Installation Instructions
3-in-1 High Chair to Booster
Model Number P5369 and P6028
• The seat can tip backwards and fall from the high
chair frame if you unlatch the booster release with
your child in it. DO NOT use this product until you
have installed the brackets on the high chair frame.
• The seat back can detach from the seat bottom if
it is not completely snapped in place. DO NOT use
this product until you have properly installed the seat
back to the seat bottom and re-installed the restraint
system properly on the seat.
WARNING
FALL HAZARD
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fisher-Price 3-IN-1 HIGH CHAIR TO BOOSTER P5369
Summary of Contents for Fisher-Price 3-IN-1 HIGH CHAIR TO BOOSTER P5369
-
Page 1: Installation Instructions
Installation Instructions 3-in-1 High Chair to Booster Model Number P5369 and P6028 • The seat can tip backwards and fall from the high chair frame if you unlatch the booster release with your child in it. DO NOT use this product until you have installed the brackets on the high chair frame. • The seat back can detach from the seat bottom if it is not completely snapped in place. DO NOT use this product until you have properly installed the seat back to the seat bottom and re-installed the restraint system properly on the seat. WARNING FALL HAZARD ™... -
Page 2: Kit Parts
Tool needed for installation: Phillips Screwdriver (not included). This kit contains small parts in it's unassembled state. Adult assembly is required. Seat Back Left and Right Brackets #8 x (The screw is shown actual size.) IMPORTANT! Enclosed is a new seat back, left and right brackets and extra fasteners for assembly. -
Page 3: Bracket Installation Instructions
Bracket Installation Instructions Latch • REMOVE your child from the seat. • While sliding the switch , pull the latch toward Remove These Screws • Turn the high chair frame over. Position it so that the footrest is facing away from you. •... - Page 4 Bracket Installation Instructions #8 x " (1,9 cm) Screw Left Bracket • Push to align the hole in the left bracket with the hole in the seat support. • Insert a #8 x " (1,9 cm) screw (provided in this kit) through the left bracket and into the seat support. Tighten the screw with a Phillips screw- driver. Do not over-tighten. Seat Support Right Bracket • Push to align the hole in the right bracket with the hole in the seat support. • Insert a #8 x " (1,9 cm) screw (provided in this kit) through the right bracket and into the seat support. Tighten the screw with a Phillips screw- driver. Do not over-tighten. Bracket installation is now complete. Seat Support Tube Seat Support • First, fit the slot on the right bracket (labeled 2) onto the seat support tube closest to you • Then, slide the right bracket completely onto the seat support...
- Page 5 Seat Back Installation Instructions LIFT "T" Ends of BACK VIEW Shoulder Straps Shoulder Straps PULL TAB • Pull the tab on the seat back. Lift to remove the • From behind the seat, push the "T" ends of the shoulder straps through the slots in the seat back. seat back from the seat.
-
Page 6: Back View
Seat Back Installation Instructions Seat Back Pad Seat Back Small Slots • Fit the straps on the back of the seat back pad into the small slots in the new seat back. • Press to fasten the pad straps and secure the seat back pad to the new seat back. Slot • At an angle, fit the tabs on the new seat back into the slots in the seat • Push the seat back to "snap" in place IMPORTANT! Pull on the seat back to be sure it is secure to the seat bottom. Seat back installa- tion is now complete BACK VIEW BACK VIEW Pad Straps... -
Page 7: Consumer Information
Consumer Information United States If you have further questions regarding the installation of the brackets or seat back, please call Fisher-Price Consumer Relations at 1-888-683-6224, 9 AM – 7 PM (EST) ® Monday through Friday and 11 AM – 5 PM (EST) Saturday. Hearing-impaired consumers using TTY/TDD equipment, please call 1-800-382-7470. - Page 8 Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2009 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. PRINTED IN U.S.A. P5369pr-0922...
