Fantom PT302H Owner's Manual

Rotary tool kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
ROTARY TOOL KIT
Model No.
PT302H
WARNING
!
Always have one hand
firmly placed on the
tool body while
operating. Never
operate the tool by
holding only the tool
handle.
CAUTION:
Before using this Rotary
Tool, read this manual and
follow all its Safety Rules
and Operating Instructions.
FANTOM, 178 West Service Road, Champlain, N.Y. 12919
· Safety Instructions
· Accessories
· Assembly
· Operation
· Maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FANTOM PT302H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fantom FANTOM PT302H

  • Page 1: Safety Instructions

    Owner’s Manual ROTARY TOOL KIT Model No. PT302H WARNING Always have one hand firmly placed on the tool body while operating. Never operate the tool by holding only the tool handle. CAUTION: Before using this Rotary Tool, read this manual and follow all its Safety Rules and Operating Instructions.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SECTION Product Specifications …………………. Power Tool Safety ..…………………….. Rotary Tool Safety .…...…... Electrical Requirements & Safety …….. WARNING Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains chemicals known (to the State of California) to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: ·...

  • Page 3: Power Tool Safety

    POWER TOOL SAFETY GENERAL SAFETY RULES WARNING Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.

  • Page 4: Rotary Tool Safety

    SERVICE Tool service must be performed only by qualified personnel. Service or maintenance performed by unqualified personnel could result in risk of injury. When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section of this manual.

  • Page 5: Electrical Requirements & Safety

    ELECTRICAL REQUIREMENTS & SAFETY DOUBLE INSULATION This cutting tool is double insulated to protect you from electrical shock. WARNING Double insulated tools are equipped with a polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug.

  • Page 6: Warning

    ACCESSORIES AVAILABLE ACCESSORIES WARNING Use only accessories recommended for this rotary tool. Follow instructions that accompany accessories. Use of improper accessories may cause injury to the operator or damage to the rotary tool. WARNING Use only accessories designed for this rotary tool to avoid severe injury or tool damage.

  • Page 7: Carton Contents

    CARTON CONTENTS ROTARY TOOL COMPONENTS DESCRIPTION Rotary Tool Precision Handle with Sole Plate Freehand Sole Plate Attachment Circle Cutter Attachment Circle Cutter Installation Adapter Router Base Attachment 1/8” Collet 1/4” Collet 1/8” Lateral Style Drywall Cutter has "000028 HSS 1/8" marked on the shank of cutter 1/8”...

  • Page 8: Know Your Rotary Tool

    KNOW YOUR ROTARY TOOL...

  • Page 9: Assembly & Operation

    ASSEMBLY & OPERATION WARNING Remove the plug from the power source before assembly, changing accessories or cutters and making adjustments. This safety action will help prevent accidental starting of the tool which could result in serious injury. ON / OFF SWITCH This Rotary Tool is equipped with a sliding ON / OFF switch (1) located on the top of the tool (see Fig.

  • Page 10: Warning

    ASSEMBLY & OPERATION CHANGING COLLET INSERT The cutting bits for this tool are locked into place with a collet nut (1) and collet (see Fig. 3). The tool is assembled at the factory with a ” collet (2) which is used to hold the cutting bit.

  • Page 11: Warning

    ASSEMBLY & OPERATION WARNING Have you read “POWER TOOL SAFETY”, “ROTARY TOOL SAFETY” and “ELECTRICAL SAFETY” on pages 3, 4 and 5 of this Manual? If not, please do it now before you operate this ROTARY TOOL. Your safetydepends on it! Every time you use the Rotary Tool you should verify the following: 1.
  • Page 12 ASSEMBLY & OPERATION CUTTING OUTLET OPENINGS IN DRYWALL DANGER Do not attempt to use this tool to make cut-outs around any fixture or opening which has live electrical wires or on any wall which may have electrical wiring behind it. If a live wire is contacted, the bit could conduct the electric current to the tool, creating an electrocution hazard for the operator.
  • Page 13 ASSEMBLY & OPERATION PRECISION HANDLE INSTALLING PRECISION HANDLE The precision handle is designed for use when precision control over the tool movement is desired. The comfortable handle can be used with either the right or left hand. 1. Remove accessory locking knob (1) from the base of the Rotary Tool motor housing (see Fig.
  • Page 14 ASSEMBLY & OPERATION CIRCLE CUTTER CIRCLE CUTTER OPERATION WARNING Unplug the tool from the power source before changing accessories, changing bits and making adjustments. Before turning the tool ON, check to make sure bit and all accessory fasteners are securely tightened. 1.
  • Page 15 ASSEMBLY & OPERATION ROUTER BASE The router accessory converts your Rotary Tool into a small hobby router that is capable of handling small ¼” shank router bits as well as the spiral cutting bit. The tilting base is ideal for bevel cutting. WARNING Unplug the tool from the power source before changing accessories, changing bits and making...
  • Page 16 ASSEMBLY & OPERATION ROUTER BASE FREEHAND CUTTING AND ROUTING When the router base accessory is installed on the Rotary Tool, it will function as a small router to be used for freehand cutting of irregular shaped patterns. You can cut patterns out of the workpiece with the cutting bit or route patterns into the workpiece with small router bits.

  • Page 17: Maintenance

    OPERATION & MAINTENANCE ROUTER BASE CUTTING CURVED LINE WITH A TEMPLATE To cut a curved line, you can use a curved template to guide the router base. 1. Make a template from hardboard or other similar material to the shape you require (see Fig. 20). NOTE: Radius of curve must be greater than 2 ½”...

  • Page 18: Warranty

    Model PT302H TWO (2) YEAR LIMITED WARRANTY FANTOM warrants this product to be free from defects in material and workmanship for a period of two (2) years from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions.
