- Page 1 INSTALLATION OPERATIONS OWNERSHIP GUIDE Model: B1B-50100 superiorwatersales.com (888) 323.5689...
- Page 2 NOTE: The Five-O Systems are intended for treatment of potable water provided by municipal water providers. While the Five-O Series system may be effective for treatment of Well Water it is vital that a well water quality analysis be provided for review PRIOR TO INSTALLATION in order to ensure that optimimum results will be delivered.
- Page 3 INSTALLATION - OPERATIONS - OWNERSHIP GUIDE Model: B1B-50100 Once installed, the Five-O Series system is a maintenance free whole house water treatment system. Each system includes a pre-programmed fully automatic Clack (Made in USA) valve that runs a self-rinsing cycle every 7 days.
- Page 4 superiorwatersales.com For service, support and info. visit or call 888.323.5689 OVERVIEW System Tank Size Depth Inlet/ Flow Rate (lbs.) (in.) (in.) (in.) Outlet (GPM) (in.) B1B-50100 8GPM 10” x 54” 1” Five-O System INSTALLATION AT A GLANCE Plumb Inlet/Outlet to system at Main Point of Entry.
-
Page 5: Pre-Installation
superiorwatersales.com For service, support and info. visit or call 888.323.5689 PRE-INSTALLATION 1. All installations are to be done in accordance with any local codes. 2. Do not use water that is micro-biologically unsafe or of unknown quality without adequate disinfection before or after the system. 3. - Page 6 superiorwatersales.com For service, support and info. visit or call 888.323.5689 CONTENTS The Five-O system arrives in one carton and comes pre-assembled and pre-programmed. After inspecting the outer carton for any damage, slide top section of carton off or open at top. Inside on top of valve will be the items pictured below.
- Page 7 The Five-O Series System Guide 1. Determine Five-O Series installation location. *NOTE* As you look at the rear of the Five-O Series control valve, the inlet water line will always enter the hole on the LEFT SIDE of the bypass valve assembly.
-
Page 8: Drain Line Installation
For service, support and info. visit or call 888.323.5689 DRAIN LINE INSTALLATION 1. The FIVE-O Series control valve has a threaded plastic swivel drain connection located directly behind the electronic control valve. 2. Attach a PVC schedule 40 drain line to the drain fitting and run to an appropriate discharge area such as a flower bed, utility sink or area drain. -
Page 9: Charging The System
Failure to close ball valve to house will result in carbon fines entering your household water supply system and making it difficult to remove them 4. Open the intake side of the bypass valve to allow the FIVE-O Series tank to fill with water. 5. This will take less than five minutes. - Page 10 • Press “SET HOUR” and the button simultaneously for 3 seconds until the digital display begins to flash. This screen will allow you to set the time for regeneration of the FIVE-O Series unit. 2 A.M. is the factory default setting (If you see anything other than 2 A.M., press the ...
- Page 11 superiorwatersales.com For service, support and info. visit or call 888.323.5689 BCKWSH PROG SET UP - CONT’D. STEP 5: CONTINUED • Press “SET HOUR” to accept this setting (a blinking arrow with dashes will appear pointing to Min. Fill) • Press “SET HOUR” button again STEP 6: Confirm Day To Regeneration Cycle •...
-
Page 12: Frequently Asked Questions
NOTE: In a home with 4 people, the water heater will need to be flushed (of dissolved solids) 3-4 months after installation of the FIVE-O, or any other HALO solution that includes the SUPERIOR WATER CONDITIONER. This is because the SUPERIOR WATER CONDITIONER water conditioner will dissolve existing scale, prevent new scale formation and inhibit hard water corrosion. - Page 13 SUPERIOR WATER CONDITIONER - 10 Limited Year Warranty How much is replacement cost when media reaches end of life? Call us for details What are the Commercial Uses for the Superior Water Conditioner? Heating & Boiler Applications Cooling and Cooling Tower Applications Food Service &...
- Page 14 It is primarily used for commercial applications where scale prevention is required, such as; water heater pretreatment, reverse osmosis pretreatment, etc. It is also used for used for residential applications where SUPERIOR WATER CONDITIONER™ water is desired for both taste and functional use.
-
Page 15: Programming Quick Reference
superiorwatersales.com For service, support and info. visit or call 888.323.5689 FREQUENTLY ASKED QUESTIONS - 4 Won’t the calcium crystals revert back to their dissolved state in my water heater? The calcium crystals will remain suspended for approx.. 24 to 72 hours. Normal water usage indicates that a typical household will turn the hot water over in a correctly sized water heater at least once per day. -
Page 16: Troubleshooting
superiorwatersales.com For service, support and info. visit or call 888.323.5689 TROUBLESHOOTING PROBLEM #1 TIMER DOES NOT DISPLAY TIME OF DAY Possible Cause • Transformer unplugged • No electric power at outlet • Defective transformer Solution • Connect Power • Repair outlet or use working outlet •... - Page 17 superiorwatersales.com For service, support and info. visit or call 888.323.5689 TROUBLESHOOTING PROBLEM #4 CONTROL VALVE STALLED IN REGENERATION Possible Cause • Motor not operating Solution • Replace motor • Repair outlet or use working outlet • Broken drive gear or drive cap assembly •...
- Page 18 superiorwatersales.com For service, support and info. visit or call 888.323.5689 TROUBLESHOOTING PROBLEM: ERROR CODES • E1 – Unable to recognize start of Regeneration • E2 – Unexpected stall • E3 – Motor timed out trying to reach next cycle position •...
- Page 19 The following information and list of “tips” was designed to help you better understand and maximize the effectiveness of this superior water treatment technology. Understanding and Appreciating Aragonite: In appliances, on dishes and on countertops where water is frequently left standing, you may begin to notice a powdered talc-like substance collecting.
- Page 20 superiorwatersales.com For service, support and info. visit or call 888.323.5689 TIPS & BEST PRACTICES Tips To Remove & Prevent Lime Scale Film On: Dishes, Glasses, Small Appliances & Plumbing Fixtures That Have Been Subjected To Untreated Water Prior To The Installation Of Your FIVE-O System: These items likely have soap scum and lime scale build up.
-
Page 21: Things You'll Need
superiorwatersales.com For service, support and info. visit or call 888.323.5689 TIPS & BEST PRACTICES Toilet Maintenance & Cleaning: 1. Adding bleach to toilet bowl will help prevent mildew and bacteria. This is particularly important for newer low-flush toilets that do not fully flush away deposits. - Page 22 superiorwatersales.com For service, support and info. visit or call 888.323.5689 WATER QUALITY RESOURCES Resources for more detailed information on water quality treatment challenges and solutions you can go to: • www.epa.com • www.nrdc.gov • www.water.com Activated Carbon General contaminant removal capabilities. Contaminants Effectively Removed Limited Contaminant Reduction Chlorine Fluoride...
-
Page 23: Limited Warranty
Limited Warranty Model: B1B-50100 B1BRANDS.COM, LLC dba Superior Water Sales (SWS) point of entry residential water filters and con- ditioners (up to 13” diameter mineral tanks) are warranted to the original owner at the original residential installation location to be free from defects in materials and workmanship from the date of manufacture as specified. - Page 24 Thank you for choosing us to provide solutions to improve your water quality at home. superiorwatersales.com is committed to delivering sustainable and effective solutions to improve household water quality by using premium media and components in order to provide these solutions. At the end of the day, we understand that you chose us in order to obtain the peace of mind that comes with having a premium water quality treatment solution to protect your family, home &...
