DVD-RAM drive unit with built-in HDD
Model
Introduction
Thank you very much for purchasing the Fostex Model EX12.
The EX12 is a DVD-RAM drive unit dedicated to the PD-6. It in-
corporates a 12-cm DVD-RAM drive with a 2.5-inch HDD.
By connecting the EX12 to your PD-6, you can use two more drives
dedicated to the PD-6, in addition to the PD-6 internal DVD-RAM
drive.
Before using the EX12, read this manual carefully. We would be
very happy if the unit is helpful to you.
<Note>
To use the EX12, the PD-6 software version must be V2.00 or higher.
If the software version of your PD-6 is lower than V2.00, ask your
local Fostex dealer or sale office for upgrade.
The built-in HDD is formatted in the "Normal" mode when shipped.
This means, the HDD is divided into eight partitions, each of which
reserves approximately 4.7 GB capacity.
For details about how to use the EX12 with the PD-6, see "V2.0 supple-
ment" supplied with the PD-6.
Owner's Manual
EX12
Advertisement
Table of Contents
Summary of Contents for Fostex EX12
- Page 1 The built-in HDD is formatted in the "Normal" mode when shipped. This means, the HDD is divided into eight partitions, each of which reserves approximately 4.7 GB capacity. For details about how to use the EX12 with the PD-6, see "V2.0 supple- ment" supplied with the PD-6. Owner’s Manual...
-
Page 2: Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER - SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. "WARNING" "TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE."... -
Page 3: Precautions On Installation
Otherwise, recorded data may be lost, as well as the DVD-RAM disk and internal HDD may be damaged. Note that Fostex assumes no responsibility on data loss or whatsoever due to use of the unit. Fostex is not responsible for any "direct damage" or "indirect damage" caused •... -
Page 4: Names And Functions
PD-6 IEEE1394/USB 1) Fastenings The left and right fastenings are used to fasten the EX12 and PD-6 when stacking them up. (See the next page for details.) 2) Disk tray You can set a DVD-RAM disk on the tray. 3) [OPEN/CLOSE] key Pressing this key opens or closes the disk tray. - Page 5 5) Pull out the connection cable from inside the EX12. 6) Put the PD-6 on the EX12 and plug the connector of the cable to the PD-6, as shown below. Make sure to plug the connector in the correct direction.
- Page 6 8) Use the fastenings on both the left and right sides of the EX12 to fastening the PD-6. Pull up the metallic projection of each fasten- ing and hang it on the PD-6.(The following pic- tures show the example of the left side.)
-
Page 7: Connecting The Power Cords
• When the EX12 is connected to the PD-6, turn on the EX12 first, followed by the PD-6. • When the EX12 is connected to the PD-6, make sure that both the PD-6 and EX12 are turned off before you switch the selector (for selecting [PD-6 IEEE1394] or [USB]) on the EX12 front panel. - Page 8 Connecting the EX12 alone to your PC By connecting the EX12 to your PC, you can export an audio file on a DVD-RAM disk set to the EX12. Note that you cannot export an audio file on the EX12 internal HDD.
-
Page 9: Main Specifications
Main specifications Internal drives: 12-cm DVD-RAM drive and 2.5-inch HDD (40 GB) Inputs/Outputs: DC12V IN Connector: XLR-4-32 type (male) Pin assignment: 1: GND, 2: NC, 3: NC, 4: +12~18 V DC12V OUT (PD-6 ONLY) Connector: XLR-4-31 type (female) Pin assignment: 1: GND, 2: NC, 3: NC, 4: +12~18 V IEEE1394 port (for PC connection) Connector:... -
Page 10: Declaration Of Ec Directive
In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by generation of noise in some cases. FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of October, 2003) <AUSTRIA>...
