Summary of Contents for Solo SOLO5

  • Page 1 USER MANUAL...

  • Page 2: Using This Manual

    This manual contains important instructions for the safe use and operation of the scooter. Please fully read the manual before using the scooter. Package Contents 1x Scooter quality checklist 1x SOLO5 electric scooter 1x SOLO5 charger 1x Allen key 1x Safety manual...
  • Page 3 DFT guidelines. The owner assumes all liability and risk associated with the use of electric scooter products and holds SOLO-E Ltd and its owners free from any liability or injury caused by their use.

  • Page 4: Specifications

    Specifications Specification Description Top speed 25kmh / 15.5mph Speed modes 3 - Eco, Mid, High Accelerator type Thumb Controlled Range Up to 45km / 28miles* Brake type Front and Rear Disc Lights Front and Rear Brake Motor 350 Watts Battery 36V 10.4Ah Weight limit 150kg / 23.6 stone...
  • Page 5 SOLO5 Overview LED display Brake lever Throttle Light switch Bell Folding buckle Anti-slip deck surface Front light Front dual Rear suspension suspension Brake light Assistant towing wheels Kickstand Brushless gearless motor...
  • Page 6 LCD Dashboard Gear mode Front light Battery Speed charge MPH/KPH indicator Journey mileage Total mileage...
  • Page 7 Dashboard The dashboard features three buttons: Press the arrow button to change the gear mode between “ECO”, “MID” and “HIGH” Press and hold the power button to power the scooter on and off Press the “M” button to change the display units between miles and kilometers...
  • Page 8 Assembly & Unfolding the Scooter Step 1 - Open the packaging and carefully remove the scooter and contents. Step 2 - Using one hand press down on the folding buckle, and use the other hand to pull the steering column up to unfold the scooter.
  • Page 9 Assembly - Unfolding the Scooter Step 5 - Fix the handle bars into their sockets. Step 6 - The scooter is fully unfolded and ready for use.
  • Page 10 Collapsing & Carrying The Scooter Step 1 - Press the folding buckle down to unlock the folding mechanism. Step 2 - Fold the steering column fully down to the foot plate. Step 3 - When folded, the scooter can then be towed along on its towing wheels.
  • Page 11 Using The Throttle & Brake Press the right throttle lever to accelerate the scooter to the desired speed. Brakes Release the throttle lever and gently press both brake levers to slow the scooter down to a controlled stop. Throttle Ensure both the throttle and brake levers are released when powering the scooter on or off.

  • Page 12: Riding The Scooter

    Riding The Scooter Only operate the scooter in areas where legally permitted and safe to do so. Do not ride the scooter on public highways or in built-up areas that pose a risk of danger or injury to the rider or bystanders. Step 1 - Press and hold the power button on the dashboard to power up the scooter.

  • Page 13: Scooter Safety

    Scooter Safety Always follow local guidance and highway laws when using the scooter at all times. Be wary of your environment, pedestrians and traffic at all times. Read this manual in full before riding the scooter for the first time. Prior to riding, check that the battery is charged, and there are no defects or damage that may affect the safety of the scooter.
  • Page 14 Scooter Safety Always follow local guidance and highway laws when using the scooter at all times. Be wary of your environment, pedestrians and traffic at all times. Use common sense and be courteous at all times when riding the scooter. Use both hands on the handlebars all times when riding the scooter.
  • Page 15 Cleaning Before cleaning the scooter ensure it is powered off, unplugged and away from the charger unit and the charging port cap is securely closed to prevent risk of injury or damage through electrical shock or short circuiting. Clean the scooter using a soft, damp cloth only; for stains that cannot be wiped off, use a drop of toothpaste and a toothbrush to gently polish the stain away, wiping with a soft, damp cloth to finish.

  • Page 16: Battery Maintenance

    Battery Maintenance Do not disconnect the battery for any reason as this can cause injury or damage due to electric shocks or short circuiting. In the event of a battery issue, please contact your authorised dealer for further advice and support. Ensure the scooter is stored in a cool dry place, ensuring the battery is away from direct sunlight, moisture, extreme heat or cold otherwise this can cause reduced battery effectiveness.

  • Page 17: Manufacturer's Warranty

    Manufacturer’s Warranty Riders can enjoy peace of mind with our scooters; we will glady repair or replace scooters or components in the event of faults caused by quality issues as per the below cases. Warranties will not be upheld if any damage or faults are deemed malicious or as a result of inappropriate use as per this manual.
