Page 3: Table Of Contents
BOSS Audio Systems Congratulations on your purchase of a ® Multimedia Receiver. It has been designed, engineered and manufactured to bring you the highest level of performance and quality, and will offer you years of entertainment pleasure. Specifications....................Safety Notice....................2 Accessories......................3... -
Page 4: Specifications
Model No. BV965NV Fixed front panel with 6.2 inch TFT screen GPS support FM/AM radio DVD fully compatible with DVD/VCD/CD/MP3/MPEG4/JPEG USB and SD card media play support General Bluetooth audio stream and hands-free phone call features AUX input AV input Video output Front/Rear view camera support Front, rear and subwoofer pre-amp output... -
Page 5: Safety Notice
Please read and understand the following safety information before operating this unit. The unit is suitable for 12V power supply (requires grounding). Do not connect it to 24V power supply in trucks or buses, or else it will be damaged. Please use genuine discs instead of incompatible discs or the unit will be damaged and/or the service live will be shortened. -
Page 6: Accessories
Remote control.............. Wire harness..............Mounting brackets............Bracket screws ............. Trim ring................ GPS Antenna..............UNIT INSTALLATION Bracket Screw Bracket Screw 1. Put the 2 brackets to the left and right side of the unit. 2. Use the supplied screws to attach the brackets to the unit. 3. -
Page 7: Remote Control Operation
Navigation menus. VOL +/- Increase or decrease volume. Answer or make a phone call. Numeric buttons Select a title/chapter/track. • In radio mode, select a preset station. • In Bluetooth phone mode, enter a phone • number or a special symbol. End or reject a phone call. -
Page 8: Wires Connection Description
WIRES CONNECTION DESCRIPTION The Description of the Input/Output Interface AM/FM Antenna Jack Video Output GPS antenna jack Fuse Front Camera Input A/V Input Pre-Amp Audio Output Rear Camera Input Wire Harness Connector Wire Harness Explanation Speaker Outputs Power White......... Left Front (+) Yellow........ -
Page 9: Panel Introduction
PANEL INTRODUCTION Remote sensor Aim the remote control directly at the sensor. Built-in microphone Pick up sound in Bluetooth operation. Disc slot Insert a disc. Eject the disc. MODE Switch a system mode. NAVI Enter or exit GPS navigation interface. Function knob - Press and hold to turn the unit on or off. -
Page 10: Main Menu Operation Instruction
MAIN MENU 1 1. NAVI Interface 2. Tuner Interface 3. Streaming Interface 4. DISC Interface 5. Phone Interface 6. USB Interface 7. SD Interface 8. Front/Rear Camera Interface MAIN MENU 2 9. AV INPUT Interface 10. AUX IN Interface 11. Setting Interface There are seven Setting Menus GENERAL SETINGS-Menu 1 1. -
Page 11: Camera Settings
3. When turned on, an audible beep tone confirms each function selection. 4. Touch to select Spanish/English. 5. Touch to select a parental control level. It allows Navi Voice to sound in other source. 7. Turn on or off GPS Time. 8. -
Page 12: Clock Settings
CLOCK SETTINGS-Menu 3 a. Touch to set clock mode: 12 or 24 hour. b. Touch to set hour. c. Touch to set minute. d. Touch to set AM/PM at 12 hour mode. AUDIO SETTINGS-Menu 4... -
Page 13: Access Setup Interface
ACCESS SETUP INTERFACE 1. Touch to select whether to output sound from an external amplifier. 2. Startup volume: default volume. If the volume at the last shutdown is less than this volume, the volume at the last ① shutdown will be used when rebooting; if the volume at the last shutdown is greater than this volume, this default volume ②... -
Page 14: About Settings
TUNER OPERATION ABOUT SETTINGS –Menu 7 1. Touch to enter the touch calibration SETTING interface. 2. Touch to view the version number of the machine. 3. Touch to restore the machine to factory settings. 4. Touch to select whether it is necessary to display the End User License Agreement when booting up. -
Page 15: Disc/Cd/Usb/Sd Playback
DVD MODE OPERATION 1. Touch to select a title/chapter of DVD. 2. Short press to move to the previous chapter; long press to rewind quickly. 3. Touch to playback/pause. 4. Short press to move to the next chapter; long press to fast forward quickly. 5. -
Page 16: Media Playing Cd Audio
MEDIA PLAYING CD AUDIO 1. Show the music’s ID3 information. 2. Time bar: show the total time and playing time of the present song. 3. Touch to change play mode: repeat all, repeat directory, repeat single, sequential play and shuffle play. -
Page 17: Bluetooth Operation
BLUETOOTH OPERATION MENU Click the phone icon to enter the Bluetooth function interface. 1. Bluetooth setting menu: a.Turn Bluetooth on and off. Turn on and the display loops between the gray Bluetooth icon, the white Bluetooth icon. The icon will turn blue when a phone is paired. b.Connect automatically. -
Page 18: Bluetooth Phonebook
BLUETOOTH PHONEBOOK 1.Touch to search for a name or phone number. 2.Contact list. BLUETOOTH PHONE CALL HISTORY 1.Click to sync recents. 2.Touch to show missed calls. 3.Touch to show the dialed phone numbers. 4.Touch to show the received phone numbers. . BLUETOOTH MUSIC-A2DP 1.Skip to the previous music file. -
Page 19: Photos
PHOTOS 1.Keypad: enter a number to select file. 2.Skip to the previous picture. 3. PLAY/PAUSE: Touch to start picture playing mode. Touch again to pause. During picture playing mode, each picture will be played for 5 seconds and then automatically move to the next if the PLAY/PAUSE button is not pressed. -
Page 20: Troubleshooting
Media displayed Cause Corrective Action Loading Disc is being read Wait until the reading finishes Disc is dirty Clean the disc No disc/Bad disc Disc is upside down Insert the disc in the correct way Unknown disc Unsupported disc type Check the disc and change Illegal mechanism Press EJECT for 5s to reset... - Page 21 Problem Cause Corrective Action Incorrect connection Check wiring and correct to parking wire No image Parking brake is not Stop vehicle in safe place and engaged set parking brake ON Flashing image or Improper video signal Check and correct the wiring interference appears connections on screen...
