PETROL CHAINSAW
P C S - 2 6 0 0
O W N E R S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCS-2600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Parker PCS-2600

Summary of Contents for Parker PCS-2600

  • Page 1 PETROL CHAINSAW P C S - 2 6 0 0 O W N E R S M A N U A L...

  • Page 2: Table Of Contents

    CHAIN BRAKE ............................32-34 OIL FLOW ..............................35 All photographs and drawings in this manual are supplied by Parker Products Ltd. to help you with the operation MAINTENANCE & CARE ........................ 36-37 and maintenance of the product. The information contained in this manual was accurate at the time of produc- tion, however Parker Products Ltd.

  • Page 3: General Safety

    GENERAL SAFETY SYMBOLS ON THE MACHINE FUEL FILLER POINT HIGH SPEED ADJUSTMENT SCREW • WARNING! Read and fully understand this user manual before operating the machine. • WARNING! Never allow children to use the machine. LOW SPEED ADJUSTMENT SCREW • WARNING! The chainsaw has been specially designed for tree maintenance and should only be used by trained operators.

  • Page 4: For Safe Operation

    FOR SAFE OPERATION FOR SAFE OPERATION • WARNING IMPORTANT Never start cutting until you have a clear work area, secure which could subsequently cause the flywheel to disintegrate.) To reduce the risk of injury, the user must read • • Never operate a chainsaw when you are fatigued, ill, or upset, or footing, and a planned retreat path from the falling tree - risk of When transporting your chainsaw, make sure the appropriate guide...
  • Page 5 FOR SAFE OPERATION FOR SAFE OPERATION • Sawdust, fumes, smoke and lubrication oil mist may be produced • Do not rely exclusively on the safety devices built into your saw. • Do not lean too far forward • Wipe spilled fuel completely using a dry rag if any spillage occurs •...
  • Page 6 Only use compatible chains to avoid damaging your machine. • Store tools so that they do not have very cold handles when next could receive serious burns. For any assistance contact Parker Products. used. • BY HAND: When carrying your saw by hand, the engine must Using non-recommended replacement parts may result in damage be stopped and the saw must be in the proper position.

  • Page 7: What's In The Box

    WHAT’S IN THE BOX WHAT’S IN THE BOX MAIN TOOL KIT BODY +CHAINSAW SPIKE +2X SPIKE SCREWS +CHAIN FILE +SPARKPLUG WRENCH +X2 SCREWDRIVERS +LARGE ALLEN KEY +SMALL ALLEN KEY COVER 10" 2X SAW CHAINS 10" 40 LINK 0.375 PITCH 1.5mm GAUGE...

  • Page 8: Features

    FEATURES FEATURES CHAIN PRIMER THROTTLE BRAKE BUBBLE TRIGGER CHOKE BUMPER STARTER 10" LEVER SPIKE RECOIL FIXING FUEL POINT EXHAUST CHAIN CHAIN OIL GRIP PORT TENSIONER HANDLE...

  • Page 9: Inspection

    INSPECTION INSPECT CHAINSAW FUEL MUST BE MIXED WITH 2 STROKE OIL AT A 25:1 RATIO (PETROL:OIL) THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK Inspect the Chainsaw and all of its components. Make sure everything is in good working order before use. Regular periodic inspection is required to ensure the Chainsaw is suitable for the task.

  • Page 10: Assembly

    ASSEMBLY ASSEMBLY DISENGAGE THE BRAKE REMOVE THE BRAKE ASSEMBLY LOCATE THE BUMPER SPIKE ATTACH THE BUMPER SPIKE Ensure the brake is disengaged by pulling the handle Remove the brake assembly by removing the nut and Attach the bumper spike (also referred to as the chain Using the two (2) screws and screwdriver provided in firmly back.
  • Page 11 ASSEMBLY ASSEMBLY INSTALL THE CHAIN INSTALL THE GUIDE BAR CHECK CHAIN DIRECTION ADJUSTING THE TENSIONER Wrap the chain around the sprocket (located behind the Install the guide bar and slide fully towards the Again check your chain is pointing in the correct Adjust the chain tensioner or guide bar position so that sprocket.
  • Page 12 ASSEMBLY ASSEMBLY REFIT THE BRAKE ASSEMBLY FINGER TIGHTEN BOLT TENSION CHAIN SECURE BRAKE COVER Refit the brake assembly cover. Carefully insert the two Use your fingers to tighten the nut that holds the brake While holding the tip of the bar, use the screwdriver With the chain tensioned correctly it is now possible to tabs at the rear of the cover into the two slots to the rear assembly in place.

  • Page 13: Fill The Tanks

    ASSEMBLY FILL THE TANKS CHECK CHAIN ROTATION CHECK CHAIN TENSION FILL THE FUEL TANK FILL THE CHAIN OIL TANK FUEL MIX CHAIN OIL Check for smooth rotation of the chain. When correctly Check the tension of the chain. When correctly adjusted Make sure there is sufficient fuel inside the Make sure there is sufficient chain oil (ISO100) inside adjusted it should be possible to manually run the chain...

  • Page 14: Starting The Engine

    STARTING THE ENGINE STARTING THE ENGINE ENGAGE THE BRAKE USE THE PRIMER BUBBLE CLOSE CHOKE (COLD START) OPEN CHOKE (WARM START) ALWAYS START THE ENGINE WITH THE CHAIN Press the primer bubble six times or until it is filled with For cold engine starts, turn the choke on (Closed) by For warm engine starts, the choke should be off in the fuel.
  • Page 15 STARTING THE ENGINE STARTING THE ENGINE TENSION THE RECOIL START THE ENGINE (WARM) SWITCH ON START THE ENGINE (COLD) 1. Make sure that the choke is OFF/OPEN Set the on/off switch to the "On" position (I). Place the chainsaw on the ground and place your 1.

  • Page 16: Using The Throttle

    USING THE THROTTLE USING THE THROTTLE THROTTLE LOCK THROTTLE TRIGGER THIS PAGE HAS INTENTIONALLY BEEN LEFT BLANK To use the throttle correctly you are required to With the heel of your hand press on the throttle With the throttle trigger now unlocked use your unlock the throttle trigger by using the throttle lock to release the throttle trigger.

  • Page 17: Chain Brake

    CHAIN BRAKE CHAIN BRAKE CORRECT USE OF CHAIN BRAKE INCORRECT USE OF CHAIN BRAKE The chain brake is a device which stops the chain should the chainsaw recoil due to kickback. Normally, the brake is The following will help maintain the chain brake's ability to protect the The following may interfere with the chain brake's ability to protect the activated automatically by inertial force, however it can also be operator...

  • Page 18: Oil Flow

    CHAIN BRAKE OIL FLOW TESTING THE BRAKE TESTING THE AUTOMATIC BRAKE ADJUSTING THE OIL FLOW 1. Start the engine. The automatic chain brake stops the chain when kickback occurs. Chain and bar lubricant promotes smooth operation by keeping the chain clean and free-running on the guide bar. Oil will 2.
  • Page 19 MAINTENANCE MAINTENANCE CLEANING THE AIR FILTER REMOVING THE SPARK PLUG The spark plug may need removing or replacing after Before cleaning, inspecting or repairing the prolonged use. You may need to adjust the gap to ensure safe unit make sure the engine is off and cool. operation of your machine.

  • Page 20: Adjusting The Carburettor

    ADJUSTING THE CARBURETTOR ADJUSTING THE CARBURETTOR ADJUSTING THE CARBURETTOR ADJUST ENGINE IDLE SPEED LOW SPEED ADJUSTMENT SCREW HIGH SPEED ADJUSTMENT SCREW The carburettor on your saw has been factory set but may require some minor adjustments due to a change in operating conditions.

  • Page 21: Fuel Instructions

    FUEL INSTRUCTIONS FUEL INSTRUCTIONS RECOMMENDED MIXING RATIO GASOLINE 25 : OIL 1 HOW TO MIX FUEL FUELLING THE UNIT FOR YOUR ENGINE LIFE, AVOID: • • Petrol is very flammable. Avoid smoking or bringing any flame or Pay attention to agitation. 1.

  • Page 22: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Clean and readjust spark plug gap to between 0.6mm and 0.7mm or No spark Replace spark plug Engine will not start Fuel mix Replace with correct fuel mix 25:1 (Petrol/Oil) Remove and dry the spark plug, then pull the starter again with no Flooded engine choke Fuel mix...

  • Page 23: Maintenance And Care

    MAINTENANCE & CARE MAINTENANCE & CARE Visual inspection Fuel tank Clean Complete machine Clean Chain oil tank Clean Chain lubrication Check Throttle trigger, trigger lockout, choke lever, stop switch, Master Check Inspect, also check sharpness Control lever (depending on version) Chain Clean Chain brake...
  • Page 24 MAINTENANCE & CARE Chain sprocket Check Clean All accessible screws and nuts Air filter Re-tighten (not adjusting screws) Replace Anti-vibration elements Check Check Chain catcher Air inlet on fan housing Clean Replace Cylinder fins Clean De-coke after first 100 hours of operation, then Exhaust port every 150 hours of operation Carburettor...

  • Page 25: Exploded Parts Diagram

    PCS-2600 EXPLODED PARTS DIAGRAM ORDER ONLINE VISIT OUR ONLINE STORE FOR ALL YOUR SPARE PARTS & CONSUMABLE NEEDS. OUR PARTS DEPARTMENT IS EXTENSIVE, WE STOCK PARTS FOR ALL OF OUR PRODUCTS. Illustrations accurate at time of going to print. Please be aware products and parts may change design without notice.

  • Page 26: Parts Index

    PCS-2600 PARTS INDEX PCS-2600 PARTS INDEX PCS-2600 PARTS INDEX PCS-2600 PARTS INDEX FILTER GROUND WIRE COVER TOP AIR FILTER COVER STRAIGHT PIN 3×4 SCREW CHAIN ADJUSTING CRANK SHAFT ASSEMBLY CYLINDER WASHER 4 PLUG PAD CLUTCH SUPPORT SCREW ST5×13 NEEDLE BEARING BALL...

  • Page 27: Specifications

    SPECIFICATIONS SPECIFICATIONS PCS-2600 POWER UNIT PCS-2600 GUIDE BAR Engine 2-Stroke Spark Plug LD L7T Type Sprocket Nose Displacement (cm³) 25.4 Oil Feeding System Mechanical Pump Sprocket Teeth x Pitch 6T x?.?? Bore x Stroke 34mm x 28mm Power (kw/min- 1) 0.9 kw / 8,500 min- 1...

  • Page 28: Guarantee

    Parker Products Ltd ☑ EN ISO 14982 : 2009 In case of any fault please contact us directly or return the product to us, Parker Products Ltd, or an ☑ EN ISO 3744 : 1995 Being the responsible person appointed by the manufacturer.
  • Page 29 P C S - 2 6 0 0 March 2022 Rev 1.0...
