INSTRUCTION MANUAL
Digital Voice Recorder
SANYO'S HELP-LINE
Call the toll-free number below if you have any difficulties operating this
product.
1-877-999-1840 (Weekdays 8:00 AM - 5:00 PM, Pacific Time)
LlNEA DE CONSULTA SANYO
Llame gratis al número indicado a continuación si tiene dificultades al
utilizar este producto.
1-877-999-1840 (días laborables de 8:00 AM a 5:00 PM, hora del Pacífico)
1AD6P1P1737-B
ICR-B150, Issue Number 1, Printed in Japan
ICR-B150
ENGLISH
ESPAÑOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICR-B150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fisher ICR-B150

Summary of Contents for Fisher ICR-B150

  • Page 1 LlNEA DE CONSULTA SANYO Llame gratis al número indicado a continuación si tiene dificultades al utilizar este producto. 1-877-999-1840 (días laborables de 8:00 AM a 5:00 PM, hora del Pacífico) 1AD6P1P1737-B ICR-B150, Issue Number 1, Printed in Japan ICR-B150 ENGLISH ESPAÑOL...

  • Page 2: Table Of Contents

    ENGLISH CONTENTS Accessories ... 2 Precautions ... 2 Controls ... 3 Power Supply ... 5 MultiMediaCard ... 6 Before Operation ... 7 Adjusting the Date and Time ... 8 Selecting the Folder and Menu ... 9 Recording ... 13 Editing the Recorded Data ... 15 Playback ...

  • Page 3: Accessories

    Notes on clock setting Be sure to set the date and time of the unit’s clock before use. (See “ADJUSTING THE DATE AND TIME” on page 8.) ACCESSORIES Audio cable x 1 CD-ROM x 1 USB cable x 1 PRECAUTIONS •...
  • Page 5 3 4 5 6 INSERT REC DATE TIME HQ SP LP 15. Power switch (POWER) 16. Record mode switch (REC MODE) 17. Playback speed control switch (SPEED CONTROL) 18. Battery compartment 19. External DC jack (EXT DC 3V, bottom of the unit) Display 1.

  • Page 6: Power Supply

    POWER SUPPLY Battery 1. Open the battery compartment lid. 2. Install two “AAA” batteries (not supplied). Observe proper polar- ity. Battery indicator ( The line of rectangles is the battery gauge. Black rectangles show the bat- tery condition while the unit is operating. : Full, good condition (“LOW BATT”...

  • Page 7: Multimediacard Tm

    MultiMediaCard Inserting the MultiMediaCard 1. Open the MultiMediaCard com- partment lid. 2. Check the edge of the card and insert the card as shown in the illustration. 3. Close the lid. Removing the MultiMediaCard 1. Slide the POWER switch (back of the unit) to the OFF position. 2.

  • Page 8: Before Operation

    BEFORE OPERATION Turning the power on and off Slide the POWER switch to the ON position to turn on the power. The unit is now in stand-by mode. Example: Folder name Current file number To turn off the power, slide the POWER switch to the OFF position in the stop mode.

  • Page 9: Adjusting The Date And Time

    ADJUSTING THE DATE AND TIME 1. Press and hold the MENU/FOLDER button down at least 2 seconds in the stop mode. “AUTHOR” appears. 2. Press the MENU/FOLDER button repeatedly until the date and time display appears. Example: 0:00 2002 JUL.01 3.

  • Page 10: Selecting The Folder And Menu

    SELECTING THE FOLDER AND MENU Selecting the folder Press the MENU/FOLDER button briefly in the stop mode. Each time the button is pressed, the display changes as follows: FOLDER BUSI (Business) LECT (Lecture) OTHERS (Others) ALARM (Alarm) Note: After few seconds, it returns to the stand-by mode on the selected folder display.
  • Page 11 2. Press the MENU/FOLDER button repeatedly to select the desired menu. Each time the button is pressed, the display changes as follows: AUTHOR EDIT Date and time ALARM REC TIME BEEP ERASE GUARD 12/24 LCD LEVEL 3. To change the setting of a submenu in the selected menu, press the TIME/SET button so that the display blinks.
  • Page 12 Various menu modes AUTHOR (Selecting ID number/Author name) ID01/USER-01 ~ ID99/USER-99 Note: Author name is automatically created. You may change it by your PC. For more details, see the instruction manual in CD-ROM. EDIT (Selecting edit mode) OVER WRITE: Overwirte recording INSERT: Insertion recording (“INSERT”...
  • Page 13 REC TIME (Selecting recording time mode) SP: For standard recording LP: For long time recording HQ: For high-quality recording Approximate Recording Times TIME 16MB 1 hr. 5 min. 2 hr. 10 min. 4 hr. 20 min. 45 min. Note: Setting or changing recording time can be used for a new file recording. When overwrite or insertion recording starts on the recorded file, it fol- lows the file’s recording time.

  • Page 16: Editing The Recorded Data

    EDITING THE RECORDED DATA Overwrite recording Note: Previous recorded material will be erased. 1. Select the “OVER WRITE” edit mode. (See “SELECTING THE FOLDER AND MENU” on page 9.) 2. Play back the file. (See “PLAYBACK” on page 16.) 3. Slide the operation switch to the STOP position (or press the CRE- ATE FILE button to set the pause mode) where you want to start...
  • Page 17 SPEED CONTROL...

  • Page 18: File Search

    File skip Press the F or E but- ton repeatedly to skip to the desired file in the selected folder. • In the stop mode, it skips to the beginning or end of the current, previous or next file. • During playback mode, it skips to the beginning of the file.

  • Page 19: Selecting Display

    SELECTING DISPLAY Press the TIME/SET button repeatedly during recording, playing and stop mode. The display changes as follows: In the recording mode: Remaining recording time v Current day/time v Original display returns Example of remaining recording time: Author USER-01 REMAIN In the playback mode: Recorded date/time v Current day/time v Remaining playing time v Original display returns...

  • Page 20: Erasing

    ERASING Important Note: Before erasing, make sure that the battery indicator is full. Preparation 1. Slide the operation switch to the STOP position. 2. Select the AUTHOR and FOLDER. (See “SELECTING THE FOLDER AND MENU” on page 9.) Erasing one file 1.
  • Page 21 ERASE TIME/...
  • Page 22 Erasing all memories 1. Press the ERASE button four times. • “ERASE ALL MEMORY” blinks. 2. While “ERASE ALL MEMORY” is blinking, press the TIME/SET but- ton. • “ERASE” appears briefly. All memories in all folders are erased. Example: USER-01 LE 1/ 1 Notes: •...
  • Page 23 Partial erasing (A-B erasing) 1. Press the F or E button to se- lect the file. 2. Slide the operation switch to the PLAY position to start playback. 3. Press the CREATE FILE button to pause at the starting point you want to erase (Point A).
  • Page 24 7. While “ERASE END” is blinking, press the TIME/SET button. • “ERASE” appears briefly. The section between points A and B in the selected file is erased. Playback pause is set automatically. (The elapsed playing time blinks.) Press the CREATE FILE button again or stop playback. Note: If you make a mistake while following steps, press the INDEX/CANCEL button before pressing the TIME/SET button.

  • Page 25: Erase Guard

    ERASE GUARD Erase guard functions to pre- vent accidental erasure. 1. Press and hold the MENU/FOLDER button down at least 2 seconds in the stop mode. (See “Selecting the menu” on page 9.) 2. Press the MENU/FOLDER button repeatedly to select “ERASE GUARD”.

  • Page 26: Voice Alarm Timer

    VOICE ALARM TIMER 1. Set the ALARM ON, date, and time. (See “Selecting the menu” and “Various menu modes” in “SELECTING THE FOLDER AND MENU” on pages 9 ~ 12.) 2. Press the MENU/FOLDER button repeatedly to select “FOLDER ALARM”. 3.

  • Page 27: Before Installing The Application Software

    BEFORE INSTALLING THE APPLICATION SOFTWARE • Your PC must run Microsoft Windows98(SE)/Millennium Edition/2000 Professional/XP Professional/XP Home Edition operating system with USB port. • You must install Microsoft Windows Media Player Ver. 6.4 or later. • Do not connect the unit to your PC yet. •...
  • Page 28 2. Follow the instructions on the screen. 3. After the installation is complete, you must restart Windows. Note: If the screen below appears, click [Continue Anyway].
  • Page 30 3. If the “Wizard” appears on the screen, follow the instructions on the screen. (There is a driver file in the place that you installed the software.) If your PC is “WindowXP”, the screen shows: 1) Click [Next]. 2) Click [Continue Any- way].

  • Page 31: How To Format The Multimediacard In The Unit

    3) Click [Finish]. 4. Operate your PC. (Follow the instructions on the CD-ROM. Refer to “D:\Manual\manual-E.pdf”.) When the “PC Memo Scriber” program is properly started on the PC, “PC CONNECT” appears on the display of the unit, and the control buttons on the unit will not function.

  • Page 32: Enrolling/Transcribing A Data File (Using Viavoice)

    ENROLLING/TRANSCRIBING A DATA FILE (USING VIAVOICE) ViaVoice is not supplied and must be purchased separately. Enrolling 1. Disconnect the USB cable. 2. Connect one end of the audio cable (supplied) to the EAR jack and the other end to the LINE-IN jack on the PC. 3.
  • Page 33 Model” field. Select “[Sanyo ICR-B150 Wavefile]” in the “Device” field. 6) Click [Next]. The Setting Up and the Enrollment will go on. If the voice from the ICR-B150 cannot be recognized using the Audio Setup Wizard, follow the steps below.

  • Page 35: Important Note

    Important Note: When you attempt to transcribe a data file from the unit, be sure to enroll by using the unit. If you enroll data by using the headset supplied with ViaVoice, an extremely low recognition rate results. Note: IBM ViaVoice Release 8 or 9 must be used. IBM and ViaVoice are registered trademarks of International Business Ma- chines Corporation.

  • Page 36: Cleaning The Cabinet

    In Regard to the Display with Windows Explorer When the Digital Voice Recorder is connected to a PC by the USB connec- tion cable, the data recorded on the MultiMediaCard can be displayed by Windows Explorer as data on a removable device. The Digital Voice Recorder records the data into the folder “Voicerec”...

  • Page 37: Fcc Information

    (2) this device must accept any interference received, including in- terference that may cause undesired operation. CANADIAN ICES-003 INFORMATION THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES- 003. Tested To Comply With FCC Standards ICR-B150 Sanyo SANYO FISHER COMPANY 21605 Plummer Street Chatsworth, California 91311 (818) 998-7322...

  • Page 38: Troubleshooting Guide

    TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION The unit does not operate. The batteries are discharged or not installed. Insert two new “AAA” batteries. “ ” and “LOW BATT” appear. The batteries are discharged. Insert two new “AAA” batteries. “POWER OFF” appears when the operation button is pressed. Hold function is set.
  • Page 39 SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION “NO CARD” appears. The MultiMediaCard is not inserted. Insert the MultiMediaCard. (See page 6.) “NO DATA” appears. The file cannot be created. Erase unnecessary files or format the card by the PC. “CARD ERR” appears. The data cannot be read correctly.

  • Page 40: User License Agreement

    READ CAREFULLY BEFORE USE!!! USER LICENSE AGREEMENT IMPORTANT! — BY INSTALLING, COPYING, ACCESSING, DOWNLOADING, AND/OR USING THIS THE SOFTWARE, YOU ARE CONSENTING TO BE BOUND BY AND ARE BECOMING A PARTY TO THIS AGREEMENT AS A LICENSEE. IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT, TERMINATE THIS INSTALLA- TION PROCESS OR, IF THE SOFTWARE IS ALREADY INSTALLED, IM- MEDIATELY UNINSTALL IT.
  • Page 41 The Software covered under this Agreement is protected under the interna- tional conventions and treaties on copyright and the related laws and regu- lations. This license shall constitute a grant of a license to Licensee for a single use of the Software and may not be deemed under any circumstances to constitute a sale of the Software itself.
  • Page 42 • Rental, lease or loan prohibited Licensee shall not lend, lease or loan the Software to any party(ies). • User support service by Licensor Licensor may choose to provide user support service in accordance with the Licensor's policy set out in User Manual, On-line documents, or other printed matters made available by Licensor from time to time (the "Support Service").
  • Page 43 4. Backup copy After having installed a copy of the Software pursuant to this Agree- ment, Licensee may make a single copy of the Software for backup and archival purposes only, provided that any copy must contain all proprietary notices included in the original. If another original medium becomes necessary to use the Software on a computer under this Agree- ment, Licensee may make a single copy of the Software.
  • Page 44 AGREEMENT OR THE USE OF OR INABILITY TO USE THE PROD- UCT, EVEN IF LICENSOR HAS BEEN ADVISED OF THE POSSIBIL- ITY OF SUCH DAMAGES. LICENSOR DOES NOT WARRANT THAT THE SOFTWARE DOES NOT INCLUDE ANY VIRUS OR DEFECTS, THE SOFTWARE ROUTINE OR OTHER SOFTWARE DESIGNED TO RESTRICT UNAUTHORIZED ACCESS;...

  • Page 45: Warranty (For Usa)

    For USA SANYO SERVICE PLUS LIMITTED DICTATION PRODUCTS ONLY In order to obtain factory warranty service for Sanyo Dictation Products, call the toll-free number below. The unit must be packed in the original carton or a well-padded sturdy carton in order to avoid shipping damage. Note: Do not return this unit to the retail store for service.
  • Page 46 Subject to the OBLIGATIONS above and EXCLUSIONS below, SANYO FISHER COMPANY (SFC) warrants this SANYO Dictation product against defects in materials and workmanship for the periods of LABOR and PARTS specified below. SFC will, at its option, within two business days after its receipt of any dictation product that fails to conform to this warranty at SFC’s...
  • Page 47 THE DURATION OF ANY WARRANTIES WHICH MAY BE IMPLIED BY LAW (INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FIT- NESS) IS LIMITED TO THE TERM OF THIS WARRANTY. IN NO EVENT SHALL SFC BE LIABLE FOR SPECIAL, INCIDENTAL OR CONSEQUEN- TIAL DAMAGES ARISING FROM OWNERSHIP OR USE OF THIS PROD- UCT, OR FOR ANY DELAY IN THE PERFORMANCE OF ITS OBLIGA- TIONS UNDER THIS WARRANTY DUE TO CAUSES BEYOND ITS CON- TROL.

  • Page 48: Warranty (For Canada)

    For Canada THE SANYO COMFORT WARRANTY BUSINESS SYSTEMS - DICTA RECORDERS WARRANTY APPLICATION New, unused Sanyo Dicta Recorder products purchased in Canada are warranted against manufacturing defects in materials and workmanship for ONE YEAR for parts and NINETY DAYS for labour, from the date of purchase by the original retail purchaser.
  • Page 49 ORIGINAL RETAIL PURCHASER’S RESPONSIBILITY You, the original retail purchaser, must present your original, dated bill-of- sale together with this warranty to SANYO Canada Inc. or to an authorized Sanyo Service Depot when you make a claim under this Warranty. You, the original retail purchaser, are responsible for any costs of TRANS- PORTING the product to and from SANYO Canada Inc.
  • Page 50 HOW TO OBTAIN WARRANTY SERVICE Please contact the Sanyo Authorized Dealer from whom the product was purchased, or contact us directly at: SANYO Canada Inc. 1-300 Applewood Crescent Concord, Ontario L4K 5C7 (905) 760-9944 1-800-263-2244 http://www.sanyocanada.com SDR 01/05 (R11) Model No. Serial No.
