crutchfield Customer Service at 1-800-955-9091
Although reasonable attempts are made to verify the accuracy of the information
contained in this guide, it is presented without warranties or guarantees of any
type due to the constantly changing nature of this type of information and running
changes in vehicle production. Any person or entity using this information does so
at his or its own risk. If you find that our instructions do not apply to your vehicle,
or if you have questions, do not continue with your installation. Contact our toll-free
technical support for assistance (Tech support phone number is on your invoice).
Tools Needed:
(depending upon vehicle)
Flat Blade
Phillips
Screwdriver
Screwdriver
Drill &
Pliers
Bit Set
Wire Stripper/
Heat
Crimp Tool
Shrink Tubing
* 0 0 0 A M P I G *
Panel Tool
Utility Knife
Socket &
Soldering
Ratchet Set
Iron
Electrical Tape
Heat Gun
000AMPIG
Revision 3/14/05
Advertisement
Related Manuals for Crutchfield 000AMPIG
Summary of Contents for Crutchfield 000AMPIG
- Page 1 IMPORTANT Before starting, compare items on your invoice with items received. Carefully check through packaging material. If any item is missing, please call: Crutchfield Customer Service at 1-800-955-9091 * 0 0 0 A M P I G * Although reasonable attempts are made to verify the accuracy of the information...
-
Page 2: Making The Power Connections
Strip the secured in engine insulation off the end of the red power wire that leads into the passenger compartment. compartment, and connect it to the other end of the fuse holder. ® Copyright 2005 Crutchfield Corporation... - Page 3 It’s important to separate the patch cables from the power wires to avoid potential noise problems. Now you can partially re-install the radio in the dash (don’t push it all the way in, in case you need to fix a problem later. Step 7 begins on page 5. ® Copyright 2005 Crutchfield Corporation...
-
Page 4: Wire Routing
Routing wire for components and power connections Determine desired locations for each component. Remove Upper Pillar Trimpanel panels necessary to route and conceal wires. Test system Kick panel before re-installing panels. ® Copyright 2005 Crutchfield Corporation... - Page 5 000AMPIG CAUTION: Amplifier Mounting and Connections Always be careful when drilling or cutting in a vehicle. Be aware of things such as wiring, windows, fuel lines and safety devices. Check drilling/cutting depth and loca- tion to avoid damage to vehicle appearance.
- Page 6 Replace the fuse and verify that the amp turns on. Also, test it with a multi-meter. This will tell you if the remote turn on is working or not. ® Copyright 2005 Crutchfield Corporation...
