Summary of Contents for BE Ag & Industrial Agri Ease BE-SG24
- Page 1 STUMP GRINDER BE-SG24 OPERATIONS & PARTS MANUAL PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION MACHINE USE AND CARE SET-UP PROCEDURES OPERATION STORAGE & MAINTENANCE PARTS LIST & EXPLODED ASSEMBLIES BE-SG24 USER MANUAL...
- Page 3 IMPORTANT SAFETY INFORMATION WARNING Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious injury. The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product but must be supplied by the operator.
- Page 4 MACHINE USE AND CARE • Always be sure the operator is familiar with proper safety precautions and operation techniques before using machine. • Do not force the machine. Machines do a better and safer job when used in the manner for which they are designed.
- Page 5 TRIMMING THE PTO SHAFT The stump grinder is shipped with a slip clutch PTO shaft that can be Þtted to most Category 1 tractors. The PTO shaft may need to be trimmed depending on your tractor and conÞguration. SET-UP PROCEDURES Follow the steps below to ensure the PTO shaft is correctly Þtted to your tractor.
- Page 6 4. Verify the distance between the locking pins on the PTO shaft while in the compressed state (Dim B) as shown in the image below. It should measure 34” (862.5 mm). 4. Verify the distance between the locking pins on the PTO shaft while in the compressed state (Dim B) as shown in the image below.
- Page 7 FLYWHEEL TOOTH TORQUING FLYWHEEL TOOTH TORQUING Prior to each operation, ensure all 34 teeth are torqued to 160 ft•lb (215 N•m) using a torque Prior to each operation, ensure all 34 teeth are torqued to 160 ft•lb (215 N•m) using a torque wrench with a wrench with a 24 mm socket.
- Page 8 OPERATION PRE-START CHECKLIST 1. Prior to operation, ensure all 34 teeth are torqued to 160 ft•lb [215 N•m] using a torque wrench with a 24 mm socket. Refer to the “FLYWHEEL TOOTH TORQUING” section of the operator’s manual. 2. With the stump grinder attached to your tractor, take the appropriate measurements to trim the PTO shaft.
- Page 9 Remove the stabilizer pin prior to operation as shown below: 4. Remove the stabilizer pin prior to operation as shown below: Remove the leg locking pins, slide the legs up inside the tubes, and reinstall the locking 5. Remove the leg locking pins, slide the legs up inside the tubes, and reinstall the locking pins to secure pins to secure them in place.
- Page 10 Once the stump is at ground level, continue to take up to 2” (50 mm) deep passes until the 6. Reverse over a tree stump and lower the stump grinder so it will remove 2” (50 mm) per pass. Always stump and roots are 4-6”...
- Page 11 Effective cutting area Therefore, when grinding a tree stump, always start from the right side of the stump, moving Therefore, when grinding a tree stump, always start from the right side of the stump, moving incrementally incrementally to the left, pulling the grinder straight forward through the stump on each pass. to the left, pulling the grinder straight forward through the stump on each pass.
- Page 12 GRINDING LEFT-TO-RIGHT Left Right CHAINSAW HOLDER CHAINSAW HOLDER Use the chainsaw holder only during transport. Always remove the chainsaw from the holder prior to Page 13 of 18 Use the chainsaw holder only during transport. Always remove the chainsaw from the holder grinding stumps.
- Page 13 STORAGE 1. Lower both support legs and reinsert the locking pins. MAINTENANCE 2. Insert the stabilizer pin in either the left or right side of machine. It does not matter which side is selected. 3. Lower the stump grinder onto a flat, level surface. 4.
- Page 14 GREASING GREASING The stump grinder has six (6) grease points: two (2) flywheel bearings, two (2) hinge pins, and two (2) on the PTO shaft. Check each grease point prior to use and add grease as needed. The stump grinder has six (6) grease points: two (2) ßywheel bearings, two (2) hinge pins, and two (2) on the PTO shaft.
- Page 15 PARTS LIST Highlighted rows indicate components exclusive to European markets. DESCRIPTION HOUSING BACK FRAME BACK SUPPORT LEG FLYWHEEL FLYWHEEL SHAFT FLYWHEEL TOOTH GREASE PIN, 25mm DIA GREASE FITTING, STRAIGHT, M6 X 1 TAPERED THD DEFLECTOR PLATE CHAINSAW HOLDER MOUTING PLATE CHAINSAW HOLDER CLAMPING PLATE CHAINSAW HOLDER RUBBER MAT CHAINSAW REST RUBBER MAT...
- Page 16 EXPLODED ASSEMBLIES COMPLETE ASSEMBLY BE-SG24 USER MANUAL...
- Page 17 BE-SG24 USER MANUAL...
- Page 18 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-SG24 USER MANUAL...
